ATX2PW430WH / ATX2PW500WH / ATX2PW530WH / ATX2PW550WH / ATX2PW630WH / ATX2PW450BR / ATX2PW450GO

ATX Power Supply - 80 Plus® Certied

*ATX2PW430WH shown

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................ 2

Packaging Contents .................................................................................................................................2

System Requirements ..............................................................................................................................2

Installation ..............................................................................................2

Hardware Installation ............................................................................3

Specications .......................................................................................... 4

DC Output ...............................................................................................7

Connectors for ........................................................................................8

Connectors for ........................................................................................9

Technical Support ..................................................................................10

Warranty Information ............................................................................ 10

Instruction Manual

Introduction

Packaging Contents

• ATX Power Supply

• Quick Install Guide

System Requirements

• ATX compliant motherboard

• ATX compliant computer case that ts a full sized power supply

• Standard Computer Power Cord (Regional AC to C13)

Installation

WARNING! Computer parts can be severely damaged by static electricity. Be sure that you are properly grounded before opening your computer case. StarTech. com recommends that you wear an anti-static strap when installing any computer component. If an anti-static strap is unavailable, discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds.

Installation of a power supply requires some mechanical skill and requires that you open your computer case to disconnect and reconnect wires. If you are unfamiliar with this kind of work, consider bringing your computer and new StarTech.com power supply to your local computer store for help.

Instruction Manual

Hardware Installation

1. If replacing an existing power supply, turn your computer o and any peripherals connected to the computer (i.e. printers, external hard drives, etc.).

2. If replacing an existing power supply check to see if it has a power switch on it, set it to the “0” position. Unplug the power cable from the rear of the power supply on the back of the computer and disconnect all other peripheral cables.

3. Remove the cover from the computer case. For detailed steps refer to the documentation included with your computer system, or computer case.

4. If replacing an existing power supply disconnect all of the power connectors from the motherboard and peripheral devices (i.e. hard drives, CD/DVD drives, etc). Make sure to take note of each connector and where they were plugged in. Ensure there are no devices connected to the existing power supply.

5. If replacing an existing power supply remove it from the computer case. This is typically done by removing four (4) mounting screws on the outside face of the power supply. Refer to documentation for your computer system or computer case for specics.

6. Hold the new power supply into place so that the 4 screw holes around the fan are lined up with installation holes on your computer case, and x 4 screws (included with your computer case) through the computer case into the power supply. Refer to documentation for your computer system or computer case for specics.

7. Connect the power connectors from the power supply to the motherboard and any peripheral devices that require power. If you are replacing an existing power supply, replace all power connectors that were removed. Refer to the documentation for your motherboard and peripheral devices for details regarding power requirements. Note: This power supply uses a 20+4 pin ATX connector, so it can be used on motherboards with either a 20-pin or 24-pin connector. Simply detach the extra 4-pin attachment for use on 20-pin motherboards.

8. Make sure any loose or unused cables from the power supply are away from fans and other moving parts.

9. Place the cover onto the computer case. For detailed steps refer to the documentation included with your computer system, or computer case.

10. Connect the Power Cable

11. Set up your computer system. Refer to documents included with your computer system and any attached devices.

12. The computer system is now ready to be turned on.

Instruction Manual

Specications

ATX2PW430WH ATX2PW500WH

Standards

ATX12V v2.3

EPS12V v2.92

Eciency Rating

80% @ 20% - 86 Watt

80% @ 50% - 215 Watt

80% @ 100% - 430 Watt

80% @ 20% - 110 Watt 80% @ 50% - 275 Watt

80% @ 100% - 550 Watt

Maximum Power

Output

430W 500W

Fans 1 x 80mm

Input Power 100 ~ 240VAC, 10 ~ 5A, 47 ~ 63Hz

Operating

Temperature

0°C to 40°C (32°F to 104°F)

Storage Temperature -20°C to 80°C (-4°F to 176°F)

Humidity 10~90% RH

MTBF 100,000

Dimensions (LxWxH) 150mm x 86mm x 140mm

Instruction Manual

Specications cont...

ATX2PW530WH ATX2PW550WH

Standards

ATX12V v2.3

EPS12V v2.92

Eciency Rating

80% @ 20% - 106 Watt 80% @ 50% - 265 Watt

80% @ 100% - 530 Watt

80% @ 20% - 110 Watt 80% @ 50% - 275 Watt

80% @ 100% - 550 Watt

Maximum Power

Output

530W 550W

Fans 1 x 80mm

Input Power 100 ~ 240VAC, 10 ~ 5A, 47 ~ 63Hz

Operating

Temperature

0°C to 40°C (32°F to 104°F)

Storage Temperature -20°C to 80°C (-4°F to 176°F)

Humidity 10~90% RH

MTBF 100,000

Dimensions (LxWxH) 150mm x 86mm x 140mm

Instruction Manual

Specications cont...

ATX2PW630WH ATX2PW450BR ATX2PW450GO

Standards

ATX12V v2.3

EPS12V v2.92

Eciency

Rating

80% @ 20% - 126

Watt

80% @ 50% - 315

Watt

80% @ 100% -630

Watt

81% @ 20% - 90

Watt

85% @ 50% - 225

Watt

81% @ 100% - 450

Watt

87% @ 20% - 90

Watt

90% @ 50% - 225

Watt

87% @ 100% - 450

Watt

Maximum

Power

Output

630W 450W 450W

Fans 1 x 80mm

Input Power 100 ~ 240VAC, 10 ~ 5A, 47 ~ 63Hz

Operating

Temperature

0°C to 40°C (32°F to 104°F)

Storage

Temperature

-20°C to 80°C (-4°F to 176°F)

Humidity 10~90% RH

MTBF 100,000

Dimensions

(LxWxH)

150mm x 86mm x 140mm
