StarTech.com PCI8S9503V, PCI4S9503V User Manual

3.3 Volt/5 Volt Buffered High Speed Serial
PCI Card

PCI4S9503V
PCI8S9503V

Instruction Guide

The Professionals’ Source For Hard-to-Find Computer Parts

SERIAL CARD

* Actual product may vary from photo

FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

1

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

DOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

SCO OpenServer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2

Introduction

Thank you for purchasing a 3.3 volt/5 volt buffered high-speed serial card from
StarTech.com. Compatible with both 3.3 or 5 volt motherboards, this card adds either
four (PCI4S9503V) or eight (PCI8S950V) high-speed RS-232 ports to your system. The
card uses a 16-Byte buffer in both the receive and transmit channels simultaneously,
reducing the number of CPU interrupts and improving system performance.

Features

• Adds high speed RS-232 serial ports to your computer

•Works with both 3.3 volt and 5 volt server slots

• Complies with Universal 32 bit PCI bus and PCI Bus Version 2.2 specifications

• Compatible with most major OS platforms including Windows, Linux and UNIX

•Provides transfer rates of up to 115 KBytes/sec

• Uses only one IRQ assigned by the PCI BIOS

Before You Begin

To ensure a quick and easy device installation, please read through this section carefully
before attempting to install the device.

Requirements

•Acomputer running Windows XP/2000/NT/Me/98/95, DOS, Linux or SCO Open
Server

• An open 3.3 or 5V PCI slot

Contents

•1 x serial card

•1 x serial cable with DB9 connectors

•Driver disks for Windows, Linux, and Unix

Note: Depending on the driver version, you may also see this referred to as the P584 or
the PCIPORT on the driver disk.
