SERVICE HANDBOOK

®

SandBlaster

Self Cleaning Commercial Gas Water Heaters with Flue Damper and Electronic Ignition

M O D E L S C O V E R E D

SBD71 120 Through SBD85 500

Also includes Parts List

Part Number STC-072

Printed in the U.S.A. - 0106

COMMERCIAL

The Expert’s Choice®

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD

HANDBOOK

TABLE OF CONTENTS

PAGE PAGE Troubleshooting (continued) Introduction 1-2 Troubleshooting the Efflkal 28-30 Wire Harness Test 31 Installation 3 IID Module 32 Clearances 4 Pilot Spark 33 Air Requirements 5-8 Pilot Valve 34-35 Contaminated Air 9 Main Burner Test 36 Flammable 9 Flame Rectification 37 Gas Pressure 10 IID Module 38 Gas Valve 11 Main Gas Valve 39-40 Venting 12-15

Sequence of Operation Mechanical 16 Service Charts and General Electrical 17-18 Questions and Answers 41-42

Troubleshooting Parts List 43-50 Transformer 19 High Limit 20-21 Component Part Information 51 Damper (on Standby) 22 PC Board 22-23 Service Check List 52-53 Thermostat 24 Effikal Damper 25 Comments 54

Effikal Harness Test 26 Normal Operation 26-27

SBD SERVICE HANDBOOK INTRODUCTION

This service handbook is designed to aid in servicing and troubleshooting State SBD water heaters in the field. No duplication or reproduction of this book may be made without the express written authorization of the State Water Heater Company.

The following text and illustrations will provide you with a step by step procedure to verify proper installation, operation, and troubleshooting procedures. Additional quick reference data is included to assist you in servicing this product.

The information contained in this handbook is designed to answer common questions encountered in the operation of the SBD product line and is not meant to be all inclusive. If you are experiencing a problem not covered in this handbook, please contact the Technical Information Department at 1-800-365-0577 or your Local State Water Heater Sales Representative for further assistance. This handbook is intended for use by licensed plumbing professionals and reference should be made to the installation manual accompanying the product. This handbook contains supplemental information to the SBD installation and operation manual.

1

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

Qualifications: Installation or service of this water heater requires ability equivalent to

that of a licensed tradesman in the field involved. Plumbing, air supply, venting, gas supply and electrical testing skills are required.

Tools Required:

• Phillips head screwdriver

• standard screwdrivers

• a 3/8 and 7/16 inch open end wrench

• set of marked drill bits

• an electrical multimeter tester capable of measuring continuity

• gas pressure gauge or manometer

• water pressure gauge

• thermometer

• 1/2 inch socket with extension for removal of the clean out cover,

• 1 1/16 inch socket with extension for anode removal.

CUSTOM COMMERCIAL STORAGE TANK MODEL NUMBER BREAKDOWN

Model Breakdown

SBD 85 500 P E A CGA D

S D 85

Sandblaster/Damper

85

Gallon

500,000

BTUH

*Up to 8,000 Feet

500

P

Propane

Warranty

E

3 Year

None=Standard

CGA

T=Tall

S=Short

A DB

Canadian

Product

(if applicable)

ASME

Constructed

High

Altitude*

2

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

INSTALLATION

This portion of the handbook will review some often overlooked installation considerations, taking note of necessary installation requirements for the SBD 71120 through SBD 85500 model heaters. The installation manual covers most of these items in detail.

MODEL A B C

120 - 200 1” (2.54CM) 1” (2.54CM) 1” (2.54CM) 250 - 305 2” (5.08CM) 2” (5.08CM) 2” (5.08CM) 365 - 400 3” (7.75CM) 3” (7.75CM) 3” (7.75CM)

500 5” (12.7CM) 5” (12.7CM) 5” (12.7CM)

A 24 inch clearance for all serviceable parts is recommended. Clearances may vary between SBD models – See instruction manual or the label on the heater, for clearances applicable to your specific model.

*20” (50.8CM) for 500 models.

CLEARANCES FROM COMBUSTIBLES

Clearance to Combustibles Table

3

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

EXTERIOR CLEARANCE

"Copyright by the American Gas Association. Used by permission of the copyright holder".

This illustrates the exterior roof clearances for SBD units with natural draft venting. The vent shall extend at least 3 feet above the highest point where it passes through a roof of a building, and at least 2 feet higher than any portion of a building within a horizontal distance of 10 feet (for vents of 12" in diameter or less). (NFPA 54 ANSI Z 223.1 SEC

7.5.2a). (Sec 7.6.2a may allow reduction to 8 feet with a “ Listed vent cap”).

4

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

AIR FOR COMBUSTION

10 CUBIC FEET OF AIR PER 1,000 BTU

1

,

0

1

,

0

1

B

Stoichiometric or theoretical complete combustion requires 10 cubic feet of air per 1000 BTUH input of the gas input. The National Fuel Gas Code also recommends an additional 2.5 cu.ft. of "excess" air. This 12.5 cu.ft minimum supply air per 1000 BTUH input applies to natural and propane gas models.

The National Fuel Gas Code also specifies minimum make-up air opening sizes for various building installations. (Ref: NFPA 54, ANSI Z223.1, sec 5.3)

0

,

0

T

0

U

0

2.5 CU. FT.

EXCESS

AIR

10 CU.

FT.

COMB.

(Minimum)

5

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

MAKE-UP AIR

DIRECT COMMUNICATION

A fresh supply of make-up air for combustion can be supplied to the heater through makeup air ducts which directly communicate with the out of doors. Two openings are required

- one within 12 inches of the top of the enclosure and one within twelve inches of the bottom of the enclosure. Each opening shall have a free area of not less than 1 square inch per 4000 BTUH of the total input of all appliances within the enclosure.

The lower opening is primarily providing combustion air. The upper opening is providing vent dilution air and acts as a relief opening for flue gases should the vent become obstructed or a downdraft condition occur. Additionally, when the heater is installed in a confined space and communicating with the outdoor air, one permanent opening, commencing within 12 in. (30 cm) of the top of the enclosure, shall be permitted where the equipment has clearances of at least 1 in. (2.5 cm) from the sides and back and 6 in. (16 cm) from the front of the appliance. The opening shall directly communicate with the outdoors and shall communicate through a vertical or horizontal duct to the outdoors or spaces (crawl or attic) that freely communicate with the outdoors, and shall have a minimum free area of:

a. 1 sq. in. per 3000 BTU per hr (7 cm

located in the enclosure, and

b. Not less than the sum of the areas of all vent connectors in the confined space.

1 Square Inch Per 4,000 BTUH

2

per kW) of the total input of all equipment

6

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

MAKE-UP AIR

VERTICAL DUCTS

1 Square Inch Per 4,000 BTUH

Often it is more practical to install vertical make-up air ducts to the out doors. Again, two openings are required - one within 12 inches of the top of the enclosure and one within twelve inches of the bottom of the enclosure. Each opening shall have a free area of not less than 1 square inch per 4000 BTUH of the total input of all appliances within the enclosure.

MAKE-UP AIR

HORIZONTAL DUCTS

When the heater is installed in an interior room with no roof access for vertical ducts, horizontal make-up air ducts should be installed. When using horizontal ducts, two openings are required - one within 12 inches of the top of the enclosure and one within twelve inches of the bottom of the enclosure. Each opening shall have a free area of not less than 1 square inch per 2000 BTUH of the total input of all appliances within the enclosure.

1 Square Inch Per 2,000 BTUH

7

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

INSUFFICIENT MAKE-UP AIR

BACKDRAFT

Insufficient make-up air is a major cause of combustion problems. One common example is in a restaurant installation where exhaust vent equipment was not considered in sizing make-up air requirements. This may result in air being backdrafted by the restaurant exhaust equipment through the heater causing flue gas spillage, flame roll out, improper combustion, inconsistent pilot operation, and/or erratic heater shut down.

8

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

CONTAMINATED AIR

Along with adequate make-up air, the quality of the air is important. Contaminants in combustion air can lead to premature heater failure. Vapors from bleaches, soaps, waxes, salts, etc. are drawn into the combustion chamber with the make-up air and, once fired, mix with water vapor in the gases to form extremely corrosive hydrochloric or hydrofluoric acid and other corrosive byproducts.

AIR FOR COMBUSTION

Flammable Items

Flammable items, pressurized containers or any other potentially hazardous articles must never be placed on or adjacent to the heater. Open containers of flammable material should not be stored or used in the same room with the heater.

9

Supply Gas

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

GAS PRESSURE REQUIREMENTS

Manifold Pressure Tap

Dirt Leg

Manifold Gas Port

Maximum Supply Pressure 10.5" W.C. 13.8" W.C. Minimum Supply Pressure 5.0" W.C. 11" W.C.

Manifold Pressure 4.0 " W.C. 10" W.C.

The supply gas pressure is normally measured at the dirt leg or at the gas pressure tapping on the gas supply shutoff valve. This reading must be measured with 'flowing' gas.

The manifold gas pressure is measured at the manifold pressure tap of the gas valve when the gas is flowing.

Natural Gas Propane Gas

10

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD GAS VALVE

The gas valves used on all SBD water heaters are 24 volt AC combination step opening gas valves. They incorporate the pilot valve, main valve, and gas pressure regulators into one body. The inlet view of the valve features a filter screen and the top knob. The top knob is a manual on/off gas control for both the pilot and main gas valves. When the top knob is placed on the black mark, gas is supplied only to the pilot valve.

On the top view, we see the pilot solenoid and pilot and main gas regulators. The top view also displays the “TH and “TR” terminals. The pilot gas regulator is found under its cover screw. It is factory preset at 3.5” W.C. but can be adjusted from

2.5 to 5 inches water column. The main gas regulator is found under its cover screw. It is factory preset to 3.5 inches W.C. and adjusts gas pressure output from 2.5 to 5 inches water column. The two electrical terminals are marked TH and TR. The TH terminal is the common between the pilot valve solenoid coil and the main valve solenoid coil. The other wire emerging from the pilot solenoid connects to the pilot valve electrical output on the IID (terminal PV). The TR terminal connects directly to the main valve electrical output from the IID module (terminal MV).

On the outlet view of the gas valve, we see the pilot gas connection port, manifold gas connection port, a limited bleed vent port, the manifold gas and pressure tap.

See step 18 for SBD-500 gas valve illustration

11

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

VENTING

Atmospheric, Single, and Multiple Heaters

All SBD water heaters are classified by ANSI as category I (non-condensing, negative pressure venting) appliances. They are approved for type B vent.

For larger applications, SBD water heaters can be common vented together either in a tapered manifold or constant size manifold. (Follow National Fuel Gas Code requirements for sizing and installation.)

Combined Vents

When vents are combined, the area of the combined vent should be equal to area of the largest single vent, plus 50% of area of all others joining.

EXAMPLE: To combine two 6” vents with an 8” vent, the area of a combined vent should be one half area of two 6 inch vents (14 + 14) plus area of 8 inch vent (50) or 78 sq. inches. Referring to chart, 78 sq. inches require 10” diameter vent.

Area in S q u are

Vent Size

5" 20 10" 79 6" 28 12" 113 7" 38 14" 154 8" 50 16" 201 9" 64 18" 254

Inches Vent Size

Area in Square

Inches

Nine Rules for Good Vents

1. The vent pipe should ALWAYS be the same size as the outlet of the draft diverter or factory supplied vent reducer.

• Model SBD 120 are supplied with a 6” to 5” reducer.

• Models SBD 250, 251 and 275 are supplied with a 8” to 6” reducer.

12

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

Nine Rules for Good Vents (continued)

2. The diameter of a vent pipe should NEVER be reduced, no matter what the circumstances.

3. In some cases it may be necessary to run a vent larger than the draft diverter outlet.

4. Take the maximum vertical rise possible immediately above the draft diverter.

5.

13

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

Nine Rules for Good Vents (continued)

6. Horizontal pipe should be sloped upward at a minimum of ¼” per foot.

7. Horizontal elements should be limited to 75% of the vertical rise of the vent above the connection.

8. Flue gases must be kept hot for proper venting.

The vent pipe should be extended to meet local codes

9. Obstructions can cause down drafts.

14

POWER VENT KITS FOR SIDEWALL VENTING

Female plug to Damper

40’, Power Venter cable with “Y” connect

Male plug to Cable

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

Water Heater Models Part Number

SBD-120-200 193933-0 SBD-250-500 193933-1

SBD water heaters can be used with power vent kits for sidewall venting. State offers power vent kits for use on installations with a maximum of 100 equivalent feet of vent piping. The power vent kits also use type B vent materials. When power venting, specific exterior clearances must be maintained, as outlined in the National Fuel Gas Code. (NFPA 54, ANSI A223.1, sec 7.8)

15

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD SEQUENCE OF OPERATION

9. Flue damper closes

1. Thermostat calls for heat

7. Thermostat satisfies

3. Intermittent Ignition Control

2. Flue damper opens

4. Pilot gas opens, Pilot sparks and flame proves

6. Main burner ignites

5. Main gas valve opens

8. Main and pilot burners "OFF"

SEQUENCE OF OPERATION

To understand SBD tank type water heaters, an examination of their sequence of operation is necessary.

When the thermostat calls for heat, the relay in the draft hood assembly activates the flue damper motor. The damper opens and power flows to the IID (Intermittent Ignition Device). This activates the IID module to open the pilot valve and begin sparking at the pilot burner assembly. Once the pilot flame is established and confirmed back to the IID, the sparking is stopped and the main gas valve is opened, allowing gas flow to the main burner. When the thermostat satisfies, main and pilot gas is shut off. Damper is returned to closed position.

16

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD ELECTRICAL SEQUENCE

100 – 109 Series

17

SBD TANK TYPE HEATERS

p

SERVICE HANDBOOK

SBD ELECTRICAL SEQUENCE OF OPERATION

115/60/12A

120 VAC to Junction Box

On / OFF Switch "ON"

24V Transformer

Tank Temperature

Calling for Heat

Tank Temperature

Satisfied

High Limit Closed

High Limit (ECO)

Closed

Thermostat Closed

Motor Opens

Damper

Cam On Damper Blade

Closes Proving End Switch

Motor Closes

Damper

IID Module

(24V) Receives Voltage

Module (PV) Terminal

Sends 24V to Pilot Coil

Module (Spark) Sends 10,000V Spark to Pilot

Pilot Ignites and Proves Flame

Spark Stops

Module (MV)

Terminal Sends 24V

To Main Gas Coil

90 Second Trial /

5 Minute Delay Between

Trials - Continuously

Main Burner Heats Tank

Themostat Opens

Power to Damper

#2 Interru

ted

Damper Motor Energized

and Damper Closed

18

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

TROUBLESHOOTING SBD WATER HEATERS

To troubleshoot a SBD water heater check that:

• 120 VAC is supplied to the heater

• the tank is full of water

• gas is supplied to the unit

STEP 1 TEST THE TRANSFORMER

STEP 1 - TO TEST THE TRANSFORMER - Using a multimeter, test for 24 VAC

between the secondary transformer terminals.

IF THEN

The meter does not read 24 VAC: • Check that the 120 VAC is supplied

from the On/Off Switch – if not, replace switch.

• Check that the 120 VAC is supplied from transformer.

The meter reads 24 VAC: • Go to step 2.

19

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 2 HIGH LIMIT, LEFT TERMINAL TEST

Ground

24 VAC

FM Transformer

STEP 2. HIGH LIMIT, LEFT TERMINAL TEST. Test for 24 VAC between the left high

limit terminal and ground.

IF THEN

The meter does not read 24 VAC: • Check wiring between transformer and

high limit.

The meter reads 24 VAC: • Go to Step 3.

Note: The high limit (Energy Cut Off) opens if the tank water temperature exceeds 205 degrees. The control is resettable (manually) when the tank water temperature drops below 185 degrees.

20

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 3

TEST HIGH LIMIT RIGHT TERMINAL

High Limit (ECO)

Reset Button

Temperature

Adj. Dial

High

Black-To

Damper Motor

STEP 3. TO TEST HIGH LIMIT RIGHT TERMINAL. Ensure that the jumper wire

between the high limit and thermostat is connected, and the damper motor power line is connected. Test for 24 VAC between the high limit right terminal and ground.

IF THEN

The meter does not read 24 VAC: • Push the reset button and redo the test (storage

water temperature below 185 degrees).

The meter reads 24 VAC: • Go to step 4.

After Push in Reset - 24 VAC is now present

Reasons For Resetting

Condition Cause Solution

High limit open Never set on initial

installation

Excessive water temperature Faulty thermostat Replace dual control Heater shut down before

reaching thermostat setting

Note: The right terminal of the high limit has a jumper wire connected to the left terminal of the thermostat. There is also a black wire connecting to the damper motor assembly. This black supplies power to the motor to close the damper during periods of standby.

Faulty high limit Replace dual control

21

Push high limit button

Limit/Thermostat

Jumper Wire

wire

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 4 INSPECT THE DAMPER

DDaammppeerr CClloosseed

STEP 4. INSPECT THE DAMPER. Lower the thermostat setting so the unit will not be

calling for heat, then inspect the damper.

IF THEN

If the damper is open: • Go to step 5. If the damper is closed: • Go to step 7.

Note: If the water temperature in the tank is below 120 degrees F, temporarily disconnect the jumper wire between the high limit and thermostat to simulate a satisfied thermostat.

d

DDaammppeerr OOppeen

n

STEP 5 CHECK THE PC BOARD

STEP 5. CHECK THE PC BOARD. Test for 24 VAC between the black PC board wire

connection and ground.

IF THEN

24 VAC is not present: • Check the black wire connections

between PC Board and high limit.

24 VAC is present: • Go to step 6.

22

STEP 6 PC BOARD MOTOR TEST

Service Switch

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

Motor Lead

STEP 6. PC BOARD/MOTOR TEST. Check for 24 VAC between the two motor lead

terminals of the PC board. Disconnect the wires for this test.

IF THEN

24 VAC is not present: • Replace the Damper Drive (part #

194484) and go to step 7. The board and relay are one piece. Regardless of which part is defective, both parts should be changed.

Voltage is present: • This verifies that the motor is receiving

power but not closing the damper.

• Replace the Damper Drive and go to

step 7.

Note: The service switch may be used to bypass the damper, while waiting for a replacement part.

WARNING - In the event of damper motor failure, verify that the damper is in the "open" position before utilizing the service switch

23

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 7 THERMOSTAT TEST

STEP 7. THERMOSTAT TEST. Set the thermostat to call for heat. Using your

multimeter, test for 24 VAC between right terminal and ground.

IF THEN

The meter does not read 24 VAC and the jumper wire

• Replace the thermostat between the high limit and the thermostat is in place: The meter reads 24 VAC: • Go to step 8.

Note: If the high limit to thermostat jumper wire was disconnected earlier to simulate a satisfied thermostat, reconnect the jumper to the terminals.

Note: A yellow wire from this thermostat terminal connects to the damper PC board.

24

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

EFFIKAL DAMPER

The wiring colors from the damper PC Board are different colors than the wires on the heater wiring harness. The male/female plugs to connect the damper board to the heater harness join in only one way.

Adapter

Plug

Service Switch

Heater Harness

Effikal Control Cover (Photo of kit mounting) Effikal Style

Motor

Lead

Terminal

Adapter not necessary on production 110,111 Series The heater harness wires still serve the same function:

Black – 24V Constant if high limit closed Yellow – 24V To damper if the thermostat is closed Red – 24V From damper to IID if damper closes end switch White – Neutral (common)

Orange Brown Yellow Black

Motor Lead

Motor

Damper

1234

From Heater

Black

Male Plug

Black

Red

Yellow

21

4

White

Female Plug

3

25

Heater Harness Function Damper Harness

Black 24V Hot 1-Brown Yellow 24V from Thermostat 2-Orange Red 24V from damper 3-Yellow White 24V common 4-Black

Condition:

• Heater on standby

• Damper closed

• High Limit closed

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

HARNESS CHART

NORMAL OPERATION

Wires are from left to right: Black i Yellow i Brown i Orange

TEST FOR 24VAC BETWEEN BLACK (COMMON)

STEP 8

STEP 8. TEST FOR 24VAC BETWEEN BLACK (COMMON) AND BROWN

IF THEN

24VAC is present Continue to Step 8A. 24VAC is not present See Troubleshooting Step 9A

AND BROWN

26

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

NORMAL OPERATION (continued)

Condition:

• Thermostat closed, damper in process of opening

STEP 8A TEST FOR 24VAC BETWEEN BLACK AND ORANGE

IF THEN

24VAC is present Continue to Step 8B. 24VAC is not present See Troubleshooting Step 9B.

Condition:

• Thermostat closed, damper fully open

STEP 8B TEST FOR 24VAC BETWEEN BLACK AND YELLOW

IF THEN

24VAC is present Continue to Step 10A. 24VAC is not present See Troubleshooting Step 9B.

27

SBD TANK TYPE HEATERS

TROUBLESHOOTING THE EFFIKAL DAMPER

Condition:

Thermostat closed, damper closed

Wires are from left to right: Black i Yellow i Brown i Orange

SERVICE HANDBOOK

TEST BETWEEN BLACK (COMMON) AND BROWN

STEP 9A

IF THEN

24VAC is present This is correct 24VAC is not present • See Steps 1 thru 4

ON THE DAMPER BOARD

Check the harness plugs connecting heater and damper for looseness or damage.

28

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

TROUBLESHOOTING THE EFFIKAL DAMPER (continued)

Condition:

Thermostat closed, damper open.

Service Switch

Damper

Open

Damper

Auto

A1 IS CORRECT, CHECK SERVICE SWITCH

STEP 9B

IF THEN

Switch is incorrect position Replace damper board/motor assembly. Switch is not in correct position • Adjust switch

POSITION

• Cycle thermostat to verify that damper operation is correct.

29

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

TROUBLESHOOTING THE EFFIKAL DAMPER (continued)

Condition:

Thermostat closed, damper is open fully

STEP 10A TEST FOR 24VAC BETWEEN BLACK AND YELLOW

IF THEN

24VAC is present This is correct – continue to Step 11 24VAC is not present • See Step 9B.

• Check the harness plug connecting.

• Check that cam on shaft rotates with

shaft.

• Replace the damper board.

• Ensure that cam is secure against end

switch.

Condition: Damper rotates continuously

STEP 10B ADJUST END SWITCH TO CAM CONTACT

IF THEN

Damper stops in proper position 24 VAC should be open on a call for heat

and close during standby/

Damper does not stop in proper position • Replace damper assembly.

30

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 11 WIRE HARNESS TEST

STEP 11. WIRE HARNESS TEST. Test for 24 VAC between terminal 24V on the IID

module, and 24V GND.

IF THEN

24 VAC is not present: • Check the wiring harness. 24 VAC is present: • Go to step 12.

Note: This test may be easier to conduct by removing the red wire from the IID terminal. Test for 24

VAC between the red wire and ground. Reconnect the red wire to the 24V terminal after the test.

31

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 12 IID MODULE TEST

STEP 12. IID MODULE TEST (Power to the Pilot Valve). Using a multimeter, test for

24 VAC between terminal PV and 24V (GND) on the IID during the 90 second trial for ignition.

IF THEN

The meter does not read 24 VAC and the

• Replace the module.

IID module is not between ignition trials: The meter does read 24 VAC: • Go to step 13

32

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 13 PILOT SPARK TEST

STEP 13. PILOT SPARK TEST. Visually check for spark at the pilot assembly.

Note: The pilot burner mounts on the left side of the main burner.

IF THEN

The igniter is not sparking: Check for:

• A 7/64” spark gap

• Spark cable continuity

• Ground cable continuity

Sparking is present: • Go to step 14.

Power To Module May Be Interrupted To Reset .

Trial for Ignition

90 sec. 5 min. 90 sec. 5 min. 90 sec.

Call for heat

Sparking No

Sparking

Sparking No

Sparking

Continuous Trial Sequence

33

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 14A PILOT VALVE - OHM TEST

SBD 120 – 400 GAS VALVE

STEP 14A. PILOT VALVE - OHM TEST. If pilot assembly is sparking but no pilot flame is established, disconnect the pilot valve solenoid leads. Using a multimeter, (set to read ohms) test for 20* ohms resistance +/- 5 through the solenoid coil.

IF THEN

The meter dose not read 20 ohms plus or minus 5: The meter does read 20 ohms plus or minus 5:

• Replace gas valve

• Gas valve should work. Also check that

pilot gas is present and pilot tube or orifice are not blocked

34

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 14B PILOT VALVE TEST – SBD 500 ONLY

PILOT GAS

MANIFOLD

PRESSURE

TAP

BLUE

WHITE

RED

The MV/PV wire on the IID is connected to the white wire

The MV wire on the IID is connected to the red wire.

STEP 14B. PILOT VALVE TEST – SBD 500 ONLY. Testing the two coils of the Honeywell VR8404P 5004 gas valve used on the model SBD 500 only. Because of built in diodes, it is difficult to test for ohms resistance through these coils. The following is a DC amperage check of the main and pilot coils. Condition:

• Tank calls for heat

• PV terminal of module has 24 Vac

• No Pilot flame

Test Procedure:

• Turn off power to heater

• Meter set to test for DC amperage (on meters, the black wire is in the “com”

port, the red wire is in the “10A” port, the dial is set to 20M/10A in the DC AMP test area).

• Blue “PV” wire is disconnected from the ignition PV terminal.

• Install meter in series between gas valve and ignition module – 10A wire to blue

gas valve lead, common wire to PV module terminal.

• Turn power on to heater, after module receives 24V

Test DC Amperage through Pilot coil of gas valve

IF THEN

.75 to .85 DCA is not present: • Replace the gas valve .75 to .85 DCA is present • Pilot should work if gas (not air) is present to pilot Power off, reattach blue gas valve wire to PV terminal of module.

35

MANIFOLD

GAS

MANIFOLD

PRESSURE

TAP

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 15 MAIN BURNER TEST

STEP 15. MAIN BURNER TEST. Visually check for main burner.

IF THEN

The main burner ignites: • Sequence is complete The main burner does not ignite • Go to step 16

36

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 16 FLAME RECTIFICATION

STEP 16. FLAME RECTIFICATION

Note: Flame rectification means that an alternating current (AC) signal is changed to a direct current (DC) signal. The pilot flame is the 'switch' which connects the pilot hood to the igniter and ground. If the pilot hood and igniter sensor had the same surface area, the flame 'switch' would conduct an AC signal. Because the pilot surface is greater than the igniter surface, the signal becomes a DC current that the module can interpret. The pilot hood must be properly grounded and the pilot flame must remain in contact with both surfaces for the flame proving signal to remain constant. If the signal is broken for just 8 tenths of a second, the heater will cycle off. Sparking at the pilot will continue if an insufficient signal is received by the module.

Sparking at the pilot will stop almost immediately after the ignition module senses the pilot flame.

IF THEN

Sparking continues after pilot is established:

• Check wire connections

• Check flame contact between hood and

lighter

• Clean pilot burner surfaces

• Replace pilot assembly

Sparking stops: • Go to step 17.

37

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 17 IID MODULE TEST

Pilot is lit - Sparking has stopped. STEP 17. IID MODULE TEST (Power to the Main Valve). Using a multimeter, test for

24 VAC between terminal MV on the IID and 24V (GND).

IF THEN

24 VAC is not present: • Replace the IID module. Conduct Step

18 before applying power to replacement module.

24 VAC is present: • Go to step 18.

38

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 18A MAIN GAS VALVE CHECK

TH

TR

SBD 120 – 400 GAS VALVE

STEP 18A. MAIN GAS VALVE CHECK. Disconnect wires from gas valve TH and TR terminals. Using a multimeter, test for 68 ohms plus or minus 5 between TH and TR on the main valve coil.

IF THEN

The meter reads ‘O’ or infinity • Replace the gas valve The meter reads 68* ohms plus or minus 5 • The main burner will ignite

39

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

STEP 18B MAIN GAS VALVE COIL CHECK

MANIFOLD

PRESSURE

TAP

BLUE

WHITE

The PV wire is connected to the blue wire

The MV/PV wire on the IID is connected to the white wire.

RED

PILOT GAS

The MV wire is disconnected from the gas valve.

MANIFOLD

GAS

MANIFOLD

PRESSURE

TAP

STEP 18B. MAIN GAS VALVE COIL CHECK – SBD 500 ONLY

Condition:

• Pilot lights

• Sparking stops

• No main burner ignition

Test Procedure:

• Power off

• Disconnect red, main valve wire from module MV terminal

• Meter set to test for DC amperage

• 10A wire to red gas valve wire, COM wire to MV terminal of ignition module

• Turn power on to heater

• After pilot lights and sparking stops

IF: THEN:

.25 to .35 DC Amps is not present • Replace the gas valve .25 to .35DCA is present • Main burner gas should ignite.

Be certain to correct you meter wire connections and setting before performing further tests.

40

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

GENERAL SERVICE CHART

CONDITION CAUSE SOLUTION DAMPER OPENS NO POWER TO IID MODULE

PILOT LIGHTS, SPARKS CONTINUOUSLY

HEATER WILL NOT IGNITE

PILOT GAS NOT COMPLETELY

WEEPING TEMPERATURE AND PRESSURE RELIEF VALVE

. DAMPER NOT FULLY OPEN . DEFECTIVE PROTECTOR

SWITCH PILOT FLAME NOT PROVING SEE FLAME RECTIFICATION - STEP 16

NOT PROVING PILOT FLAME EXISTANCE

INTERRUPTED AT END OF HEATING CYCLE

. THERMAL EXPANSION ADD THERMAL EXPANSION TANK

. FAULTY VALVE REPLACE RELIEF VALVE

.EFFIKAL – REPLACE DAMPER CONTROL ASSEMBLY . REPLACE DAMPER

. REPLACE PC BOARD

INTERRUPT 120 VAC POWER . CHECK GROUND WIRE

ATTACHMENT . CLEAN OR REPLACE PILOT

ASSEMBLY . CHECK SUPPLY GAS PRESSURE

. REPLACE GAS VALVE

LARGE VOLUME WATER RELIEF FROM T&P VALVE

PREMATURE TANK LEAKAGE

CONTAMINATED AIR

WATER HAMMER

THERMAL EXPANSION

DEPLETED ANODES SCHEDULE ANODE CHECKS -

DAMPER WILL NOT OPEN BINDING SHAFT SUPPORT VENTING DAMPER MOTOR EFFIKAL-REPLACE DAMPER CONTROL

NO SPARK AT PILOT DAMPER FULLY OPEN

IID MODULE REPLACE IID STEP 12 SPARK CABLE REPLACE CABLE STEP 13

. EXCESSIVE WATER TEMPERATURE . FAULTY RELIEF VALVE REPLACE RELIEF VALVE

CONDENSATION . INCREASE STORED WATER

DAMPER ASSEMBLY SEE STEP 10A

. CHECK WIRING . REPLACE DUAL CONTROLLER

TEMPERATURE AND CONFIRM PROPERLY SIZED APPLICATION

. REMOVE CONTAMINANTS. . SUPPLY CLEAN COMBUSTION AIR. . ADD WATER HAMMER ARRESTOR. . REDUCE WATER PRESSURE. . REMOVE UNNECESSARY CHECK VALVES. ADD THERMAL EXPANSION TANK.

REPLACE AS NEEDED.

ASSEMBLY

Services Switch may bypass problem until replacement part is received. (EFFIKAL – REPLACE DAMPER CONTROL ASSEMBLY

41

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

GENERAL QUESTIONS AND ANSWERS

Q. What is unique about the Canadian – SBC-CGA – models vs. U.S. SBD models?

A. The Canadian models have different dimensions to meet Canadian code requirements.

Q: How much electrical power is required for a SBD water heater?

A: The SBD models draw approximately .7 Amps at 120VAC.

Q: The units require "leg kits" to meet National Sanitation Foundation standards.

Q: When should SBDs be delimed? NOTE: The “Hydrocannon” should eliminate or greatly

reduce the lime build up rate from the water heater.

Many variables affect the liming up process including:

water temperature - The amount of lime precipitation during the same period of time will be nearly 2 times greater if water is stored at 140 degrees F than at 120 degrees F. A 180 degree setting will precipitate lime about seven times as fast as a 140 degree F setting. volume of water - The more gallons flowing through the SBD, the more exposure to accumulation. hardness – The harder the water the higher the possibility of lime build up. 1 to 3.5 grains per gallon is "soft", 3.5 to 7 grains per gallon is "moderate", 7 to 10.5 grains per gallon is "hard" and 10.5 + grains per gallon is "very hard". (An aspirin is about 5 grains. One grain is equal to 17.1 parts per million.)

A: Deliming should be done when a slight rumbling or popping sound is detected when the

main burners are on.

Q: What effect will lime build-up have on the SBD water heater? A: One eighth inch of scale build-up may reduce efficiency as much as 22%; a 1/4 inch build-

up, as much as 38%.

A: Less efficient heat transfer means more bottom head expansion/contraction stress and

premature leakage.

A: Heavy build-up on the bottom head and bottom portion of the flue pipes leads to more heat

transfer at the top of the flues. This can lead to stacking or erratic thermostat operation.

A: The “Hydrocannon” greatly reduces the possibility of lime build-up.

Q: Anode rods provide additional protection against corrosion. When should these be

replaced?

A: When large gouges or pits appear in the anodes, replace them. It is recommended that

these be inspected every 6 months.

42

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD MODELS 120 THRU 500A

SERIES 110-111

EFFIKAL DAMPER DRIVE ASSEMBLY

PARTIAL REPLACEMENT

PARTS LIST

MODELS SBD 120 THRU 500A:

STANDARD AND ASME (A)

SERIES 110/111

HONEYWELL VALVE SBD 500A

GAS VALVES

WHITE RODGERS VALVE SBC 120 –400A

43

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD MODELS 120 THRU 500A (continued)

SERIES 110-111

44

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD MODELS 120 THRU 500A (continued)

SERIES 110-111

ITEM PARTS SBD71120NE SBD81154NE SBD81180NE SBD100199NET SBD100199NE

1 ..........Flue Baffle ................................. 193595.............. 192199-3........... 193795-1 .........193696 ..............193696

3 ..........Main Burner Orifice Bracket....... 98044(3) ........... 98044(3)............98044(5)..........98044(5)............98044(5)

4 ..........Main Burner ............................... 98047................ 98047 ................98047 .............. 98047 ................98047

5 ..........Main Burner w/Pilot Bracket....... 193873-1........... 193873-1 ........... 193873-1 .........193873-1 ...........193873-1

6 ..........Pilot Burner, Natural .................. 193314-4........... 193314-4 ........... 193314-4 .........193314-4 ...........193314-4

7 ..........Pilot Burner, LP ......................... 193314-3........... 193314-3........... 193314-3 .........193314-3 ...........193314-3

CLEANOUT ASSEMBLY

11 ...Gasket ....................................... 99038

12 ...Pressure Plate ........................... 99037................ 99037 ................99037 .............. 99037 ................99037

13 ...Screws, Self Tapping................. 69852................ 69852................ 69852 ..............69852 ................ 69852

17 ........Control, Ignition Module ............. 193325.............. 193325..............193325 ............193325 .............. 193325

18 ........Control, Dual w/ECO ................. 192828.............. 192828.............. 192828 ............ 192828 ..............192828

19 ........Cover, Cleanout......................... 181260.............. 181260.............. 181260 ............ 181260 ..............181260

22a ......Drafthood ................................... 193596.............. 193596-1........... 191790 ............191790 ..............191790

22b ......Damper Drive Assembly ............ 194484.............. 194484.............. 194484 ............ 194484 ..............194484

22c ......Harness Adapter........................ 194459.............. 194459..............194459 ............194459 ..............194459

LABELS

41 ........Manifold ..................................... 76244................ 76244 ................76244-2 ...........76244-2 .............76244-2

42 ........Instruction Manual ..................... 195121.............. 195121..............195121 ............195121 ..............195121

43 ........Main Burner Orifice, Natural…... 76243-32........... 76243-30 ........... 76243-35 .........76243-32 ...........76243-32

44 ........Main Burner Orifice, LP ............. 76243-49........... 76243-46 ........... 76243-51 .........76243-49 ...........76243-49

45 ........Anode Rod................................. 43817-38........... 43817-38........... 43817-38 .........43817-42 ...........43817-42

47 ........Transformer ............................... 193444.............. 193444 ..............193444 ............193444 ..............193444

48 ........Pilot Tubing................................ 1417-60............. 1417-60............. 1417-60 ...........1417-60 .............1417-60

49 ........Inlet Tube................................... 193729.............. 192626 ..............193729 ............ 192626 ..............192626

51 ........Gas Valve Natural...................... 192827.............. 192827 .............. 192827 ............ 192827 ..............192827

52 ........Gas Valve LP............................. 192827-1........... 192827-1 ........... 192827-1 .........192827-1 ...........192827-1

55 ........Switch Panel/Mounting Plate ..... 193448.............. 193448..............193448 ............ 193448 ..............193448

56 ........Off/On Switch ............................ 193243.............. 193243..............193243 ............ 193243 ..............193243

57 ........Bushing...................................... 193404.............. 193404 ..............193404 ............193404 ..............193404

58 ........Jumper Wire .............................. 193476.............. 193476..............193476 ............ 193476 ..............193476

59 ........Control Box Panel...................... 193447.............. 193447.............. 193447 ............ 193447 ..............193447

60 ........Cover - Burner ........................... 98185................ 98185................ 98185-2 ...........98185-2 .............98185-2

61 ........Hydro-Cannon ........................... 195100.............. 195100.............. 195098 ............195098 ..............195098

62 ........(1 1/2”) galvanized pipe cap ...... 193940.............. 193940 .............. 193940 ............ 193940 ..............193940

63 ........(1 1/2”) galvanized pipe plug...... 194623.............. 194623 ..............194623 ............194623 ..............194623

64 ........(1 1/2”) galvanized pipe union.... 194127.............. 194127 ..............194127 ............194127 ..............194127

Series 110-111

................ 99038 ................99038 .............. 99038 ................99038

45

SBD TANK TYPE HEATERS

/

SERVICE HANDBOOK

SBD MODELS 120 THRU 500A (continued)

SERIES 110-111

ITEM PARTS SBD81190NE SBD100199NES/A SBD100250NE/A SBD65251NE/A SBD100275NE

ITEM PARTS DESCRIPTION SBD81190NE SBD100199NES/A SBD100250NE/A SBD65251NE/A SBD100275NE/A

1 ..........Flue Baffle ................................... 193795-1 ....... 193889................193595 ................193595...........193945

3 ..........Main Burner Orifice Bracket......... 98044(5)........ 98044(5) .............098044(5) ............098044(7) ......098044(5)

4 ..........Main Burner ................................. 98047............ 98047.................. 98047 ..................98047.............98047

5 ..........Main Burner w/Pilot Bracket......... 193873-1 ....... 193873-1............. 193873-1 .............193873-1 .......193873-1

6 ..........Pilot Burner, Natural .................... 193314-4

7 ..........Pilot Burner, LP ........................... 193314-3....... 193314-3............. 193314-3 .............193314-3 .......193314-3

CLEANOUT ASSEMBLY

11 ...Gasket .........................................99038 ............ 99038.................. 99038 ..................99038.............99038

12 ...Pressure Plate ............................. 99037............ 99037.................. 99037 ..................99037.............99037

13 ...Screws, Self Tapping................... 69852 ............ 69852.................. 69852 ..................69852.............69852

17 ........Control, Ignition Module ............... 193325.......... 193325................ 193325 ................193325...........193325

18 ........Control, Dual w/ECO ................... 192828 .......... 192828................ 192828 ................192828...........192828

19 ........Cover, Cleanout........................... 181260 .......... 181260................ 181260 ................181260...........181260

22a ......Drafthood ..................................... 191790.......... 191790................ 193891 ................193891...........193891

22b ......Damper Drive Assembly .............. 194484 .......... 194484................194484 ................194484...........194484

22c ......Harness Adapter.......................... 194459.......... 194459................ 194459 ................194459...........194459

LABELS

41 ........Manifold ....................................... 76244-2......... 76244-2............... 76244-2 ...............76244-3 ......... 76244-2

42 ........Instruction Manual ....................... 195121 .......... 195121................ 195121 ................195121...........195121

43 ........Main Burner Orifice, Natural ........ 76243-32 ....... 76243-32............. 76243-30 .............76243-33 ....... 76243-29

44 ........Main Burner Orifice, LP ............... 76243-49 ....... 76243-48............. 76243-45 .............76243-51 .......76243-44

45 ........Anode Rod................................... 43817-38 ....... 180618-42........... 180618-42 ...........43817-38 .......180618-42

47 ........Transformer ................................. 193444.......... 193444................ 193444 ................193444...........193444

48 ........Pilot Tubing.................................. 193729.......... 1417-60...............1417-60 ...............1417-60 .........1417-60

49 ........Inlet Tube..................................... 193729.......... 193729................ 192626 ................ NA..............192626

51 ........Gas Valve Natural........................ 192827.......... 192827................ 192827 ................192827...........192827

52 ........Gas Valve LP............................... 192827-1 ....... 192827-1............. 192827-1 .............192827-1 .......192827-1

55 ........Switch Panel/Mounting Plate ....... 193448 .......... 193448................193448 ................193448...........193448

56 ........Off/On Switch .............................. 193243 .......... 193243 ................ 193243 ................193243...........193243

57 ........Bushing........................................ 193404.......... 193404................ 193404 ................193404...........193404

58 ........Jumper Wire ................................ 193476 .......... 193476................193476 ................193476...........193476

59 ........Control Box Panel........................ 193447 .......... 193447................ 193447 ................193447...........193447

60 ........Cover - Burner ............................. 98185-2......... 98185-2...............98185-2 ...............98185-3 .........98185-2

61 ........Hydro-Cannon ............................. 195100 .......... 195100................ 195098 ................195102...........195098

62 ........(1 1/2”) galvanized pipe cap ........ 193940.......... 193940................ 193940 ................ NA..............193940

63 ........(1 1/2”) galvanized pipe plug........ 194623.......... NA................... NA ...................194623........... NA

64 ........(1 1/2”) galvanized pipe union...... 194127.......... NA................... NA ...................194127........... NA

....... 193314-4.............193314-4 .............193314-4 .......193314-4

46

SBD TANK TYPE HEATERS

E

SERVICE HANDBOOK

SBD MODELS 120 THRU 500A (continued)

SERIES 110-111

ITEM PARTS DESCRIPTION SBD65305NE/A SBD85365NE/A SBD100400NE/A SBD85500N

1 ........... Flue Baffle........................................193595....................... 193696............................ 193995................193995

3 ........... Main Burner Orifice Bracket.............098044(7) .................. 098044(9)........................ 098044(9)

............. 098044(9)

4 ........... Main Burner .....................................192322....................... 98047.............................. 192322................192322

5 ........... Main Burner w/Pilot Bracket.............193873....................... 193873-1......................... 193873................ 193873

6 ........... Pilot Burner, Natural.........................193314-4 ................... 193314-4 ......................... 193314-4.............193314-

4

7 ........... Pilot Burner, LP................................193314-3 ................... 193314-3......................... 193314-3............. 193314-

3 CLEANOUT ASSEMBLY

11 .... Gasket .............................................99038......................... 99038.............................. 99038..................99038

12 .... Pressure Plate .................................99037......................... 99037.............................. 99037..................99037

13 .... Screws, Self Tapping.......................69852......................... 69852.............................. 69852.................. 69852

17 ......... Control, Ignition Module ...................193325....................... 193325............................ 193325................ 193325

18 ......... Control, Dual w/ECO........................192828....................... 192828............................ 192828................192828

19 ......... Cover, Cleanout...............................181260....................... 181260............................ 181260................181260

22a ....... Drafthood .........................................193891....................... 193891............................ 193891................ 193891

22b ....... Damper Drive Assembly ..................194484....................... 194484............................ 194484................194484

22c ....... Harness Adapter..............................194459....................... 194459............................ 194459................ 194459

LABELS

41 ......... Manifold ...........................................76244-3 ..................... 76244-4........................... 76244-4...............76244-4

42 ......... Instruction Manual............................195121....................... 195121............................ 195121................195121

43 ......... Main Burner Orifice, NAT……..........76243-37 ................... 76243-32......................... 76243-31.............76243-

28

44 ......... Main Burner Orifice, LP....................76243-48 ................... 76243-49......................... 76243-48............. 76243-

44

45 ......... Anode Rod.......................................43817-38 ................... 180618-42 ....................... 180618-42...........180618-

42

47 ......... Transformer .....................................193444....................... 193444 ............................ 193444 ................ 193444

48 ......... Pilot Tubing......................................1417-60 ..................... 1417-60........................... 1417-60...............1417-60

49 ......... Inlet Tube......................................... NA.......................... 192626............................ 192626................ 192626

51 ......... Gas Valve Natural............................192827-2

0

52 ......... Gas Valve LP...................................192827-3 ................... 192827-3 ......................... 192827-3.............193366-

1

55 ......... Switch Panel/Mounting Plate ...........193448....................... 193448............................ 193448................ 193448

56 ......... Off/On Switch...................................193243....................... 193243............................ 193243................193243

57 ......... Bushing............................................193404....................... 193404 ............................ 193404 ................ 193404

58 ......... Jumper Wire ....................................193476....................... 193476............................ 193476................193476

59 ......... Control Box Panel............................193447....................... 193447............................ 193447................193447

60 ......... Cover - Burner .................................98185-3 ..................... 98185-4........................... 98185-4...............194111

61 ......... Hydro-Cannon..................................195102....................... 195098............................ 195098................195098

62 ......... (1 1/2”) galvanized pipe cap............. NA.......................... 193940............................ 193940 ................ NA

63 ......... (1 1/2”) galvanized pipe plug............194623-3 ................... 194623-3......................... NA................... 194623-

3

64 ......... (1 1/2”) galvanized pipe union..........194127....................... 194127 ............................ NA ................... 194127

................... 192827-2......................... 192827-2............. 193366-

47

SBD TANK TYPE HEATERS

N

SERVICE HANDBOOK

SBD MODELS 120 THRU 500A (continued)

SERIES 110-111

CGA CGA CGA CGA CGA ITEM PARTS DESCRIPTION SBD71120NE SBD81154NE SBD76180NE SBD85199NE SBD76190

CGA CGA CGA CGA

1 ............. Flue Baffle......................................193595........... 192199-3 .......193795-0 ......... 193696 193795-0

3 ............. Main Burner Orifice Bracket...........98044(3) ........98044(3) ........ 98044(5) .......... 98044(5) 98044(5)

4 ............. Main Burner ...................................98047.............98047 ............ 98047 ..............98047 98047

5 ............. Main Burner w/Pilot Bracket...........193873-1 .......193873-1 .......193873-1 .........193873-1 193873-1

6 ............. Pilot Burner, Natural.......................193314-4

7 ............. Pilot Burner, LP..............................193314-3 .......193314-3 .......193314-3 .........193314-3 193314-3

CLEANOUT ASSEMBLY

11 ...... Gasket............................................99038.............99038 ............ 99038 ..............99038 99038

12 ...... Pressure Plate ...............................99037.............99037 ............ 99037 ..............99037 99037

13 ...... Screws, Self Tapping .....................69852............. 69852 ............69852 ..............69852 69852

17 ........... Control, Ignition Module .................193325...........193325 .......... 193325 ............193325 193325

18 ........... Control, Dual w/ECO......................192828........... 192828 .......... 192828 ............192828 192828

19 ........... Cover, Cleanout .............................181260........... 181260 .......... 181260 ............181260 181260

22a ......... Drafthood .......................................193596...........193596-1 .......193596-1 .........193596-1 193596-1

22b ......... Damper Drive Assembly ................194484...........194484 .......... 194484 ............194484 194484

22c ......... Harness Adapter ............................194459...........194459 ..........194459 ............194459 194459

LABELS

41 ........... Manifold .........................................76244-0 .........76244-0 .........76244-2 ...........76244-2 76244-2

42 ........... Instruction Manual..........................195121-1 .......195121-1 .......195121-1 ......... 195121-1 195121-1

43 ........... Main Burner Orifice, Natural...........76243-32 .......76243-30 .......76243-35 ......... 76243-32 76243-32

44 ........... Main Burner Orifice, LP..................76243-49 .......76243-46 .......76243-51 ......... 76243-49 76243-49

45 ........... Anode Rod .....................................43817-38 .......43817-38 .......43817-38 ......... 43817-42 43817-38

47 ........... Transformer ...................................193444...........193444 .......... 193444 ............193444 193444

48 ........... Pilot Tubing ....................................1417-60 .........1417-60 .........1417-60 ........... 1417-60 1417-60

49 ........... Inlet Tube.......................................193729...........192626 ..........193729 ............ 192626 193729

51 ........... Gas Valve Natural..........................192827...........192827 .......... 192827 ............192827 192827

52 ........... Gas Valve LP .................................192827-1 .......192827-1 ....... 192827-1 ......... 192827-1 192827-1

55 ........... Switch Panel/Mounting Plate..........193448...........193448 .......... 193448 ............193448 193448

56 ........... Off/On Switch.................................193243...........193243 .......... 193243 ............193243 193243

57 ........... Bushing..........................................193404...........193404 ..........193404 ............ 193404 193404

58 ........... Jumper Wire...................................193476...........193476 ..........193476 ............ 193476 193476

59 ........... Control Box Panel ..........................193447........... 193447 .......... 193447 ............193447 193447

60 ........... Cover - Burner ...............................98185.............98185 ............ 98185-2 ........... 98185-2 98185-2

61 ........... Hydro-Cannon................................195100........... 195100 ..........195098 ............195098 195098

62 ........... (1 1/2”) galvanized pipe cap...........193940...........193940 .......... 193940 ............193940 193940

63 ........... (1 1/2”) galvanized pipe plug..........194623...........194623 ..........194623 ............194623 194623

64 ........... (1 1/2”) galvanized pipe union........194127...........194127 ..........194127 ............ 194127 194127

.......193314-4 .......193314-4 ......... 193314-4 193314-4

48

SBD TANK TYPE HEATERS

E

SERVICE HANDBOOK

SBD MODELS 120 THRU 500A (continued)

SERIES 110-111

CGA CGA CGA CGA CGA ITEM PARTS DESCRIPTION SBD100199NES/A SBD100250NE/A SBD65251NE/A SBD100275NE/A SBD65305N

1 ............ Flue Baffle.....................................193889 ............193595 ..............193595.............. 193945.........193595

3 ............ Main Burner Orifice Bracket.......... 98044(5) .......... 98044(5) ............98044(7) ........... 98044(5) ......98044(7)

4 ............ Main Burner ................................. 98047 ..............98047 ................98047................ 98047...........192322

5 ............ Main Burner w/Pilot Bracket..........193873-1 .........193873-1 ...........193873-1 .......... 193873-1......193873

6 ............ Pilot Burner, Natural......................193314-4 .........193314-4 ...........193314-4 .......... 193314-4 ......193314-4

7 ............ Pilot Burner, LP.............................193314-3 .........193314-3 ...........193314-3 .......... 193314-3......193314-3

CLEANOUT ASSEMBLY

11 ..... Gasket ..........................................99038 ..............99038 ................99038................ 99038...........99038

12 ..... Pressure Plate .............................. 99037 ..............99037 ................99037................ 99037...........99037

13 ..... Screws, Self Tapping....................69852 ..............69852 ................69852................ 69852...........69852

17 .......... Control, Ignition Module ................193325 ............193325 ..............193325.............. 193325.........193325

18 .......... Control, Dual w/ECO.....................192828 ............192828 ..............192828.............. 192828.........192828

19 .......... Cover, Cleanout............................181260 ............181260 ..............181260.............. 181260.........181260

22a ........ Drafthood ......................................191790 ............193891 ..............193891.............. 193891......... 193891

22b ........ Damper Drive Assembly ...............194484 ............194484 ..............194484.............. 194484.........194484

22c ........ Harness Adapter ...........................194459 ............194459 ..............194459.............. 194459.........194459

LABELS

41 .......... Manifold ........................................ 76244 ..............76244 ................76244-2 ............ 76244-2........76244-2

42 .......... Instruction Manual.........................195121-1 .........195121-1 ...........195121-1 .......... 195121-1......195121-1

43 .......... Main Burner Orifice, Natural..........76243-32 .........76243-30 ...........76243-35 .......... 76243-32......76243-32

44 .......... Main Burner Orifice, LP.................76243-48 .........76243-46 ...........76243-51 .......... 76243-49......76243-49

45 .......... Anode Rod....................................180618-42 .......43817-38 ...........43817-38 .......... 43817-42 ......43817-38

47 .......... Transformer .................................. 193444 ............193444 ..............193444.............. 193444......... 193444

48 .......... Pilot Tubing................................... 1417-60 ...........1417-60 .............1417-60 ............ 1417-60........1417-60

49 .......... Inlet Tube...................................... 193729 ............192626 ..............193729.............. 192626.........193729

51 .......... Gas Valve Natural.........................192827 ............192827 ..............192827.............. 192827.........192827

52 .......... Gas Valve LP................................192827-1 .........192827-1 ...........192827-1 .......... 192827-1 ......192827-1

55 .......... Switch Panel/Mounting Plate ........193448 ............193448 ..............193448.............. 193448.........193448

56 .......... Off/On Switch................................193243 ............193243 ..............193243.............. 193243.........193243

57 .......... Bushing.........................................193404 ............193404 ..............193404.............. 193404.........193404

58 .......... Jumper Wire..................................193476 ............193476 ..............193476.............. 193476.........193476

59 .......... Control Box Panel.........................193447 ............193447 ..............193447.............. 193447.........193447

60 .......... Cover - Burner ..............................98185-2 ...........98185-2 .............98185-2 ............ 98185-2........98185-2

61 .......... Hydro-Cannon...............................195100 ............195198 ..............195102.............. 195098.........195102

62 .......... (1 1/2”) galvanized pipe cap..........193940 ............193940 .............. NA................. 193940......... NA

63 .......... (1 1/2”) galvanized pipe plug......... NA ............... NA .................194623-3 .......... NA ............194623-3

64 .......... (1 1/2”) galvanized pipe union....... NA ............... NA .................194127.............. NA............194127

49

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD MODELS 120 THRU 500A (continued)

SERIES 110-111

CGA CGA CGA ITEM PARTS DESCRIPTION SBD85365NE/A SBD100400NE/A SBD85500NE/A

1 ............ Flue Baffle................................................... 193945 ........................193995......................... 193995

3 ............ Main Burner Orifice Bracket........................ 098044(9)....................098044(9) .................... 098044(9)

4 ............ Main Burner ...............................................98047 ..........................192322......................... 98047

5 ............ Main Burner w/Pilot Bracket........................ 193873-1 .....................193873-1 ..................... 193873-1

6 ............ Pilot Burner, Natural....................................193314-4 .....................193314-4 ..................... 193314-4

7 ............ Pilot Burner, LP........................................... 193314-3 .....................193314-3 ..................... 193314-3

CLEANOUT ASSEMBLY

11 ..... Gasket ........................................................99038 ..........................99038........................... 99038

12 ..... Pressure Plate ............................................ 99037 ..........................99037........................... 99037

13 ..... Screws, Self Tapping ..................................69852 ..........................69852........................... 69852

17 .......... Control, Ignition Module .............................. 193325 ........................193325......................... 193325

18 .......... Control, Dual w/ECO................................... 192828 ........................192828......................... 192828

19 .......... Cover, Cleanout.......................................... 181260 ........................181260......................... 181260

22a ........ Drafthood .................................................... 193891 ........................193891......................... 193891

22b ........ Damper Drive Assembly .............................194484 ........................194484......................... 194484

22c ........ Harness Adapter .........................................194459 ........................194459......................... 194459

LABELS

41 .......... Manifold ...................................................... 76244-4.......................76244-4 ....................... 76244-4

42 .......... Instruction Manual....................................... 194027 ........................194027......................... 194027

43 .......... Main Burner Orifice, Natural........................76243-32 .....................76243-31 ..................... 76243-29

44 .......... Main Burner Orifice, LP............................... 76243-49 .....................76243-48 .....................76243-44

45 .......... Anode Rod..................................................180618-42 ...................180618-42 ................... 180618-42

47 .......... Transformer ................................................ 193444 ........................193444......................... 193444

48 .......... Pilot Tubing.................................................1417-60 .......................1417-60 ....................... 1417-60

49 .......... Inlet Tube.................................................... 192626 ........................192626......................... 192626

51 .......... Gas Valve Natural....................................... 192827-2 .....................192827-2 ..................... 193366

52 .......... Gas Valve LP..............................................192827-3

55 .......... Switch Panel/Mounting Plate ......................193448 ........................193448......................... 193448

56 .......... Off/On Switch.............................................. 193243 ........................193243......................... 193243

57 .......... Bushing....................................................... 193404 ........................193404......................... 193404

58 .......... Jumper Wire................................................193476 ........................193476......................... 193476

59 .......... Control Box Panel....................................... 193447 ........................193447......................... 193447

......... Cover - Burner...................................... 98185-2 ...................98185-2 .................... 98185-2

60

61 .......... Hydro-Cannon............................................. 195102 ........................105098......................... 195098

62 .......... (1 1/2”) galvanized pipe cap........................ 193940 ........................193940......................... NA

63 .......... (1 1/2”) galvanized pipe plug....................... 194623 ........................ NA ........................... 194623

64 .......... (1 1/2”) galvanized pipe union..................... 194127 ........................ NA ........................... 194127

.....................192827-3 ..................... 193366-1

50

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

COMPONENT PART INFORMATION

DUAL

CONTROLLER THERMOST

HIGH LIMIT

GAS VALVE NATURAL

PROPANE

INTERMITENT

IGNITION

DEVICE

CONTROL

DAMPER COMPLETE

MOTOR 24 VAC, 60 HZ, 120 RPM, 5

P.C. BOARD

TRANSFORMER 120 V PRIMARY, 24 VAC

NAME SPECIFICATIONS STATE PART

120-180O RANGE, + 4O, 5O

DIFFERENTIAL,

AT

LIQUID FILLED, ANTI-

STACKING

OPENS - 205O FIXED, MANUAL

(ECO)

RESET BELOW 185O

SBD 120-400;24VAC, 60hz,

GAS

.6A,.7” to 3.5” W.C.,

STEP OPEN

SBD 500; 24VAC, 60hz, Dual

Gas Valve,

STEP OPEN

SBD 120-400;

GAS

2.5 – 10” W.C. STEP OPEN

SBD 500; 24VAC, 60hz, Dual

Gas Valve,

STEP OPEN

NATURAL

GAS AND

PROPANE

24 VAC, 50-60 HZ, .1A;

.7 MICROAMP SIGNAL

CONTINUOUS RETRIAL

GAS

ASSEMBLY

WATT

(NOT 110, 111 SERIES)

Service Switch

W/RELAY

(NOT 110, 111 SERIES)

SECONDARY,

40 VA, 50-60 HZ, CLASS 2 "B"

NUMBERS

# 192828

# 192827-2

# 193366-0

# 192827-3

# 193366-1

193325

SEE PARTS LIST

#6521

#6522

#193444

51

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

SBD SERVICE CHECKLIST

(This service checklist may be photo copied to assist with SBD service call.)

This checklist is intended to aid the Service Agent in determining that the State SBD Water Heater has been properly installed and is operating correctly. Because the circumstances of each installation may vary greatly, it is not intended to be an allinclusive list of the problems that the Service Agent may encounter. Any item checked "no" on this list should be thoroughly investigated and corrective action taken, if required.

SERVICE AGENT INSTALLATION DATE MODEL NUMBER SERVICE DATE SERIAL NUMBER LOCATION ADDRESS

GAS TYPE - CHECK ONE NATURAL PHONE( ) ___ - ____

PROPANE

I. Check Clearances (circle answer) A. Are exterior clearances adequate? yes no B. Are interior clearances adequate? yes no

Comments: II. Check Makeup Air Requirements

A. Is the quantity of make-up air adequate per the National Fuel Gas Code? yes no Comments: B. Is the quality of make-up air adequate? yes no Comments: III. Gas Pressure (fill in blank)

A. Supply gas pressure B. Manifold gas pressure (main burner)

Comments: IV. Venting (check)

A. Properly sized per the National Fuel Gas Code? yes no B. Does the installation have mechanically assisted venting? yes no

If so, is it operational? yes no Comments:

inches of W.C.

52

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

V. WATER PIPING Is the system properly sized? yes no Is the system properly installed? yes no Are there any water leaks? yes no Does the installation have a recirculating system? yes no If so, is it operational? yes no

VI. PROPER SEQUENCE OF OPERATION During standby does damper close on standby? yes no During standby is pilot flame off? yes no On a call for heat does thermostat close? yes no On a call for heat does damper open completely? yes no Does sparking begin at pilot? yes no Is pilot flame established? yes no If so, does sparking stop? yes no Does main burner ignite? yes no Does the thermostat satisfy? yes no Does damper close? yes no

Comments: VII. SAFETY

A. Gas Does pilot flame prove before main burner ignites? yes no Does damper blade fully open before ignition sequence occurs? yes no Is burner cover plate in place? yes no Is burner floor shield in place? yes no Does IID lockout occur after 30 sec. trial for ignition? (Propane models only) yes no

B. Water Temperature Is the thermostat adjusted to the lowest acceptable temperature? yes no Does the installation have a mixing valve? yes no If so, is it operational? yes no What is the outlet temperature of the mixing valve? Is a properly rated temperature and pressure relief valve installed? yes no

C. Electrical Is the 120 VAC electrical power supply properly wired? yes no Are all the SBD control covers in place? yes no Is the 120 VAC electrical power supply properly fused? yes no

D. Flammables Are flammable materials located in the area of the water heater? yes no Are flammable vapors located in the area of the water heater? yes no

(This service checklist may be photo copied to assist with SBD service call.)

53

Author: Terry Mulder

SBD TANK TYPE HEATERS

SERVICE HANDBOOK

COMMENTS

54

COMMERCIAL

The Expert’s Choice®

Prepared by the State Water Heaters Training Department.

For additional technical information call 800-365-0577.

State Water Heaters

500 Tennessee Waltz Parkway Ashland City, TN 37015 800-365-8170 www.statewaterheaters.com

State Industries SBD71 120, SBD85 500 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
