Steiner Mk7 Technical Manual

Mk7 BATTLE LIGHT

INTEGRATED SHOTGUN WHITE LIGHT LED 350 LUMENS / REPLACES MAGAZINE CAP

Technical Manual

MAINTENANCE:

• Never use strong cleaners or solvents on housing.

• Use soft towel and soapy water to clean external housing.

• Use damp towel to clean internal battery compartment. Excess moisture
inside battery compartment may damage unit.

• Use alcohol and soft towel to clean front window.

STEINER HERITAGE™ WARRANTY

We are committed to building optics that never need service. However,
should one become damaged or defective, for any reason other than theft or
deliberate misuse, we will repair or replace it at no charge – no questions
asked. That’s our promise to not only you, but to all those who will own your
Steiner optic after you.

• No warranty card needed

• No receipt required

• Fully transferable – from generation to generation

The Mk7 Shotgun Tactical Light features a stunning 350 lumen LED in
a sleek, compact package. The Mk7 offers the ability to remove the
pump stock tailcap from your shotgun and replace it with Mk7
adapter to integrate Mk7 light directly into the shotgun without
having to replace the pump stock.

FITS

• Benelli M4 (M1014)

• Benelli Nova

• Benelli Supernova

• Remington 870

• Mossberg 500

BATTERY INSTALLATION:

1. Remove rear cover.

2. Use provided screw driver to rotate battery cap counter clock wise and
remove from housing.

3. Install battery in correct orientation as marked on housing.

4. Install battery cap by turning clock wise into housing.

5. Do not over tighten battery cap.

SPECIFICATIONS:

• Power settings: High/Low

• Push button operation

• Integrated design replaces magazine cap

• Type: White Light LED

• Lamp: Light Emitting Diode

• Lumens: 350

• Divergence: 10°

• Range: 100 m

• Weight: 4.1 oz.

• Length: 3.54 in.

• Diameter: 1.34 in.

• Battery: 1 x CR 123A

• Battery Life: 1.0 hours

• Material: Anodized Aircraft Aluminum 6061-T6,
MIL-SPEC Type III Hardcoat Anodized

• Environment: Waterproof to 3 m

• Warranty: Heritage Warranty™
