Cat 6 RJ45 Modular Plug for Solid Wire - 50 Pack
Quick-Start Guide
Product Diagram (CRJ45C6SOL50)
1
Connector Function
1 Pins x 8
• Used to connect the eight wires within the
Ethernet cable to the Modular Connector.
Requirements
• Unshielded Twisted Pair Patch Cable (UTC) x 1
• Modular Connectors x 2
• Crimping Tool x 1
• Cable Tester x 1
• Wire Cutter x 1
Installation
Notes: Wire Cutter’s are very sharp and should be used with extreme care.
Wiring should be completed by a certied professional as per the local safety and
building code guidelines.
1. Carefully using a Wire Cutter strip the jacket o of the UTC Cable, 1.5” from the end
of the cable exposing the four pairs of twisted wires.
2. Spread the four pairs of twisted wires apart.
4. Arrange the eight wires using either the T568A or T568B pattern. See Wire
Orientation for more information.
5. Using the Wire Cutters, cut the eight wires 0.5” from the end of the wires, leaving a
clean straight cut at the end of the wires.
6. Carefully insert the wires in the Modular Connector. Ensure that each of the wires
passes through the guides that are inside of the Modular Connector.
7. Push the Modular Connector into the slot in the Crimping Tool and squeeze down
on the handle to secure the wires in the Modular Connector.
8. Repeat steps 1 - 7 on the other end of the UTC Cable.
9. Using the Cable Tester on both ends of the UTC Cable to test each of the pins in the
Modular Connector.
Wire Orientation
T568A Standard:
Note: Start from the left of the Modular Connector and work towards the right (Pin
1 - 8).
Pin Wire
Pin 1 • White/Green
Pin 2 • Green
Pin 3 • White/Orange
Pin 4 • Blue
Pin 5 • White/Blue
Pin 6 • Orange
Pin 7 • White/Brown
Pin 8 • Brown
Note: CAT5e cables have a pull sting that will need to be removed.
CAT6 Cables have a spine that will need to be removed.
3. Untwist the four pairs of wires, creating eight separate wires.
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: January 25, 2019 1:04 PM
T568B Standard:
Note: T568B Standard is the mostly commonly used method for Ethernet cables.
Pin Wire
Pin 1 • White/Orange
Pin 2 • Orange
Pin 3 • White/Green
Pin 4 • Blue
Pin 5 • White/Blue
Pin 6 • Green
Pin 7 • White/Brown
Pin 8 • Brown
