Composite and S-Video to VGA Video Scan Converter
Product ID: VID2VGATV2
The VID2VGATV2 Composite and S-Video to VGA Video Scan Converter (with Scaler) provides a simple way to
convert Composite or S-Video signals to VGA (or Component RCA) output, for use with computer monitors,
projectors or HDTV sets.
Equipped with an On-Screen Display (OSD) menu and dip switches for simple configuration and selection of your
video output settings, this compact video scaler installs quickly and easily for a true plug-and-play experience. An
integrated scaler circuit dynamically converts the S-Video or Composite video input signal, giving you multiple output
resolutions to choose from, to ensure compatibility with your display or projector.
Plus, the Component/S-Video-VGA Converter includes a VGA to Component (RCA) breakout cable, which enables
you to connect to TV sets that are not equipped with a VGA port.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Certifications, Reports and Compatibility
Applications
• Perfect for displaying video from DVD players, VCRs or legacy Game Consoles on VGA projectors and HDTV sets
• Monitor security cameras with S-Video or composite signaling using VGA monitors or televisions
• Adapt VHS video in the classroom to newer televisions
• Convert legacy Medical Imaging equipment for display on computer monitors
• Use in boardrooms for adapting legacy video equipment to work with new projectors
• Display camcorder output on televisions or monitors equipped with VGA input
Hardware
Warranty
2 Years
Active or Passive Adapter
Active
AV Input
S-Video
Composite
AV Output
VGA
Component
Audio
No
Performance
Supported Resolutions
PC: 1600x1200, 1280x1024, 1024x768
HDTV: 480p (50/60Hz), 576p (50Hz), 720p (50/60Hz), 1080p
(50/60Hz)
Signal Levels
Input
Video @ 1V p-p, 75 ohm
Y @ 1 V p-p, 75 ohm
Color @ 0.7V p-p, 75 ohm
Connector(s)
Connector A
Composite Video (1 x RCA)
S-Video (4 pin, Mini-DIN)
Features
• Convert and scale Composite/S-Video input to VGA/Component output
• Accepts NTSC and PAL input
• On-Screen Display for simple output setting selection
• 50 Hz to 60 Hz frame rate conversion
• Plug & Play installation - no drivers or software required
• VGA to Component (YPbPr) RCA Adapter included
Connector B
VGA (15 pin, High Density D-Sub)
Indicators
LED Indicators
Composite (Yellow) / S-Video (Red) input indicator
Power
Power Source
AC Adapter Included
Output Voltage
5 DC
Output Current
1A
Power Consumption (In
Watts)
2.5
Environmental
Operating Temperature
0C to 40C (32F to 104F)
Storage Temperature
0C to 60C (32F to 140F)
Humidity
0~60% RH
Physical
Characteristics
Color
Black
Material
Plastic
Product Length
4.4 in [11.2 cm]
Product Width
2.5 in [64 mm]
Product Height
1.0 in [26 mm]
Weight of Product
3.0 oz [86 g]
Packaging
Information
Package Length
4.6 in [11.8 cm]
Package Width
8.2 in [20.9 cm]
Package Height
2.4 in [61 mm]
Shipping (Package)
Weight
16.2 oz [459 g]
What's in the
Box
Included in Package
Video Converter/Scaler
Universal Power Adapter
Instruction Manual
VGA to Component (RCA) breakout cable
*Product appearance and specifications are subject to change without notice.
