4K HDMI Splitter - HDMI Splitter 1 In 4 Out - 4-Port
- 4K 60Hz
Product ID: ST124HD20
This 4K HDMI splitter lets you connect your HDMI video source to four HDMI displays, with support for
Ultra HD resolutions and HDR (High Dynamic Range) as well as 7.1 surround sound audio.
Unlike many 4K splitters that only support a 30Hz refresh rate, this splitter works with 4K HDMI 2.0
displays with output resolutions of up to 3840 x 2160p at 60Hz.
Supports true 4K at 60Hz
Not all 4K splitters are created equal. While some HDMI 1.4 splitters can achieve 4K resolutions, they'll
only work at a 30Hz refresh rate. Other HDMI 1.4 splitters are marketed as 4K at 60Hz, but their color
data is reduced to a lower 4:2:0 chroma subsampling. This drastically reduces color quality in order to
achieve 4K at 60Hz resolution, even with limited HDMI 1.4 bitrate capabilities.
www.startech.com
1 800 265 1844
This 4K 60Hz HDMI splitter offers full support for your HDMI 2.0 equipment, including true 4K resolution
at 60Hz. For smoother video and color transitions, the splitter offers 4:4:4 chroma subsampling, meaning
every pixel gets its own unique color. Support for HDMI 2.0 devices means this splitter can transmit
bandwidth up to 18Gbps, making it the ideal solution for high-resolution tasks requiring the highest color
detail.
Widely compatible
The splitter supports HDCP 2.2 and is backward compatible with 4K 30Hz and 1080p displays. This
ensures that it will work with lower resolution displays such as TVs or projectors around your site or in
your digital signage application.
Easy installation and setup
For hassle-free setup, the 4K HDMI splitter offers easy plug-and-play installation with no additional
software or drivers required. The splitter passes EDID between your video source and the display attached
to port 1, ensuring native settings such as resolution and refresh rate are configured automatically.
Mounting hardware is also included, for a tidy and professional installation.
The ST124HD20 is backed by a 2-year StarTech.com warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Output and split your 4K 60Hz HDMI signal to two different HDMI
displays
• Distribute 4K60 video to computer monitors that require the highest
quality of image detail, such as in control centers or video production
studios
• Display corporate information or advertising on multiple displays at a
shopping center
• Display the same information on multiple displays in the waiting
rooms of healthcare facilities
Features
• Astonishing picture quality with support for 4K 60Hz and HDR
• Support for 7.1 surround sound audio
• Tidy, professional installation with mounting hardware included
• Supports 4:4:4 chroma subsampling even at 4K 60Hz with bandwidth
up to 18Gbps
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Audio Yes
Industry Standards HDMI 2.0
Output Signal HDMI
Ports 4
Performance Audio Specifications 7.1 surround sound
Maximum Analog Resolutions 4K @ 60Hz
Maximum Digital Resolutions 3840x2160 (4K) @ 60Hz
2560x1600
1920x1200
1920x1080 (1080p)
1280x720 (720p)
Wide Screen Supported Yes
Connector(s) Connector A 1 - HDMI (19 pin) Female Input
Connector B 4 - HDMI (19 pin) Female Output
Indicators LED Indicators 1 - power LED
1 - input LED
4 - output LEDs
Power Input Current 0.2
Input Voltage 100 ~ 240 AC
Output Current 1 A
Output Voltage 5 DC
Environmental Humidity 5.±8 kV (air-gap discharge) ±4 kV (contact discharge)
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Physical
Characteristics
Color Black
Product Height 0.7 in [17 mm]
Product Length 6.5 in [165 mm]
Product Width 2.5 in [64 mm]
Packaging
Information
Shipping (Package) Weight 0.2 lb [0.1 kg]
What's in the Box Included in Package 1 - HDMI video splitter
1 - universal power adapter (NA, EU, UK, ANZ)
www.startech.com
1 800 265 1844
1 - quick-start guide
Product appearance and specifications are subject to change without notice.
