StarTech.com POEINJ2GI User Manual

Industrial 2 Port Gigabit PoE+ Injector 48V / 30W - Wall-Mountable
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 11/29/2013
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the equipment.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.
Instruction Manual
Table of Contents
Introduction ............................................................................................2
Packaging Contents ................................................................................................................................. 2
System Requirements .............................................................................................................................. 2
Product Overview ..................................................................................2
Terminal Block Power Connector ........................................................................................................ 3
LED Indicators............................................................................................................................................. 3
Pinout ............................................................................................................................................................ 4
Din Rail / Wall Bracket Installation .......................................................................................................6
Hardware Installation .............................................................................................................................. 6
Specications ..........................................................................................7
Technical Support .................................................................................. 8
Warranty Information ............................................................................8
Instruction Manual
1

Introduction

Packaging Contents

• 1 x 2 Port PoE Injector
• 1 x DIN Rail Bracket w/ Screws
• 2 x Wall Mount Brackets w/ Screws
• 1 x 4-Pin Terminal Block
• 2 x Dust Covers (RJ-45)
• 1 x Power Cable w/ Female DC Jack
• 1 x Instruction Manual

System Requirements

• RJ45 terminated Cat5 or higher Ethernet cabling
• 10/100/1000 Mbps compatible Ethernet network
• 50-57 V DC Power Supply

Product Overview

Terminal Block
Power LED
Gigabit Data Port
Instruction Manual
Gigabit PoE Port
PoE LEDs
2

Terminal Block Power Connector

LED Indicators

PWR (Green) Solid: Power is connected and functioning
Solid: PoE device detected
PoE LED x 2 (Blue)
Flashing: Detecting PoE device
O: No PoE device detected
Instruction Manual
3

Pinout

1000Base-T
RJ-45 Input (Data Only) RJ-45 Output (Data and Power)
Symbol Description Symbol Description
1 BI_DA+ Data BI_DA+ BI_DA+ (Vdc+) Data BI_DA+ and
2 BI_DA- Data BI_DA- BI_DA- (Vdc+) Data BI_DA- and
3 BI_DB+ Data BI_DB+ BI_DB+ (Vdc-) Data BI_DB+ and
4 BI_DC+ Data BI_DC+ BI_DC+ Data BI_DC+
5 BI_DC- Data BI_DC- BI_DC- Data BI_DC-
6 BI_DB- Data BI_DB- BI_DB- (Vdc-) Data BI_DB- and
7 BI_DD+ Data BI_DD+ BI_DD+ Data BI_DD+
8 BI_DD- Data BI_DD- BI_DD- Data BI_DD-
Feeding power (+)
Feeding power (+)
Feeding power (-)
Feeding power (-)
Instruction Manual
4
10/100Base-TX
RJ-45 Input (Data Only) RJ-45 Output (Data and Power)
Symbol Description Symbol Description
1 Rx+ Data Receive Rx+ (Vdc+) Data Receive and
Feeding power (+)
2 Rx- Data Receive Rx- ( Vdc+) Data Receive and
Feeding power (+)
3 Tx+ Data Transmit Tx+ (Vdc-) Data Transmit and
Feeding power (-)
4 NC Not connected NC Not connected
5 NC Not connected NC Not connected
6 Tx- Data Transmit Tx- (Vdc-) Data Transmit and
Feeding power (-)
7 NC Not connected NC Not connected
8 NC Not connected NC Not connected
Note: pins 3 and 6 (-Vdc) should not be shorted to ground
Instruction Manual
5

Din Rail / Wall Bracket Installation

If you are mounting the POEINJ2GI product onto either a DIN Rail or to a wall, you will rst need to attach the appropriate bracket(s) to the device as shown below.

Hardware Installation

1. Connect an Ethernet cable from the desired source network device (i.e. computer, router, switch, etc.) to the “Data In” RJ45 connectors of the POEINJ2GI unit. These can be connected to the same router/switch, or a dierent one depending on your application.
2. Connect the terminal block power source to the POEINJ2GI unit.
3. Connect an RJ45 terminated Ethernet cable to the “PoE Out” connectors on the POEINJ2GI unit. The other end of the cable will either connect directly to a PoE+ / PoE-compliant device, or to a POE Splitter device to separate data and power.
POWER
Power Supply
Instruction Manual
PoE Wireless Access Point
PoE
DATA + POWER
POEINJ2GI
6
DATA
Non-PoE
Ethernet Switch
Specications
Number of Ports 2
Industry Standards IEEE 802.3at PoE, IEEE 802.3af PoE
EMS: EN61000-4-2 (ESD), EN61000-4-3
(RS), EN61000-4-4 (EFT), EN61000-4-5
(Surge), EN61000-4-6 (CS), EN61000-4-8,
Regulatory Approvals
Vibration: IEC60068-2-6 Safety: EN60950-1
Connector(s)
Maximum Data Transfer Rate 1Gbps
Power Output 50V / 600mA, 30 Watts max. per port
Enclosure Type Steel
Power Adapter Terminal Block
Input Voltage 50 ~ 57 DC
Operating Temperature -40°C to 70°C (-40°F to 158°F)
Storage Temperature -40°C to 80°C (-40°F to 176°F)
Humidity 5~95% RH (Non-Condensing)
Dimensions 95 x 70 x 26 mm
Weight 212g
EN61000-4-11
Shock: IEC60068-2-27
Free Fall: IEC60068-2-32
4 - RJ-45 Female
1 - Terminal Block (4 Wire) Female
Instruction Manual
7

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access our comprehensive selection of online tools, documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
Instruction Manual
8
