Dual Monitor USB 3.0 Docking Station with HDMI &
4K DisplayPort
Product ID: USB3DOCKHDPC
This TAA compliant dual-monitor USB 3.0 docking station combines a 4-port USB 3.0 hub, headphone and
microphone audio connectors, a USB fast-charge port, and a GbE RJ45 Port with Wake-on-LAN (WOL).
www.startech.com
1 800 265 1844
4K Ultra HD Resolutions
This 4K USB docking station supports DisplayPort plus HDMI dual video, or a single DP display at 4K Ultra
HD resolutions (3840 x 2160p).
Maximum Supported Resolutions*
Video Output Configuration Max DisplayPort Resolution Max HDMI Resolution
DisplayPort
(Single Display)
3840 x 2160p (4K) N/A
HDMI
(Single Display)
N/A 2560 x 1440p
DisplayPort and HDMI
(Two Displays)
2048 x 1152p 2048 x 1152p
*Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports
2560 x 1600p and 2560 x 1440p.
Integrated USB 3.0 Hub
The built-in USB hub features four USB 3.0 ports for connecting extra peripherals such as external hard
drives or a wired mouse as if they are connected directly to your laptop.
USB Fast Charge
The USB 3.0 dock’s always-on USB fast-charge port charges devices without a laptop connection and
supports USB Battery Charging Specification 1.2 making it easy to charge your tablets and other mobile
devices.
www.startech.com
1 800 265 1844
Direct Ethernet Connectivity
The integrated RJ45 Ethernet port supports speeds of 10/100/1000Mbps, giving you an instant connection
to a reliable wired network.
Easy to Use
This docking station with DisplayPort and HDMI is universally compatible, working with Mac and
Windows® USB 3.0 equipped laptops and includes a 2ft. USB 3.0 cable for quick setup.
StarTech.com laptop docking stations can be used for cost savings and faster deployment with just a
single cable. This USB 3.0 docking station is backed by a competitive 3-year warranty and free lifetime
multilingual Technical Support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Classrooms
• Computer Labs
• Network and Systems Administration
Features
• Connect dual monitors (HDMI and 4K DP) to your Mac or Windows
laptop
• Achieve a higher resolution with up to 3840x2160p on a single
display
• Maximize your display capabilities with dual displays at 2048x1152p
resolutions
• Connect more devices with 4 x USB 3.0 ports
• Charge your mobile devices with built-in USB fast-charge port
www.startech.com
1 800 265 1844
Warranty 3 Years
Hardware 4K Support Yes
Bus Type USB 3.0
Chipset ID DisplayLink - DL-5900
VIA/VLI - VL812
Displays Supported 2
Fast-Charge Port(s) Yes
Industry Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB Battery Charging Specification Rev. 1.2
USB 3.0 - Hub ports support USB 2.0/1.1 backwardcompatibility
Performance Auto MDIX Yes
Compatible Networks 10/100/1000 Mbps
Full Duplex Support Yes
Maximum Data Transfer Rate 5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions 3840x2160 @ 30Hz / 2560x1600 / 2560x1440 (DisplayPort
- Single Display)
2560x1440 (HDMI - Single Display)
2048x1152 & 2048x1152 (DisplayPort & HDMI - Two
Displays)
Type and Rate USB 3.0 - 5 Gbit/s
UASP Support Yes
Connector(s) Connector Type(s) 1 - DisplayPort (20 pin) Female
1 - HDMI (19 pin) Female
1 - USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 - USB Type-A (9 pin) USB 3.0 Female
1 - RJ-45 Female
1 - 3.5 mm Mini-Jack (4 Position) Female
1 - USB Type-B (9 pin) USB 3.0 Female
1 - Security Lock Slot Female
Software OS Compatibility Windows® 7, 8, 8.1, 10
macOS 10.8 - 10.12, 10.14
Chrome OS™ v55+
www.startech.com
1 800 265 1844
Special Notes /
Requirements
System and Cable Requirements DisplayPort display must support 4K resolutions
If connected to a USB 2.0 host port, or if using a USB 2.0
host connection cable, performance may be limited (USB 3.0
host cable included)
Indicators LED Indicators 1 - Link (Green)
1 - Activity (Yellow)
Power Input Current 1.5 A
Input Voltage 100 ~ 240 AC
Output Current 6.5 A
Output Voltage 5 DC
Plug Type 4-pin DIN
Power Consumption (In Watts) 32.5
Power Source AC Adapter Included
Environmental Humidity 90% RH
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 80°C (14°F to 176°F)
Physical
Characteristics
Cable Length 2 ft [0.6 m]
Color Black
Enclosure Type Steel and Plastic
Product Height 0.9 in [24 mm]
Product Length 8.9 in [227 mm]
Product Weight 9.8 oz [277 g]
Product Width 3 in [76 mm]
Packaging
Information
Shipping (Package) Weight 2.4 lb [1.1 kg]
What's in the Box Included in Package 1 - USB 3.0 Laptop Docking Station
1 - 2ft USB 3.0 Cable
1 - Universal Power Adapter
4 - Power Cords (NA/JP, EU, UK, ANZ)
1 - Driver CD
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
