10/100 30km Single Mode Media Converter
StarTech ID: ET90110SM30
StarTech.com’s high-speed ET90110SM30 media converters are engineered to make fiber connections simple
and reliable for even the most demanding network specialists. StarTech.com’s ET90110SM30 is
the perfect solution for connecting buildings to main networks.<br />
<br />
Easy to set up and install in a matter of seconds. This reliable and compact fiber optic media converter
features a heavy-duty power supply to withstand the most challenging environments. <br />
<br />
ET90110SM30 easily converts between 10 Base-T or 100 Base-TX electrical Ethernet signals and
100 Base-FX optical Ethernet signals. While supporting a maximum single mode fiber optic cable
distance of 30km, it allows full wire speed of 148,800 packet per second throughput that prevents bottlenecks
and keeps your data flowing quickly and smoothly.<br />
<br />
Guaranteed compatibility with 3COM, Cisco, Lucent and Nortel networks and fully complies with
the IEEE 802.3 and 802.3u standard.
Specifications
> Color Beige
> Connector Types 1 - RJ45 Female
> Connector Types 2 - Fiber Optic SC Female
> Product Height 0.79 in [20 mm]
> Input Voltage 115 AC
> Product Length 4.8 in [122 mm]
> Output Current 1 Amp
> Output Voltage 12 DC
> Power Adapter Included Yes
> Center Tip Polarity Positive
> Carton Quantity 14
> Shipping (Package) Weight 2.03 lb [0.92 kg]
> Product Weight 12 oz [340 g]
> Product Width 3.37 in [85.6 mm]
> LED Indicators
> Power indicator
> 100M active (light) or 10M (off)
> FX port with full Duplex (light) or Half Duplex (off)
> UTP port with Full Duplex (light) or Half Duplex (off)
> Fx port link success (light), fail (off) or receive data (flash)
> UTP port link success (light), fail (off) or receive data (flash)
