Manual Revision: 12/10/2018
User Manual
For the latest information and specications visit
www.startech.com/RKCONS1901
1U 19” Rackmount LCD Console | USB
Actual product may vary from photos
SKU#: RKCONS1901
1
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Compliance Statements
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du
Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any
interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil
doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
2
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Use of Trademarks, Registered Trademarks, and other
Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and
other protected names and/or symbols of third-party companies not related in
any way to StarTech.com. Where they occur these references are for illustrative
purposes only and do not represent an endorsement of a product or service
by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com
hereby acknowledges that all trademarks, registered trademarks, service marks,
and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.
3
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Safety Statements
Safety Measures
• Wiring terminations should not be made with the product and/or electric
lines under power.
• Product installation and/or mounting should be completed by a certied
professional as per the local safety and building code guidelines.
• Cables (including power and charging cables) should be placed and routed
to avoid creating electric, tripping or safety hazards.
Mesures de sécurité
• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit
et/ou les câbles électriques sont sous tension.
• L’installation et/ou le montage du produit doit être réalisé par un
professionnel certié et dans le respect des normes locales et du code de
construction local.
• Les câbles (y compris les câbles d’alimentation et de chargement) doivent
être placés et acheminés de façon à éviter tout risque électrique, de chute ou
de sécurité
安全対策
• 電源が入っている状態の製品または電線の終端処理を行わないでくださ
い。
• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に
従い、有資格の専門業者が行うようにしてください。
• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し
を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう
にしてください。
Misure di sicurezza
• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le
linee elettriche sotto tensione.
• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un
tecnico professionale certicato che conosca le linee guida locali sulle norme
edilizie e sulla sicurezza.
• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati
e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o
pericoli per la sicurezza.
4
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Säkerhetsåtgärder
• Montering av kabelavslutningar får inte göras när produkten och/eller
elledningarna är strömförda.
• Installation och/eller montering får endast göras av behöriga yrkespersoner
och enligt gällande lokala förordningar för säkerhet och byggnormer.
• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så
sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.
Warning Statements
• Make sure to assemble this product according to the instructions. Failure to
do so might result in personal injury or property damage.
• Never use this product if parts are missing or damaged.
5
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Table of Contents
Compliance Statements ........................................................................1
Safety Statements ..................................................................................3
Warning Statements ..............................................................................4
Product Diagram (RKCONS1901) .........................................................7
Front ............................................................................................................................................................... 7
Rear ................................................................................................................................................................ 8
Product Information ..............................................................................9
Packaging Contents .................................................................................................................................9
Hardware Kit Contents ............................................................................................................................ 9
Requirements ............................................................................................................................................. 9
Installation ..............................................................................................10
Mounting the Rack Console Drawer .................................................................................................. 10
Grounding the LCD Console ................................................................................................................. 11
Connecting the LCD Console ................................................................................................................11
Opening the LCD Console ......................................................................................................................12
Closing the LCD Console ........................................................................................................................13
Panel Controls and On-Screen Display (OSD) Functions .................14
LCD Console Panel Menu ....................................................................................................................... 14
Auto Tuning the Display .........................................................................................................................14
Adjusting the Display’s Brightness ..................................................................................................... 15
Adjusting the Display’s Contrast ..........................................................................................................16
Adjusting the Display’s Color Settings .............................................................................................. 16
6
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Adjusting the Image or OSD Position ................................................................................................ 17
Adjusting the Language ......................................................................................................................... 17
Resetting the LCD Console to Factory Settings.............................................................................. 18
Exiting the OSD .......................................................................................................................................... 18
LED Indicator ..........................................................................................19
Conguration ..........................................................................................19
Testing the LCD Console ......................................................................................................................... 19
Conguring Display Settings ................................................................................................................ 20
Specications .......................................................................................... 20
Important Considerations ....................................................................21
7
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Diagram (RKCONS1901)
Front
Handle
Release
Switch
Display
Console
Panel
Mounting
Brackets
(2)
Rails (2)
Keyboard
Touchpad
8
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Rear
Power
Connection
Port
Power
Switch
Ground
Connection
Screw
Host
Port
9
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Product Information
Packaging Contents
• 1U LCD Rack Console Drawer x 1
• Console Cable Kit x 1
• Mounting Rails - Set x 1
• Power Adapter x 1
Hardware Kit Contents
• Side Rails with Brackets x 2
• Keys x 2
• Screw Kit x 1
Requirements
Requirements are subject to change. For the latest
requirements, please visit www.startech.com/RKCONS1901.
• 1U of Rack Space
• Grounding Wire
• Power Source
• Computer, Server, or KVM
• Phillips Head Screwdriver
10
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Installation
Mounting the Rack Console Drawer
Note: It’s easier to install the Rack Console Drawer if an-
other person helps you with the installation.
Warning: Use caution and proper lifting techniques when
installing the Rack Console Drawer.
1. Based on the mounting depth of the server rack that you are
using, select the appropriate length of Mounting Rails.
2. Decide where in the Rack you want to install the Rack
Console Drawer.
3. Insert the M5 Cage Nuts (two per mounting post) into the
square mounting holes on the Rack’s mounting posts.
4. Align the Rear Mounting Brackets (rails) with the M5 Cage
Nuts on the corresponding Rack mounting post.
5. Insert an M5 Screw (two per mounting post) through the
Rear Mounting Bracket (rail) and into the M5 Cage Nut. Do
not tighten the M5 Screws.
6. With assistance, slide the Rack Console Drawer into the
Rack, guiding the Rear Mounting Brackets (rails) into the
rail assembly.
7. Insert an M5 Screw (two per mounting post) through the
Front Mounting Bracket (rail) into the M5 Cage Nut.
8. Use a Phillips Head Screwdriver to tighten the M5 Screws.
11
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Grounding the LCD Console
Note: Grounding is recommended in environments with
high levels of electromagnetic interference (EMI), or frequent
electrical surges.
1. Using a Phillips Head Screwdriver, loosen the Grounding
Connection Screw.
2. Attach the Grounding Wire to the shaft of the Grounding
Connection Screw.
3. Tighten the Grounding Connection Screw, making sure not
to over-tighten.
4. Attach the other end of the Grounding Wire (not connected
to the LCD Console) to a proper earth-ground connection.
Connecting the LCD Console
To connect the LCD Console to a Computer or KVM, perform
the following steps:
1. Turn o the Computer or KVM Switch.
2. Connect the 15-pin Host/KVM Connector on the KVM
Cable to the Host Port on the LCD Console and to a VGA
port and USB port on the rear panel of the Computer or
KVM Switch.
3. Connect the Power Cable to the Power Connection Port on
the LCD Console and to an AC Electrical Outlet.
4. Power on the LCD Console.
5. Power the Computer or KVM back on.
12
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Opening the LCD Console
1. Move the Release Switch to the unlocked position.
Unlocking the LCD Console
2. Use the Handle to pull the LCD Console out of the Rack
until you hear the LCD Console click into place. The LCD
Console will power On.
3. The LED Indicator on the left of the monitor panel changes
from orange to green.
4. Adjust the Display into the desired position.
Closing the LCD Console
1. Lower the Display until it’s ush against the Keyboard.
2. Slide and hold the two Switches located on the sides of the
LCD Console forward and push the LCD Console in towards
the rear of the rack.
3. Release the two Switches and continue pushing the LCD
Console the rest of the way into the Rack, until you hear an
audible click.
13
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Panel Controls and On-Screen
Display (OSD) Functions
Console Panel Menu
The Console Panel buttons are for display adjustments and
OSD navigation:
Button Function
Auto/Exit
Auto-synchronizes and scales down the
display to any valid factory preset timings.
Exits the OSD.
SL-
Press to scroll to the function you want to
adjust.
SL+
Press to scroll to the function you want to
adjust.
Menu/
Select
Opens the OSD menu.
Used to select an option on the OSD.
Auto Tuning the Display
The Auto button automatically adjusts the display size and
tunes the Display to its optimal state.
1. On the Console Panel, press the Auto/Exit button.
- or -
2. On the Console Panel, press the Menu/Select button.
14
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
3. On the OSD, use the SL- down and SL+ up (on the Console
Panel) buttons to select Auto.
4. Press the Menu/Select button.
Adjusting the Display’s Brightness
1. On the Console Panel, press the Menu/Select button.
2. On the OSD, use the SL- down and SL+ up (on the Console
Panel) buttons to highlight Menu, then press the Menu/
Select button.
3. On the Menu list select Brightness and press the Menu/
Select button.
4. Use the SL- down and SL+ up (on the Console Panel)
buttons to adjust the brightness on the display.
5. Press the Menu/Select button to save your selection.
15
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Adjusting the Display’s Contrast
1. On the Console Panel, press the Menu/Select button.
2. On the OSD, use the SL- down and SL+ up (on the Console
Panel) buttons to highlight Menu, then press the Menu/
Select button.
3. On the Menu list select Contrast, then press the Menu/
Select button.
4. Use the SL- down and SL+ up (on the Console Panel)
buttons to adjust the contrast on the display.
5. Press the Menu/Select button to save your selection.
Adjusting the Display’s Color Settings
1. On the Console Panel, press the Menu/Select button.
2. On the OSD, use the SL- down and SL+ up (on the Console
Panel) buttons to higlight Menu, then press the Menu/
Select button.
3. On the Menu list select Color, then press the Menu/Select
button.
4. Select one of the following Color options:
• 9300°K: Sets CIE coordinates at 9300°K color.
• 7500°K: Sets CIE coordinates at 7500°K color.
• 6500°K: Sets CIE coordinates at 6500°K color.
• User: Sets user dened CIE.
• Auto Color: Auto adjusts color.
16
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
• Return: Returns to the OSD Menu without making any
changes.
5. Press the Menu/Select button to save your selection.
Adjusting the Image or OSD Position
1. On the Console Panel, press the Menu/Select button.
2. On the OSD, use the SL- down and SL+ up on the Console
Panel to highlight Menu, then press the Menu/Select
button.
3. On the Menu list select Position, then press the Menu/
Select button on the Console Panel.
4. Select one of the following Color options:
• Image Pos: Adjusts the position of the image.
• OSD Pos: Adjusts the position of the OSD.
• Return: Returns to the OSD Menu without making any
changes.
5. Press the Menu/Select button on the Console Panel to save
your selection.
Adjusting the Language
1. On the LCD Console Panel, press the Menu/Select button.
2. On the OSD, use the SL- down and SL+ up on the Control
Panel to highlight Menu, then press the Menu/Select
button.
3. On the Menu list select Language, then press the Menu/
Select button on the Console Panel.
17
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
4. Use the SL- down and SL+ up (on the Console Panel)
buttons to select a language.
5. Press the Menu/Select button on the Console Panel to save
your selection.
Resetting the LCD Console to Factory Settings
1. On the Console Panel, press the Menu/Select button.
2. On the OSD, use the SL- down and SL+ up on the Console
Panel to highlight Menu, then press the Menu/Select
button.
3. On the Menu list select Misc and press the Menu/Select
button on the Console Panel.
4. Select one of the following recall options:
• Yes: Reset.
• No: Returns to the OSD Menu without resetting.
Exiting the OSD
• To exit the menu, scroll to Exit, then press the Menu/Select
button.
18
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
LED Indicator
LED Indicator Status
Power LED Green: On
Red: Standby, Suspend,
or O
Conguration
Testing the LCD Console
To test that the LCD Console is working properly, perform the
following steps:
1. Power up the Rack Console, and then turn on the
Computer.
2. Make sure that the video image is centered on the screen. If
the image is not centered, use the OSD controls to adjust the
image (see Panel Controls and OSD Functions) or press the
Auto button on the Console Panel.
Note: If the unit does not power up when the Display is
pulled up, try pushing the Power button on the Console
Panel.
19
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Conguring Display Settings
When the LCD Console is rst connected you may need to
congure one or more display settings. Use the Computer’s
operating system to congure the following display settings:
• Display mode: also called desktop area or video resolution
• Refresh rate: also called vertical scan rate or vertical sync
• Color depth: also called color palette or number of colors
Specications
Specication Description
Panel Type Active Matrix TFT LCD
Max. Resolution 1280 x 1024
Supported Colors 16M Colors (6-bit with
FRC)
Response Time Rising Time: 8ms
Decay Time: 8ms
System Cables VGA + USB
Keyboard 99-key
Mouse Touchpad
Sync 50 - 75KHz
Power Source 100 - 240 VAC Input
20
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Operating Temperature Celsius: 0 ° - 50 °
Fahrenheit: 32 ° - 122 °
Storage Temperature Celsius: -20 ° - 60 °
Fahrenheit: -4 ° - 140 °
Humidity 10% - 90% RH
Dimensions 447.5 x 482 x 44 mm
Important Considerations
• If you’re installing the device in a closed or multi-unit
rack assembly, ensure that the environmental conditions
are within the LCD Console’s maximum and minimum
specications.
• Installing the LCD Console in a rack or cabinet may reduce
airow. Consider your airow requirement when selecting a
location for installation.
• It’s recommended that the LCD Console be connected to a
power source with over-current protection and supply wiring.
Appropriate consideration of equipment nameplate ratings
should be used when addressing this concern.
• The LCD Console should be grounded appropriately during
installation.
21
Warranty Information
This product is backed by a two-year warranty.
For further information on product warranty terms and conditions, please refer
to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or
their ocers, directors, employees or agents) for any damages (whether direct
or indirect, special, punitive, incidental, consequential, or otherwise), loss of
prots, loss of business, or any pecuniary loss, arising out of or related to the use
of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or
consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
21
Hard-to-nd made easy. At StarTech.com, that isn’t a slogan.
It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need.
From the latest technology to legacy products — and all the parts that bridge
the old and new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they
need to go. Just talk to one of our tech advisors or visit our website. You’ll be
connected to the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products
and to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and
technology parts. StarTech.com was founded in 1985 and has operations in the
United States, Canada, the United Kingdom and Taiwan servicing a worldwide
market.
Reviews
Share your experiences using StarTech.com products, including product
applications and setup, what you love about the products, and areas for
improvement.
StarTech.com Ltd.
45 Artisans Cres.
London, Ontario
N5V 5E9
Canada
StarTech.com LLP
2500 Creekside Pkwy.
Lockbourne, Ohio
43137
U.S.A.
StarTech.com Ltd.
Unit B, Pinnacle
15 Gowerton Rd.,
Brackmills
Northampton
NN4 7BW
United Kingdom
FR: fr.startech.com
DE: de.startech.com
ES: es.startech.com
NL: nl.startech.com
IT: it.startech.com
JP: jp.startech.com
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Loading...
