Printed in Germany
HB 1750
Listed/Répertorié/Registrado
16C6
HB 1750
Thank you
for purchasing a STEINEL heat
tool. This device lets you perform
a wide variety of tasks such as
drying, shrinking, removing varnish, etc. safely and reliably.
9
All STEINEL devices are manufactured according to the highest
standards and subjected to
rigorous quality testing.
2
1
6
5
Used in the proper manner, this
heat tool will give you lasting
satisfaction.
3
7
8
Device components
1
Self-cooling aluminum
output tube
2
Mesh guard keeps out
foreign bodies
3
Remove screws to change
heating element
4
Sturdy rubber power cord
Slide switch with cool air stage
5
6
Plug-in key
7
Baffle adjusts air and temperature within range
Ergonomic soft grip handle
8
- 2 -
9
Color coded keys each lock in
a specific temperature range
Base includes key storage
10
area
Fully adjustable quick-lock
11
stand
12
Support for resting tool
4
HB 1750
10
11
12
7 3
Available Accessories (sold separately)
Your dealer has these nozzles available for you as accessories
1
/4’’ / 7 mm – Reduction nozzle for desoldering
A
Item No. 07695
B
8’’ / 200 mm – Spreader for films, packaging
and drying
Item No. 07725
C
Large reflector for shrink tubing up to 50 mm dia.
Item No. 07705
Small reflector for shrink tubing up to 20 mm dia.
D
Item No. 07715
A B C
- 3 -
D
English English
IMPORTANT SAFETY INSTRUCTIONS
READ THESE INSTRUCTIONS
UL WARNING: Read this instruction book before using. To reduce risk of fire or electric shock, do
not expose to rain or moisture. Store indoors. Double insulated. When servicing, use only identical replacement parts. When using electric tools, basic safety precautions should always be followed to reduce
risk of fire, electric shock and personal injury. This hot air gun operates at 1200°F with no visual
indication of temperature (no flame). Never leave device unattended. Otherwise risk of fire. The heat stream
at the outlet nozzle will burn flesh. Do not turn on heat gun with hand in front of nozzle. DO NOT USE
NEAR COMBUSTIBLE LIQUIDS. DO NOT USE FOR: ● Heating gas engines ● Heating car batteries ●
Thawing refrigerator equipment.
WARNING: Some dust created by power sanding, sawing, grinding, drilling and other construction
activities contains chemicals known (to the State of California) to cause cancer, birth defects, or other
reproductive harm. Some examples of these chemicals are:
● lead from lead-based paints,
● crystalline silica from bricks and cement and other masonry products, and
● arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work.
To reduce your exposure to these chemicals: work in a well ventilated area, and work with approved
safety equipment, such as those dust masks that are specially designed to filter out microscopic particles.
WARNING!
This tool is capable of producing temperatures up to 1200° F of flameless heat at the nozzle. ALWAYS:
● Direct the heat away from yourself and others.
● Prevent ignition of combustible materials on or near the workpiece.
● Prevent blockage of intake and nozzle openings.
● Keep a fully charged fire extinguisher on hand.
● Allow the nozzle and accessory tips to cool to room temperature before storage.
Cautions
1. WARNING: Hidden areas such as behind walls, ceilings, floors, soffit boards and other panels may contain
flammable materials that could be ignited by the heat gun when working in these locations. The ignition of
these materials may not be readily apparent and could result in property damage and injury to persons. Do
not use if in doubt about this hazard. When working in these locations, keep the heat gun moving in a backand-forth motion. Lingering or pausing in one spot could ignite the panel or the material behind it.
2. This heat gun can produce up to 1200° F of flameless heat at the nozzle. Do not direct airstream at clothing,
hair or other body parts. Do not use as a hair dryer.
3. Do not use near flammable liquids or in an explosive environment (fumes, gases or dust). Remove materials
or debris, that may become ignited, from work area.
4. Always hold tool by plastic enclosure. The metal nozzle requires approximately 20 minutes to cool after turning off the tool. Do not touch nozzle or accessory tips until cool.
5. Do not store tool until nozzle has cooled to room temperature. Place tool in a clear area away from combustible materials while cooling.
6. Do not cut off airflow by placing nozzle too close to workpiece. Keep intake vents clean and clear of obstructions.
7. Place cord in a position that won’t cause tipping.
8. Do not leave tool unattended while running or cooling down. Otherwise risk of fire.
9. Keep a fully charged fire extinguisher nearby.
10. Do not direct airflow directly on glass.
11. Shield materials around the heated area to prevent damage or fire.
12. Use only with 120 V AC voltage.
13. Do not use in wet conditions.
14. Not to be used by children. This is not a toy and should be respected.
15. Do not use in bath or over water.
16. Safety glasses should be worn when using this tool.
17. It is recommended that leather gloves be worn when using a heat gun.
- 4 - - 5 -
18. Always unplug after use.
19. WARNING: Extreme care should be taken when stripping paint. The peelings, residue and vapors of paint
may contain lead, which is poisonous. Any pre-1977 paint may contain lead and paint applied to homes
prior to 1950 is likely to contain lead. Once deposited on surfaces, hand to mouth contact can result in
the ingestion of lead. Exposure to even low levels of lead can cause irreversible brain and nervous system
damage; young and unborn children are particularly vulnerable. Before beginning any paint removal
process you should determine whether the paint you are removing contains lead. This can be done by
your local health department or by a professional who uses a paint analyzer to check the lead contact of
the paint to be removed. LEAD-BASED PAINT SHOULD ONLY BE REMOVED BY A PROFESSIONAL
AND SHOULD NOT BE REMOVED USING A HEAT GUN.
20. Do not allow dust, debris or other contamination to enter the heat blower air intake. They may ignite or cause
damage to the tool.
Persons removing materials should follow these guidelines.
1. Move the work piece outdoors. If this is not possible, keep the work area well ventilated. Open the windows and put an exhaust fan in one of them. Be sure the fan is moving the air from inside to outside.
2. Remove or cover any carpets, rugs, furniture, clothing, cooking utensils and air ducts.
3. Place drop cloths in the work area to catch any residue. Wear protective clothing such as extra work
shirts, overalls and hats.
4. Work in one room at a time. Furnishings should be removed or placed in the center of the room and
covered. Work areas should be sealed off from the rest of the dwelling by sealing doorways with drop
cloths.
5. Children, pregnant or potentially pregnant women and nursing mothers should not be present in the work
area until the work is done and all clean up is complete.
6. Wear a dust respirator mask or a dual filter (dust and fume) respirator mask which has been approved
by the Occupational Safety and Health Administration (OSHA), the National Institute of Safety and Health
(NIOSH), or the United States Bureau of Mines. These masks and replaceable filters are readily available
at major hardware stores. Be sure the mask fits. Beards and facial hair may keep masks from sealing
properly. Change filters often.
DISPOSABLE PAPER MASKS ARE NOT ADEQUATE.
7. Use caution when operating the heat gun. Keep the heat gun moving as excessive heat will generate
fumes which can be inhaled by the operator.
8. Keep food and drink out of the work area. Wash hands, arms and face and rinse mouth before eating
or drinking. Do not smoke or chew gum or tobacco in the work area.
9. Clean up all removed residue and dust by wet mopping the floors. Use a wet cloth to clean all walls,
sills and any other surface where residue or dust is clinging. DO NOT SWEEP, DRY DUST OR VACUUM.
Use a high phosphate detergent or trisodium phosphate (TSP) to wash and mop areas.
10. At the end of each work session put the residue and debris in a double plastic bag, close it with tape
or twist ties, and dispose of properly.
11. Remove protective clothing and work shoes in the work area to avoid carrying dust into the rest of the
dwelling. Wash work clothes separately. Wipe shoes off with a wet rag that is then washed with the work
clothes. Wash hair and body thoroughly with soap and water.
SAVE THESE INSTRUCTIONS
Please Note
This heat tool may emit a vapor during the first few minutes of operation. This is normal and due to residue
from the manufacturing process. It is burned off after the first few minutes of operation.
English English
Double Insulated Tools
Tools marked with the words “Double Insulated” are equipped with a two prong plug. These
tools have a special insulation system that complies with applicable UL and CSA standards.
They do not require grounding. ”Double Insulated” tools, like this one, have two prong cords and
can use either a two or three prong extension cord.
“This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of
electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not
fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not
modify the plug in any way.”
Extension Cords
As the distance from the supply outlet increases, heavier
gauge extension cords are required. The use of extension
cords of inadequate size wire causes a serious drop in voltage and loss of power. Protect the cord from damage. Keep
cords away from excessive heat, sharp edges and damp or
wet areas. Repair or replace damaged extension cords before using.
Technical specifications
Ext. Cord Length Wire Size
085 Ft. 14
100 Ft. 12
170 Ft. 10
270 Ft. 08
400 Ft. 06
650 Ft. 04
Voltage
Output
Airflow
Temperatures
Available Temperature Keys
Protection class
Item No.
34750
34751
34752
34753
34754
34755
Model
HB 1750
HB 1750 B
HB 1750 G
HB 1750 Y
HB 1750 O
HB 1750 R
120 V / 60 Hz
1750 W
up to 23 CFM, adjustable with baffle
Level 1: 80°F
Level 2: selected by key
Red: 1000 – 1200 °F
Orange: 750 – 1000 °F
Yellow: 500 – 750 °F
Grey: 300 – 500 °F
Blue: 200 – 300 °F
Double insulated
Description
Heat Blower with all 5 Keys
Heat Blower with Blue Key
Heat Blower with Gray Key
Heat Blower with Yellow Key
Heat Blower with Orange Key
Heat Blower with Red Key
Temperature Range
200 – 1200 °F
200 – 300 °F
300 – 500 °F
500 – 750 °F
750 – 1000 °F
1000 – 1200 °F
- 6 - - 7 -
For your safety
This heat tool incorporates a thermal fuse which automatically switches the device off in cases of severe
overheating.
Getting started
Operation
The device is switched on and off
with the selector switch on the
front of the handle. The distance
from the object being processed
depends on the material and the
intended type of processing.
Temperature Selection
Level 1 is the cool air setting. The
temperature is approximately 80°F
(room temperature). Use the cool
air function to dry paint, to cool
workpieces or to cool the nozzle
before changing an accessory
part. At Level 2 the blower temperature is determined by means
Always do an initial test with regard to air volume and temperature. With the optional accessory
nozzles (see accessories on page
3), the hot air can be precisely
targeted to specific points or sur-
of the key used and the position of
the rotary wheel. Color coded keys
each lock in a specific temperature
range. When not in use, keys may
be stored on the convenient base.
Disconnect the device from the
power supply before changing the
keys. Remove the key to be
faces. Exercise caution when
changing hot nozzles! When
you use the heat gun as a stationary device, ensure that it is
positioned securely on a clean
surface so that it cannot slip.
changed from the device using
your thumb and index finger.
Select the desired temperature key
from the stand and insert it into the
unit. After the key locks into the
unit, the device can be switched
on again.
Adjustable Baffle
Turn the baffle to adjust the
air and temperature within the
range allowed by the key in use.
Turning the baffle toward LO low-
Working with the stand
Push the quick-lock switch
on the base using your thumb
and index finger and set the
Changing the heating element
The HB 1750’s plug-in heating
element is quick and easy to
change.
1. Caution! Disconnect the
device from the power supply.
Exercise caution if the device
was being used previously.
7
11
ers the temperature while increasing the airflow. Turning the baffle
toward HI increases the temperature while decreasing the airflow.
device into the guide channel.
Then release. Press the locking
switch to adjust the blower
The protective tubing will be
very hot. Let it cool down first!
2. Unscrew the the two screws
3
at the end of the protective
tubing.
3. Remove the protective tubing.
4. Remove the heating element
and replace it with a new one.
See Technical Specifications for
the temperature range defined by
each key.
direction of the HB 1750 by
swivelling it.
5. Replace the protective tubing
and screw it tight.
English
Limited Warranty
STEINEL warrants that STEINEL brand heat tools are free from defects in materials and
workmanship. The warranty for STEINEL heat tools is one year from the date of original
purchase.
Products failing to give satisfactory service must be returned to STEINEL for diagnosis
and evaluation. Tools found to have failed due to defective materials or workmanship will
be repaired or replaced at STEINELs election and expense.
Consumable products are not covered by any warranty. Consumables are products reasonably expected to be used up or damaged during use, as well as products with a shelf life, such as certain glues. Note that while heating elements are
consumable products, STEINEL DOES warrant them for one year under normal
use, which for heating elements is defined as up to 500 hours of operation.
STEINEL does NOT warrant any product or part subject to abnormal use or abuse.
Specifically excluded from warranty are tools that have been misused, modified, mounted
on machinery/equipment, opened or repaired by anyone other than STEINEL, and products that have been worn by continuous or production service use. STEINEL does not
provide any warranty for tools which have been improperly maintained, neglected, or
subject to unreasonable conditions or use.
STEINEL shall NOT be liable for any incidental or consequential costs or damages arising
from the use of the product or incurred by the purchaser or others, including but not limited to lost sales, profits, business opportunities, goodwill, interruption of business, failure
to deliver and any other damage or injury. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you.
This warranty is your exclusive remedy and is in place of all other rights and remedies.
You may have other rights which vary from state to state or country.
Please contact STEINEL for an RGA prior to returning any product for warranty claim.
Have ready your proof of purchase and complete information regarding conditions of use
and difficulties experienced.
STEINEL America Inc.
9051 Lyndale Avenue South
Bloomington, MN 55420
Tel.: 952-888-5950
Fax: 952-888-5132
Toll free: 1-800-852-4343
E-mail: sales@steinel.net
Visit our website: www.steinel.net
- 8 -
Loading...
