CardBus USB Adapter
2 Port CardBus Laptop USB 2.0
PC Card Adapter - VIA chip
CBUSB22
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver •
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company
in question. Regardless of any direct acknowledgement elsewhere in the body of
this document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.
i
Table of Contents
Introduction ..................................................................... 1
Packaging Contents.....................................................................1
System Requirements .................................................................1
Installation ....................................................................... 1
Driver Installation .........................................................................1
Verifying Driver Installation ..........................................................2
Specifications .................................................................. 3
Technical Support ........................................................... 4
Warranty Information ...................................................... 4
1
Introduction
Packaging Contents
1 x CBUSB22 CardBus adapter•
1 x Driver CD•
1 x Instruction Manual•
System Requirements
Intel Pentium Pro/Pentium III equivalent or greater processor•
CardBus enabled computer system•
Microsoft Windows•
®
98SE/ME/2000 SP3/XP/Server 2003/Vista,
Mac OS® 10.2+, Linux kernel
Installation
Driver Installation
Windows 98SE/ME
Please insert the driver CD into your CD-ROM drive.1.
Open the drivers folder, then the windows folder, then double click 2.
the setup.exe files.
Please click “Next.” Next you will be prompted with a window offering 3.
you two choices. Choose to install the USB 2.0 drivers if you wish
to install the USB 2.0 drivers, or should you wish to remove the USB
2.0 drivers simply choose the other option, and the drivers will be
completely removed from your computer. Click “Next” to finish the
installation.
You will now be prompted to restart your computer. Click “Finish” to 4.
restart your computer. Remember to save any other files you may be
working on before restarting your computer.
2
Once your computer restarts, insert the CBUSB22 card into the 5.
CardBus slot. The “Add Hardware Wizard” will launch and guide you
through the installation of the required drivers. You will need to do
this two times since there are two USB ports on this product.
Windows 2000/XP/Server 2003/Vista, Mac OS 10.2+, Linux Kernel
No driver installation is required for these operating systems, as this
CardBus USB Controller Card is natively supported, so the drivers are
already installed.
Verifying Driver Installation
Windows 98SE/ME: From the main desktop, right-click on “My
Computer”, then select Properties. Click on the Device Manager tab
along the top.
Windows 2000/XP/Vista: From the main desktop, right-click on “My
Computer” (“Computer” in Vista), then select Manage. In the new
Computer Management window, select Device Manager from the left
window panel.
Double-click on the “Universal Serial Bus Controllers” option. There
should be several “VIA” devices visible, including an “Enhanced”
controller, which indicates USB 2.0 speeds.
3
Specications
Bus Interface
CardBus (32-bit)
USB Specification
USB 2.0 (EHCI/UHCI)
External Connectors
2 x USB type A
1 x DC power connector
(3.4mm OD, 1.3mm ID)
Chipset
VIA VT6212
Maximum Data Transfer Rate
USB 2.0: 480 Mb/s
Optional Power Adapter
5VDC, 1A
Compatible Operating
Systems
Windows 98SE/ME/2000/XP/
Server 2003/Vista,
Mac OS 10.2+, Linux kernel
4
