5m Coax High Resolution Monitor VGA Video Cable
- HD15 to HD15 M/M
Product ID: MXTMMHQ5M
The MXTMMHQ5M High Resolution VGA Cable (5-meter) is designed to provide the highest video quality
possible through VGA, ideally suited for high resolution applications of 1920x1200 and above.
This durably constructed coaxial VGA video cable (HD15 to HD15) eliminates the picture "ghosting" and
fuzzy images that are inherent to non-coaxial VGA cables, while delivering superior EMI interference
protection by using ferrite cores near the connector ends.
www.startech.com/uk
0800 169 0408
Certifications, Reports
and Compatibility
Applications
• Replace a worn-out or missing VGA monitor cable with this high
quality, coax VGA cable
• Supports high resolution VGA monitors (1920x1200)
• Create a longer connection between a high resolution VGA display
and a desktop PC/video switch than a typical cable length would
allow
Features
• Triple coaxial + twisted-pair wire for crystal clear display
• Durably constructed cable, with high quality HD15 connectors
• Impedance matched at 75 Ohms for full brightness and vibrant
picture color from your VGA monitor
• High quality VGA connectors with molded PVC strain relief
www.startech.com/uk
0800 169 0408
Warranty Lifetime
Hardware Cable Jacket Type PVC - Polyvinyl Chloride
Cable Shield Type Aluminum-Mylar Foil with Braid
Connector Plating Nickel
Fire Rating CMG Rated (General Purpose)
Number of Conductors 14
Number of Ferrites 1
Connector(s) Connector A 1 - VGA (15 pin, High Density D-Sub) Male
Connector B 1 - VGA (15 pin, High Density D-Sub) Male
Environmental Humidity 0 - 80 %RH
Operating Temperature 0 to 60 °C
Storage Temperature -20 to 80 °C
Physical
Characteristics
Cable Length 5 m [16.4 ft]
Color Black
Product Length 5 m [16.4 ft]
Product Weight 0.6 kg [1.2 lb]
Wire Gauge 28 AWG
Packaging
Information
Package Quantity 1
Shipping (Package) Weight 0.6 kg [1.2 lb]
What's in the Box Included in Package 1 - 5m Coax High Resolution Monitor VGA Cable - HD15 M/M
Product appearance and specifications are subject to change without notice.
