VGA to HDMI Adapter with USB Audio & Power –
Portable VGA to HDMI Converter – 1080p
Product ID: VGA2HDU
The VGA2HDU VGA to HDMI adapter lets you turn the VGA port on your Desktop or Laptop computer into
an HDMI output port.
With the VGA2HDU, you can expand your VGA video output to accommodate the increasing number of
displays and projectors that only support HDMI.
Not all VGA converters are created equal. This adapter ensures you're harnessing the highest video
quality from your VGA output, with support for resolutions up to 1920x1080 (1080p).
For hassle-free setup the VGA to HDMI adapter allows for plug-and-play installation. Plus, with a built-in
USB power cable the device is powered using the USB port on your computer. The VGA to HDMI adapter
will work with any computer operating system, but when working with a Windows® computer the adapter
supports native USB audio, allowing you to add your computer audio to the HDMI signal.
The VGA2HDU is backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Connect your VGA-equipped computer to an HDMI home theatre
system
• Share video content from your VGA-equipped computer on an HDMI
television or projector
• Connect a legacy VGA-equipped device to a newer HDMI display
• Share audio from your Windows based PC
Features
• Supports video resolutions up to 1920x1080
• Plug-and-play installation
• USB powered
• USB audio
• Compact, lightweight design
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Active or Passive Adapter Active
Adapter Style Adapters
Audio Yes
AV Input VGA
AV Output HDMI
Cabling HDMI
Chipset ID Micro Silicon - MS9282
Performance Maximum Analog Resolutions 1920x1080
Maximum Digital Resolutions 1920x1080
Supported Resolutions 1920x1080 (1080p)
1680x1050 (WSXGA+)
1600x1200
1600x900
1440x900
1400x1050 (SXGA+)
1366x768
1360x768
1280x1024
1280x960
1280x800
1280x768 (WXGA)
1280x720p (720p)
1280x600
1152x864
1024x768
800x600 (SVGA)
640x480 (480p)
Wide Screen Supported Yes
Connector(s) Connector A 1 - VGA (15 pin, High Density D-Sub) Male Input
1 - USB Type-A (4 pin) USB 2.0 Male
Connector B 1 - HDMI (19 pin) Female Output
Special Notes /
Requirements
Note When used with a Windows® computer this adapter
supports native USB audio.
Power Power Source USB-Powered
Environmental Humidity 40%-85%RH
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -10°C to 70°C (14°F to 158°F)
www.startech.com
1 800 265 1844
Physical
Characteristics
Color Black
Enclosure Type Plastic
Product Height 0.6 in [1.5 cm]
Product Length 10.2 in [26 cm]
Product Width 1.4 in [35 mm]
Weight of Product 2.5 oz [70.7 g]
Packaging
Information
Package Height 1.2 in [30 mm]
Package Length 6.8 in [17.3 cm]
Package Width 5.7 in [14.4 cm]
Shipping (Package) Weight 5.3 oz [151 g]
What's in the Box Included in Package 1 - VGA to HDMI adapter w/ USB power & audio
1 - 2ft USB Extension Cable
Product appearance and specifications are subject to change without notice.
