Startech WALLSTS1 Product Data Sheet

Wall Mount Workstation - Articulating Full Motion Standing Desk with Ergonomic Height Adjustable
Monitor & Keyboard Tray Arm - Mouse & Scanner Holders - Single VESA Display

Product ID: WALLSTS1

This wall-mounted sit-stand desk is perfect for areas that don't have enough space for a traditional sit-stand desk. Its
compact, wall-mounted design combines a single-monitor arm and a keyboard tray, with easy height adjustments that
let you alternate between sitting and standing without disrupting your workflow.

Adjust your working position in one smooth motion. Simply lift the work surface up to 17.2" (436 mm), to elevate your
monitor, keyboard and mouse. The monitor mount has a separate height adjustment of up to 4.9" (124 mm) along the
column.

This sit-stand monitor arm supports one monitor up to 34" (with weight capacity of 17.6 lb./8 kg). Adjust your monitor
for ideal viewing with -5 to 35 tilt, or rotate your monitors up to 360 for portrait or landscape orientation.

The sit-stand desk folds back to the wall, and keyboard tray folds up to 90, saving space when not in use. You can
move the swing arm left or right (from -90 to 90) and lower or raise the arm (from -30 to 65) to make maximum use of
your space.

The monitor arm offers plenty of work space with a large keyboard tray (17.68 x 8.15"/ 449 x 207 mm) and a slide-out
tray (8.5 x 8.4" / 217 x 213 mm) that holds your mouse, on the left or right.

The WALLSTS1 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Certifications, Reports and Compatibility

Applications

• Works well in areas needing quick and easy computer access by many users, where space is limited

• A flexible solution for a wide range of users of various heights

• Ideal for use in medical and retail environments, with features like the scanner holder

Hardware

Warranty

2 Years

Wallmountable

Yes

Cable Management

Yes

# of Displays Supported

1

Mounting Options

Wall-Mount

VESA Hole Pattern(s)

75x75 mm

100x100 mm

Features

• WALL-MOUNT WORKSTATION: Ergonomic standing desk with a VESA compatible (75x75/100x100mm) single
monitor arm supports any display including Ultrawide up to 17.6lb (8kg); Wall-mounted sit-stand workstation with
keyboard and mouse tray

• FOLDABLE WORKSTATION: Stow away when not in use (13.1" profile); Secure computer keyboard w/ adhesive
strip, includes mouse tray; Articulating arm allows monitor to extend 22" & keyboard tray 38" from wall

• RANGE OF MOTION: Display has +35/-5 vertical tilt, 360 rotation; Keyboard & mouse tray tilts 90; Raise
workstation (monitor, keyboard and mouse) with 17.2" one-touch adjustable height; Adjustment tools incl.

• FULL ARTICULATION: Full workstation can swivel +/-90, tilt +65/-30; When workstation is ideally positioned, the
monitor has additional one-touch height adjustment along the 4.9" track

• THOUGHTFUL DESIGN: Integrated cable management for monitor & keyboard tray; Individual holders for mouse &
handheld scanner; High quality finish w/ decorative cover for the base plate that attaches to wall

• Viewing distance: 16.1" (408.7 mm)

• Rotates 360 for landscape or portrait viewing

• Durable construction, made of steel, aluminum and plastic

• Built-in cable management keeps your workstation well organized

• Compact sit-stand desk folds back to the wall, and keyboard tray folds up to 90, saving space when not in use

• 100 x 100 mm, 75 x 75 mm VESA mount compatible

• Supports a single monitor up to 34" (with weight capacity of 17.6 lb./8 kg)
