Composite and S-Video to HDMI Converter with Audio
Product ID: VID2HDCON
The VID2HDCON Composite and S-Video to HDMI Video Converter (with Audio) lets you connect an S-Video or
Composite device, along with supporting 3.5mm audio, to your HDMI monitor or television.
Equipped with convenient selector switches for easy configuration, the S-Video/Composite to HDMI converter is able
to function with both NTSC and PAL systems, and offers support for output resolutions up to 1600x1200 (PC) or
1080p (TV) to seamlessly integrate with almost any display.
The converter features an integrated 3.5mm audio connection that enables sending the output through a single HDMI
cable to your destination display, avoiding the hassle of running a separate audio cable.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Certifications, Reports and Compatibility
Applications
• Convert VCRs, DVD players, camcorders, video game consoles and other home theater devices to work on HDMI
displays
Features
• Functions with NTSC and PAL systems
• PC/TV resolution selector switch for compatibility with many different displays
• Advance 3D motion adaptive de-interlace
• 50/60 Hz frame rate conversion
Hardware
Warranty
2 Years
Active or Passive Adapter
Active
AV Input
Composite
S-Video
3.5 mm Stereo Audio
AV Output
HDMI
Audio
Yes
Industry Standards
NTSC 3.58 and PAL
Performance
Supported Resolutions
PC - 1600x1200, 1280x1024, 1024x768
TV - 1080p, 720p, 576p, 480p
Connector(s)
Connector Type(s)
Composite Video (1 x RCA)
S-Video (4 pin, Mini-DIN)
HDMI (19 pin)
3.5 mm Mini-Jack (3 Position)
Indicators
LED Indicators
Red - S-Video, Yellow - Composite Video
Power
Power Source
AC Adapter Included
Input Voltage
100 - 240 AC
Input Current
0.3A
• On Screen Display
• Plug and play installation - no software/drivers required
• 3D (frame based) motion adaptive YNR/CNR noise reduction
