StarTech.com NETRS2321POE User Manual
NETRS2321POE
Instruction Manual
Ethernet Device Server
1-Port Industrial RS-232
Ethernet Device Server - Power
over Ethernet
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver •
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks,
service marks, and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.
Table of Contents
Hardware Guide ............................................................... 2
Package Contents ....................................................................... 2
Front Panel ..................................................................................2
Rear Panel ................................................................................... 3
LED Indicators .............................................................................3
Hardware installation ...................................................... 4
Configuring the Adapter ................................................. 4
Setting the IP Address .................................................................4
Setting the IP Address from a DHCP Server ...........................5
Setting the IP Address using a Web Browser .......................... 5
Setting the IP Address using the Em.exe Utility ......................6
Managing the Adapter Settings ................................................... 6
Controller Setup Menu Items .......................................................7
Software Installation ....................................................... 9
VSP Virtual COM Port Driver ....................................................... 9
Installing the VSP Vir tual COM Port Driver ..................................10
Specifications .................................................................. 13
Technical Support ........................................................... 15
Warranty Information ...................................................... 15
i
Hardware Guide
Package Contents
1 x Driver CD •
1 x Industrial Switch •
1 x Instruction Manual •
1 x Power Adapter •
Front Panel
1 2 3 4
Switch to Restore Default Settings -1. This switch can be used to
reset the product to its factory default settings. Pressing the switch
using either a pen or similar tool will immediately restore the unit
to its default settings.
RJ45 LAN Connector -2. 10/100Mbps Ethernet port. It supports the
auto cross-over feature, and allows use of the same cable to
connect to either a Hub/Switch or a host computer.
Heartbeat LED3.
+7~12VDC Power Input DC Jack4.
2
Rear Panel
RS-232 Connector1.
LED Indicators
10/100 Mbps LED (amber color)1.
Link/Activity LED (green color)2.
Heartbeat LED (green color)3.
1
1 2 3
LED Name Colour Function
10/100 Mbps
Link/Activity
Heartbeat
Green On: 100Mbps. Off: 10Mbps.
Green On: Linked. Blinking: Transfering Data.
Amber Blinking: Normal Operation. Not Blinking:
Malfunction.
3
Hardware installation
Use static electricity discharge precautions. Remove possible static 1.
discharge potential from any objects that the adapter may come in
contact with prior to installation. This can be accomplished by
touching a bare metal chassis rail after you have turned off the
power.
If you will be externally powering the device, connect the DC power 2.
adapter. If connecting to a PoE switch, hub, or other device, then
a power adapter is not required, as the product will draw its power
from the host device it is connected to. In this case, ensure that
your switching hub is the PoE type that can act as PSE (Power
Source Equipment).
Connecting LAN cable: Use a standard straight-through Ethernet 3.
cable to connect to a Hub or Switch. If you connect the adapter to
your computer’s Ethernet port instead, you don’t need to change to
a cross-over type cable since the adapter provides the auto cross-
over feature.
Connect the Adapter’s serial port to your serial device.4.
Use the DIN RAIL mounting Kit if you want to place the product on 5.
the industrial DIN RAIL. (optional)
Conguring the Adapter
Setting the IP Address
Please consult your Network Administrator to determine the appropriate IP address. The adapter comes with the factory installed IP address
192.168.1.254. It is ready to accept a new IP address from a DHCP
Server. If your network has a DHCP server, it will automatically assign
an IP address to the Adapter the first time it is connected and powered
up.
4
