Operation Manual
50 Watt SMD Work Site Light
- 4,700 Lumens
Prod. No. 849915 Mod. No. SWL-50
Read all safety warnings and instructions. Failure to follow all warnings
and instructions may result in electric shock, re, or serious injury.
Save all warnings and instructions for future reference.
• Do not use in areas where ammable materials may be present
• Do not abuse the cord. Never use the cord for carrying, pulling, or unplugging the light.
Keep cord away from heat, oil, sharp edges, or moving parts
• Do not use if switch is not operational
• Disconnect from power source before cleaning or maintaining light
• Use an outdoor rated extension cord if using light outside
• Do not look directly at light during operation to avoid possible eye injury
• Do not alter or modify the work light in any way
CAUTION: RISK OF ELECTRIC SHOCK – Do not use with extension cord in
water or near where water may accumulate. Keep work light a minimum
of 16' away from pools, spas and other bodies of water
M16-ST849915
TECHNICAL SPECIFICATIONS
Voltage: 120 V, 60 Hz
Amperage: 0.2 A
Lumens: 4,700
Watts: 50
Surface Mounted Diodes: 100
IP rating: IP-44
SMD Lifetime Estimate: 30,000 hours
POWER SUPPLY
Assembly and Operation
B
C
Your STARTECH work light must be connected to a 120 V 60 Hz
15 A power supply protected by a circuit breaker. FAILURE TO
CONNECT THIS WAY MAY CAUSE ELECTRICAL SHOCK OR FIRE.
Work light must be grounded; consult a quali ed electrician if
you are not sure if your outlet is properly grounded. FAILURE
TO USE A PROPERLY GROUNDED OUTLET MAY CAUSE
ELECTRICAL SHOCK.
Your STARTECH work light is IP-44 rated for use outdoors.
For outdoor wet locations the use of a Ground Fault Circuit
Interrupter (GFCI) provides additional safety.
DO NOT REMOVE OR ALTER THE GROUNDING PRONG
EXTENSION CORDS
Using an extension cord will
result in the loss of voltage
between the outlet and the
tool. Use chart below to
determine minimum AWG
wire size for the length of
cord you require. If used
outdoors ensure extension
cord is suitably rated.
Length Gauge
0 – 25 Feet 16 ga
26 – 50 Feet 14 ga
51 – 100 Feet 12 ga
A
Figure 1
ASSEMBLY
1. Place base (A) on at work surface.
2. Attach light using lock knob (B) inserted through hole in
bracket (C) into threaded hole in base (see gure 1).
3. Fasten with at washer and lock washer.
OPERATION
Plug light into 120 V 60 Hz single phase 15 A receptacle. Press
weather sealed switch (located on back of unit) once to turn
light on and again to turn it o . Always turn light o at the
switch before disconnecting from power supply.
Light can be aimed up to 30° down or 90° up. Loosen side
locking knobs, adjust work light head to aim light at work
space, then tighten locking knobs.
MAINTENANCE
Your work light requires little maintenance. Clean lens and
body with a non-abrasive cleaner. Periodically inspect cord
for cracks, cuts, and abrasions. Inspect plug and ensure
grounding prong is present and undamaged. If service is
required, use only identical replacement parts. Contact your
retailer for further information.
DISPOSAL
Do not dispose of used electrical equipment in household
or unsorted waste. Contact your local municipal authority
for information on recycling electrical equipment in your
community.
