Staub Electronics EA-AMP-12D-70A User Manual
Multi-Channel, Class D,
OWNER’S MANUAL >>
70 Watt Amplier
EA-AMP-12D-70A EA-AMP-8D-70A
12 CHANNEL 8 CHANNEL
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of re or electric shock, do not expose this apparatus in or near rain or moisture.
1. Read the following instructions carefully.
2. Keep manual for future reference.
3. Heed all warnings.
4. Follow all instructions in this manual.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install according to manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus
(including ampliers) that produce heat.
9. Do not override the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades -
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade
or the third prong is provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles, and
the point where it exits from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with a cart, stand, tripod, bracket or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged
in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. To completely disconnect this equipment from the AC mains, disconnect the power supply cord plug from
the AC receptacle.
The lightning ash with arrowhead symbol, within an equilateral
CAUTION
CAUTION: TO REDUCE THE RISK
OF ELECTRICAL SHOCK, DO
NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
triangle, is intended to alert the user to the presence of
uninsulated dangerous voltage within the product’s enclosure
that may be of sufcient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
WELCOME TO EPISODE
Episode® is one of the most highly-regarded brands of audio products available today. We appreciate your business, and we
stand committed to providing our customers with the highest degree of quality and service in the industry
These Episode® Ampliers are built on the latest digital technology and deliver efcient, clean power to every room. Each model
is designed to produce the subtle details of music, while having the exibility to meet a variety of installations. For the best sound
quality, use Episode® Speakers to complete the system.
®
FEATURES
DURABLE AUDIOPHILE DESIGN
These Episode Ampliers use the latest digital technology to deliver cool-running performance from a compact, reliable package.
Plus, they feature superior quality components for outstanding sound quality and are up to 90% more efcient than conventional
analog designs.
MULTIPLE STAGES OF PROTECTION
Each pair of channels (or Zone) is individually protected with an operation mode indicated by bi-color LEDs on the front of the
amplier. These enable simple troubleshooting. If the circuitry determines that a channel must be shut down for protection due
to a short, only the channels that are affected will be turned off. The other zones will continue to play.
GLOBAL A & B AND DIRECT INPUTS
A dedicated input can be assigned to a pair of channels via the channel Line In connection. Each pair of channels can also
be congured to play common signals from the global input. When using the global connections, odd-numbered channels will
receive the right channel, and the even-numbered channels will receive the left channel. This is further indicated by the color of
the channel Line In jacks (odd numbers have white jacks and even numbers have red jacks). A 3 position switch is available for
each channel pair to choose between the line-in and the 2 Global-Inputs. This provides unparalleled exibility that is needed for
today’s demanding custom audio installations.
INDIVIDUAL CHANNEL AND GAIN ADJUSTMENTS
Each pair of channels has its own level adjustment which adjusts the maximum output. This allows the output of to be perfectly
matched to its area. It can also serve to provide a limit on how loud each speaker may be allowed to play. Be sure set the
volume at a level that does not clip or cause distortion when the volume is at the maximum level. This can cause damage to the
speakers and the amplier.
INSTALLATION-FRIENDLY CONNECTIONS
Each pair of speakers feature a removable speaker wire connector that accommodates up to 14 gauge stranded speaker wire.
The power cord is removable as well, facilitating fast and simple installations. The Global Inputs, Loop Output, and individual
Channel Inputs are all high-quality RCA connectors.
BRIDGING
The power output of adjacent channels can be combined to provide extra power when needed in certain areas.
This is easily accomplished by ipping a single switch. Maintain an 8 ohm minimum when using bridge mode.
RACK-MOUNTABLE
Each Episode amplier includes an accessory package of rack ‘ears’ that may be attached to the amplier. The amplier feet
can be easily removed for clean rack mounting. The amplier chassis and rack ears are NOT designed to support anything other
than the amplier. DO NOT stack components on top of the amplier, as it could damage the amplier’s chassis.
POWER MODE
Power state can be toggled using the front Power Button, 12V input, or Audio Sensing. The method for power toggle is set by
using the Power Mode Switch on the rear of the amplier. See Power Mode Switch under Rear Channel Features for information
on the operation of each mode.
Note: The front panel power button is inoperative when the 12V Trigger or Audio Sense power modes are selected.
© 2011 Episode
pg.3
EA-AMP-12D-70
1 2 3 4 5 6 7 8 9 10 11 12
REAR PANEL FEATURES (12D and 8D)
1. GLOBAL INPUT
Easily amplify outputs from any stereo source across any/all channels
2. LOOP OUT
Allows global inputs to be sent to other ampliers
3. GAIN CONTROL
Allows independent gain for each pair of inputs
4. BRIDGED SWITCH
Easily couple two channels together for increased power
NOTE: 8-ohm minimum when using bridge mode
5. LINE INPUTS
Individual channel inputs for use with multi-channel preamps/ or dedicated sources
pg.4
EA-AMP-8D-70
1 2 3 4 5 6 7 8 9 10 11 12
6. INPUT SWITCH
Choose between global inputs and individual inputs for each channel
7. SPEAKER OUTPUTS
8. MASTER POWER SWITCH
Disables power to the amplier
7. POWER MODE SWITCH
Sets the ampliers power mode:
On – Turns ON / OFF via front power button
12V – Turns on when +12V is received at Trigger input
AUDIO - Turns on when a minimal amount of audio signal is received at the audio
inputs and will go into standby after 18 minutes of no audio signal.
Note: The front panel power button is inoperative when the 12V Trigger or Audio Sense power
modes are selected.
10. 12V TRIGGER IN/OUT
Turns amplier on when 12v dc is applied and power mode switch is set to 12v. This 12v
signal is regenerated to the 12v out for triggering additional ampliers.
Note: the front panel power button is inoperative when the 12v trigger or audio sense power
modes are selected.
© 2011 Episode
11. POWER CONNECTOR
12. FUSE LOCATION
pg.5
