Dual HDMI over CAT6 Extender - 1080p
Product ID: ST222HDBT
This HDMI® over CAT6 extender lets you extend two HDMI sources up to 90 m (295 ft.), to individual
HDMI displays over a single CAT6 cable. Designed for a simple, tidy setup, the extender also supports bi-
directional IR control for added flexibility.
Dual source support
Reduce the need for additional equipment and cables, by extending two HDMI connections with a single
CAT6 cable. Running only one cable can save cost on installation or enable you to extend two HDMI
signals using an existing cable run. You can also use this 1080p HDMI extender to run separate video
signals to the same display, for mission critical digital signage applications where if one signal goes down,
the other can easily be swapped in it's place.
www.startech.com
1 800 265 1844
Bi-directional control
With bi-directional IR control, you can control your devices from either end of the extension, such as a
Blu-ray™ player and laptop on one end and two TV displays on the other. The extender includes an IR kit
with discreet dongles that easily connect to both your transmitter and receiver, enabling you to remotely
control any device you choose from either side of your extension.
Simplified setup
The simplicity of one-cable setup avoids the hassle of running multiple cables, while also reducing
potential failure points. The included mounting hardware offers professional mounting options ideal for
public spaces such as offices or auditoriums.
The TAA compliant ST222HDBT is backed by a 2-year StarTech.com warranty and free lifetime technical
support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Great for tradeshows where multiple remote source devices need to
be placed out of sight
• Ideal for auditoriums, lecture halls or other professional presentation
venues, where a discreet setup is required
Features
• Extend two separate HDMI sources to their own HDMI 1080p displays
with one CAT6 cable
• Support for bi-directional IR signals, for remote control from either
end of your extension
• Extend two 1080p source signals up to 90 m (295 ft.)
• Includes mounting brackets
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Audio Yes
AV Input HDMI
Toslink
3.5 mm Audio
AV Output HDMI
Toslink
3.5 mm Audio
Cabling Cat 5e UTP or better
Chipset ID VS2310TX
VS2310RX
Daisy-Chain No
Ports 2
Performance Audio Specifications 7.1 Surround Sound
Max Distance 90 m / 295 ft
Maximum Cable Length 295.2 ft [90 m]
Maximum Digital Resolutions 1920x1080 (1080p) @ 60 Hz
Supported Resolutions 1920x1080 (1080p)
1280x720 (720p)
Wide Screen Supported Yes
Connector(s) Connector A 2 - HDMI (19 pin) Female Input
1 - Toslink (SPDIF, Optical) Female Input
1 - 3.5 mm Audio Female Output
1 - 3.5 mm Audio Female Input
1 - DB 9-pin Serial Male
1 - Infrared Female Input
1 - Infrared Female Output
1 - RJ-45 Female Output
Connector B 2 - HDMI (19 pin) Female Output
1 - Toslink (SPDIF, Optical) Female Output
1 - 3.5 mm Audio Female Output
1 - 3.5 mm Audio Female Input
1 - DB 9-pin Serial Male
www.startech.com
1 800 265 1844
1 - Infrared Female Output
1 - Infrared Female Input
1 - RJ-45 Female Input
Indicators LED Indicators 1 - Link / Status
Power Input Voltage 100 ~ 240 AC
Output Current 1.5 A
Output Voltage 12 DC
Plug Type M
Environmental Humidity 0% to 80% RH (non-condensing)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Physical
Characteristics
Product Height 1.7 in [43 mm]
Product Length 6.2 in [158 mm]
Product Weight 7.1 oz [200 g]
Product Width 5.1 in [130 mm]
Packaging
Information
Shipping (Package) Weight 9 oz [256 g]
What's in the Box Included in Package 1 - HDMI transmitter
1 - HDMI receiver
2 - universal power adapters (NA/JP, EU, UK, ANZ)
2 - sets of mounting brackets
1 - IR blaster
1 - IR receiver
1 - CAT5 cable
8 - rubber feet
1 - user manual
Product appearance and specifications are subject to change without notice.
