Universal USB 3.0 Laptop Docking Station w/ Dual DVI Video - HDMI® & VGA Adapters, 2x USB Fast
Charge Ports, USB 3.0, GbE
StarTech ID: USB3SDOCKDD
The USB3SDOCKDD USB 3.0 Laptop Docking Station delivers display flexibility, faster device charging, and
desktop convenience to your home or office workstation. From just a single connection point, the docking station
instantly adds two DVI ports plus HDMI® and VGA adapters, a USB 3.0 hub with two quick-charge ports, Gigabit
Ethernet, and a 3.55mm headset jack to your USB 3.0-equipped laptop, for hassle-free docking.
Display Flexibility
Discover multi-monitor freedom! Boost your productivity and add dual monitors to your workstation with one of the
only docking stations to offer dual DVI video ports with support for resolutions up to 1920x1200.
For extra display flexibility we’ve included two DVI video adapters, letting you avoid the frustration and costs of
purchasing additional products just to fit the displays you already use. Leave the stress of interface limitations at the
door by adapting to the most popular monitor types right out of the box. No hassle, no headaches.
Device Charging
Charge your mobile devices faster, with or without a host connected to the dock. USB charging is convenient, fast,
and accessible through two front “always on” USB fast-charge ports with downstream throughput and support for
USB Battery Charging Specification 1.2.
You can easily charge other devices while connected to multiple displays, a Gigabit network, and numerous USB
peripherals through the integrated 5-port USB 3.0 controller. Perfect for external USB 3.0 hard drives, the docking
station supports UASP-enhanced performance for faster data transfer rates, which means less waiting and more
productivity.
Desktop Convenience
Save time and get more work done! With a single connection to a single laptop (e.g. MacBook Pro®, MacBook
Air®, Lenovo® ThinkPad®, HP® or Dell® Ultrabook™) your required peripherals remain connected. Overcome
your laptop port limitations and reduce the hassle of constantly reconnecting devices, to create an organized and
full-sized workstation with less clutter that's great for “hot desking”.
Plus, for a clean and customized workspace you can position the docking station in horizontal orientation, or upright
(tower), using the included optional stand.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Connect multiple monitors in a variety of flexible display combinations right out-of-the-box: DVI + DVI, DVI +
HDMI, DVI + VGA, HDMI + DVI, HDMI + VGA
Create a shared workspace or hot desk with an integrated charging station for guests, customers, and
colleagues
Connect a wide variety of peripherals at home / office to a laptop, all from a single USB 3.0 connection
Neatly set up in mixed environments with upright or vertically positioning through an included optional stand
Perfect for use with your Macbook or Ultrabook, with aesthetically matching silver sand blast housing
Features
Dual monitor support with dual DVI output plus DVI to HDMI® and DVI to VGA adapters included
Two front fast-charge USB 3.0 ports able to charge devices without a host connection
Brushed aluminum finish with vertical or horizontal dock orientation
5x USB 3.0 ports with UASP support (2x front ports with USB Battery Charging Specification 1.2., 3x rear
ports)
Front panel 3.5mm 4-Position TRRS Headset port - Audio/Microphone
Gigabit Ethernet RJ-45 Port with Wake-on-LAN (WOL)
Includes 1m flexible and ultra-thin USB 3.0 host cable, stand with screws / screwdriver, and 4x rubber feet
Charging station with more USB 3.0 ports than most docking stations (5 total)
Front panel Power LED
Technical Specifications
Warranty 2 Years
Bus Type USB 3.0
Industry Standards IEEE 802.3, 802.3u and 802.3ab
USB Battery Charging Specification Rev. 1.2
USB 3.0 - Hub ports support USB 2.0/1.1 backward-compatibility
Chipset ID DisplayLink - DL-3900 (Display, LAN, Audio)
Genesys Logic - GL3520 (USB 3.0 w/ Charge)
Connector Type(s) 1 - DVI-D (25 pin) Female
Connector Type(s) 1 - DVI-I (29 pin) Female
Connector Type(s) 5 - USB 3.0 A (9 pin; SuperSpeed) Female
Connector Type(s) 1 - USB 3.0 B (9 pin; SuperSpeed) Female
Connector Type(s) 1 - RJ-45 Female
Connector Type(s) 1 - 3.5 mm Mini-Jack (4 Position) Female
Maximum Data
Transfer Rate
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Analog
Resolutions
1920x1200 (VGA)
Maximum Digital
Resolutions
1920x1200 (Dual-Link DVI/HDMI)
Type and Rate USB 3.0 - 5 Gbit/s
Compatible Networks 10/100/1000 Mbps
Auto MDIX Yes
Full Duplex Support Yes
OS Compatibility Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64)
Windows Server® 2012, 2008 R2, 2003
Mac OS 10.6 and up (Tested up to 10.9)
System and Cable
Requirements
USB 3.0 port interface and USB 3.0 cable to connect the Laptop Docking Station to a host
computer (USB 3.0 host cable included)
Note HDMI and VGA adapters included
VGA adapter can only be used on the DVI-I (29-pin) port
Color Black & Silver
Enclosure Type Aluminum and Plastic
Cable Length 3.3 ft [1 m]
Product Length 3.1 in [80 mm]
Product Width 0.9 in [24 mm]
Product Height 7.1 in [180 mm]
Product Weight 15.9 oz [450 g]
LED Indicators 1 - 1 - Power
Input Voltage 100 ~ 240 AC
Input Current 800 mA
Output Voltage 5 DC
Output Current 4.0 A
Center Tip Polarity Positive
Plug Type M
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 5~85% RH
Shipping (Package)
Weight
19.8 oz [560 g]
Included in Package 1 - USB 3.0 Laptop Docking Station
Included in Package 1 - 1m USB 3.0 Cable
Included in Package 4 - Rubber Feet
Included in Package 1 - Stand
Included in Package 2 - Stand Screws
Included in Package 1 - Screwdriver
Included in Package 1 - DVI to VGA Adapter
Included in Package 1 - DVI to HDMI Adapter
Included in Package 1 - Universal Power Adapter (NA/UK/EU)
Included in Package 1 - Driver CD
Included in Package 1 - Instruction Manual
Certifications, Reports and Compatibility
