100-Mbps RJ45 to SC Single Mode Fiber Media Converter
StarTech ID: ET9003SM
The StarTech.com 100Base-TX to 100Base-FX Long Range Fiber Optic media converter provides a
simple plug and play solution for converting electrical Ethernet signals to optical Ethernet signals.
This allows the use of single mode fiber optic cable for electrical noise immunity and cable lengths
of up to 20Km. This model uses SC type fiber optic connectors.
Applications and Solutions
> Connecting networks between buildings
> Connecting remote areas of large buildings
> Connecting buildings in a metropolitan area
Features
> Complete set of diagnostic LEDs to indicate the converter’s operating status
> Easy installation in seconds.
> Guaranteed compatibility with 3Com, Cisco, Lucent, and Nortel networks due to compliance with
IEEE 802.3u standard
> Heavy-duty power supply which is engineered to withstand the most challenging environments.
> Slim and compact palmtop design
> Standard RJ-45 connectors for connecting to UTP media, and SC connectors for connecting to
fiber media.
> Supports 802.3u 100BaseTX and 100BaseFX industry standards
> Supports a maximum single mode fiber optic cable distance of 20 km or 12.5 miles
> Supports Half-Duplex and Full-Duplex operating modes.
Specifications
> Color Beige
> Connector Types 1 - RJ45 Female
> Connector Types 1 - Fiber Optic SC Female
> Product Height 0.87 in [22 mm]
> LED Indicators 1 - Power
> LED Indicators 1 - Link
> LED Indicators 1 - Activity
> Product Length 3.74 in [95 mm]
> Shipping (Package) Weight 1.94 lb [0.88 kg]
> Product Width 2.76 in [70 mm]
> Copper Connector Shielded RJ-45 Female
> Fiber Connectors SC Female (single mode)
> Fiber types supported 8.3/125, 8.7/125, 10/125 micron single mode
> Operating Temperature 0 - 50? C
> Humidity 5 - 90% non-condensing
> Certifications FCC PArt 15 Class A, CE Mark
> Wave length 1300nm
