1.Put the back of the mobilepnone fixing component
to match the antenna and handle of the controller .
2.Press the controller to clicks into mobilephone
fixing component .
After you place the mobilephone on the holder ,
open the software and you can enjoy the real time
video showed on your mobilephone .
Return
Take
Record
Video
Media
Speed :30%
/60%/100%
Altitude
hold
Sensor Mode
Gravity
Virtual
Rocker
Menu
HOW TO START YOUR QUADCOPTER
Step1:Connect the
battery to the battery
port.
Step 2:Press the
ON/OFF power switch
up.
Step 3: Push the throttle
lever to the highest
position, And then pull
it back to the lowest
position. There will be
one clear sound from the
transmitter, this shows
that the quadcopter has
entered into the pre-fly
state.
Step 4: Pull the left control
stick to the left bottom and
right control stick to the
right bottom, then the
motor will be ready to work.
This is an extra operation
for the product with altitude
hold function.
HOW TO LAND YOUR QUADCOPTER
Way 1: After playing, control
the drone to the ground and
keep the throttle at the lowest
position for 3-4 seconds or
until the motor stop working.
Finally switch off the
transmitter and drone.
TIPS:
For the drone with altitude hold function, which means the drone can keep in the same flying altitude,the left
control stick(accelerator) will self-return to the center to keep balance. Player can push it up or pull it down
to control the drone at the altitude that he wants it to be when release the left control stick(accelerator).
Way 2: For fast turn off or any
emergency, pull the left control stick
to the left bottom and right control
stick to the right bottom, then the
motor will stop working at once.
Please do not do this operation while
the product in the sky, or it can fall
down suddenly due to non-working
motor.
M
Tested to comply with FCC standards .
FOR HOME OR OFFICE USE .
This device complies with part 15 of the FCC
Rules .Operation is subject to the following two conditions :
(1)This device may not cause harmful interference and
(2)This device must accept any interference received ,
including interference that may cause undesired operation .
WARNING: Changes or modifications to this unit are not expressly approved by the
party responsible for compliance and could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. The limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC ID : 2ABDSBL-775-104
WARNING: Changes or modifications to this unit are not expressly approved by the
party responsible for compliance and could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. The limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC ID : 2ABDSBL-775-104
WARNING: Changes or modifications to this unit are not expressly approved by the
party responsible for compliance and could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. The limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC ID : 2ABDSBL-775-104
WARNING: Changes or modifications to this unit are not expressly approved by the
party responsible for compliance and could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. The limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC ID : 2ABDSBL-775-104
WARNING: Changes or modifications to this unit are not expressly approved by the
party responsible for compliance and could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. The limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC ID : 2ABDSBL-775-104
