Startech USB32DPES2 User Manual

USB to DisplayPort Adapter - USB 3.0 - 4K 30Hz
Product ID: USB32DPES2
This USB to DisplayPort adapter lets you connect your computer to a 4K DisplayPort monitor using a USB
3.0 Type-A port, even if your computer doesn’t support 4K video.
www.startech.com
1 800 265 1844
Increase your productivity by adding a 4K display
This USB to DP adapter can boost your productivity by providing more screen space to work with. Having
you to reference material on one display while composing on another. The adapter even supports display
rotation for a vertical screen that’s ideal for viewing spreadsheets, newsfeeds or stock tickers.
Easy-to-install
The multi-monitor adapter is powered by your computer's USB Type-A port, so you won’t need to connect
a bulky external power adapter. Plus, the drivers install quickly and easily and only need to be installed
once, regardless of how many USB video adapters you want to connect.
Get astonishing picture quality with 4K video
Even if your system doesn’t natively support 4K video output, this USB video adapter lets you enjoy the
picture quality of Ultra HD video. With support for 4K at 30Hz, you get sharp and crisp picture quality
that’s richer and more true-to-life than traditional HD, with far greater detail in both darker and brighter
images.
The USB32DPES2 is backed by a 2-year StarTech.com warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
Applications
Mirror or extend your desktop onto an additional display
View large spreadsheets, or several spreadsheets, across multiple displays
View data on multiple screens, such as newsfeeds and stock tickers
Features
Be more productive by multitasking on an additional, independent display
Get exceptional USB video performance with support for video resolutions up to 4K 30Hz
Install easily with no external power adapter required
2-channel (stereo audio) support
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Audio Yes
Chipset ID MCT - T6-688L
Memory DDR 4Gb
Output Signal DisplayPort
Ports 1
USB Pass-Through No
Performance Audio Specifications 2-channel stereo
General Specifications This USB video adapter uses a Trigger family chipset. If
you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Maximum Digital Resolutions 4K x 2K @ 30Hz
Supported Resolutions Widescreen(16/32 bit):
3840×2160, 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720
Standard(16/32 bit): 1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640X480
Wide Screen Supported Yes
Connector(s) Connector A 1 - USB Type-A (9 pin) USB 3.0 Male Input
Connector B 1 - DisplayPort (20 pin) Female Output
Software Microsoft WHQL Certified Yes
OS Compatibility Windows® 10 (32/64)
Windows 8 / 8.1 (32/64) Windows 7(32/64)
Special Notes / Requirements
Note This USB video adapter uses a Trigger family chipset. If
you’re connecting this device to a computer along with additional USB video adapters or docking stations, avoid using devices with different family chipsets, such as DisplayLink® or Fresco Logic®
This USB video adapter is not intended for graphical intensive applications
www.startech.com
1 800 265 1844
System and Cable Requirements For 1 ~ 2 video adapters
- CPU: Intel® Core™ i3 2.8 GHz or equivalent (Core i5 recommended for HD video)
- RAM: 2 GB or more (4 GB recommended for HD video)
For 3 ~ 4 video adapters
- CPU: Intel Core i5 Quad Core 2.8 GHz or equivalent
- RAM: 4 GB or more
For 5 video adapters
- CPU: Intel Core i7 Quad Core 3.0 GHz or equivalent
- RAM: 8 GB or more
Power Power Source USB-Powered
Environmental Humidity < 85% non-condensing
Operating Temperature 0°C to 45°C (32°F to 133°F)
Storage Temperature -15°C to 75°C (5°F to 167°F)
Physical Characteristics
Cable Length 2.4 in [62 mm]
Color Black
Enclosure Type Plastic
Product Height 7.7 in [195 mm]
Product Length 3.5 in [88 mm]
Product Weight 1.5 oz [43 g]
Product Width 0.6 in [14 mm]
Packaging Information
Shipping (Package) Weight 0.4 lb [0.2 kg]
What's in the Box Included in Package 1 - USB video adapter
1 - quick-start guide
Product appearance and specifications are subject to change without notice.
