Composite/S-Video to HDMI Video Converter
with Audio
VID2HDCON
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 07/28/2011
*actual product may vary from photos
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company
in question. Regardless of any direct acknowledgement elsewhere in the body of
this document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.
Instruction Manual
Table of Contents
Introduction ............................................................................................. 1
Packaging Contents ..........................................................................................................................1
System Requirements.......................................................................................................................1
Front View .............................................................................................................................................2
Rear View ...............................................................................................................................................2
Side View ...............................................................................................................................................3
Installation ............................................................................................... 4
Hardware Installation .......................................................................................................................4
Driver Installation ...............................................................................................................................4
Specications ........................................................................................... 6
Technical Support ................................................................................... 7
Warranty Information ............................................................................. 7
Instruction Manual
i
Introduction
The VID2HDCON Composite and S-Video to HDMI® Video Converter with Audio
lets you connect an S-Video or Composite device with supporting 3.5mm audio
to your HDMI monitor or television.
Equipped with convenient selector switches for conguration, the S-Video/
composite converter is able to function in both NTSC and PAL systems, and
oers support for output resolutions up to 1600x1200 (PC) or 1080p (TV) to
seamlessly integrate with almost any display.
An integrated 3.5mm audio connection provides the ability to send your
output through a single HDMI cable to your destination display, avoiding the
hassle of running a separate audio cable.
Packaging Contents
• 1 x Video Converter
• 1 x Universal Power Adapter
• 3 x Power Adapter plug (NA/UK/EU)
• 1 x Instruction Manual
System Requirements
• Composite or S-Video enabled video source (i.e. DVD player, PVR/DVR, etc.)
• Composite or S-Video cable
• HDMI enabled display device (e.g. monitor, projector, etc.)
• HDMI cable
• Available AC electrical outlet
Instruction Manual
1
Front View
Rear View
Instruction Manual
2
Side View
Instruction Manual
3
Installation
Hardware Installation
1. Make sure all devices and components are powered o.
2. Connect the video source to the input side of the video converter using
either an S-Video or composite RCA cable (both sold separately).
3. For audio, connect a 3.5mm Audio mini-jack cable into the “Audio In”
connector on the converter. Audio will be combined and output through
HDMI.
4. Plug the power adapter into the video converter. The Input indicator LED will
light up steady.
5. If not already set to the correct input, press the Input selector button to
change the input source. The LED will light up green for composite and red
for S-Video.
6. Connect the display to the converter using a male/male HDMI cable (sold
separately).
7. Set the Output Signal Mode selector switch along the side of the video
converter to the type of display you are using: “HD” for a TV and “PC” for a
monitor.
8. Select the output resolution using the slide switch next to the HDMI output
connector. Make sure to select an output resolution that is supported by the
display device.
9. Power on the display device.
10. Power on the video source.
Driver Installation
The video converter is an external pure hardware converter, so no driver or
software installation is required.
Instruction Manual
4
Specications
Video Signal (Input)
Video Signal (Output) HDMI
1 x RCA Composite female
Connectors
LEDs 1 x Input Selection
Supported Video Systems NTSC, PAL
PC: XGA (1024x768), SXGA (1280x1024),
Supported Video Output
On Screen Display Yes
Audio Support Yes
Power Adapter
Enclosure Material Plastic
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
Humidity 20% ~ 90% RH
Dimensions (LxWxH) 165.0mm x 162.6mm x 33.5mm
Weight 100g
1 x S-Video 4-pin female
UXGA (1600x1200) @ 60 Hz
HD: 480p, 720p, 1080p @ 50/60 Hz
5V DC, 1000mA, center positive,
Composite
S-Video
1 x HDMI type A female
1 x DC Power
type M plug
Instruction Manual
5
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials and
workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products
at our discretion. The warranty covers parts and labor costs only. StarTech.com does not
warrant its products from defects or damages arising from misuse, abuse, alteration, or
normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
