VGA to Cat 5 Monitor Extender Kit (250ft/80m) - VGA Cat5 Extender
StarTech ID: ST121UTPEP
The ST121UTPEP VGA Video Extender over Cat5 - Point to Point lets you connect a remote VGA
display/projector up to 80m (250ft) away from the VGA signal source. The ST121UTPEP is a bundled kit that
includes both a local and a remote unit providing a complete end to end solution for a single source/display
connection, transmitting the source VGA signal over a standard Ethernet cable (Cat5e or better UTP cable,
terminated with RJ45 connectors).
Offering convenient and cost-effective VGA distribution, the ST121UTPEP only requires one power adapter
which can be installed at either the local or remote end of the connection, depending on what is most convenient
for your application.
To ensure a tidy installation, the ST121UTPEP includes a mounting bracket for the receiver to help eliminate
unnecessary cable tangles.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Place the display in a convenient viewing area, while the system equipment is placed elsewhere in a
clean and secure environment
Ideal for digital signage applications in financial, educational, and business sectors
Extend your display across harsh environment industrial sites
Perfect for video conferencing solutions in boardrooms and office settings
Optimize placement of your demo stations at tradeshows and in auditoriums
www.startech.com
1 800 265 1844
Features
Extends video signal by up to 250 ft. (80m)
Supports 1920x1200 or 1600x1200 resolutions at 150 ft. (50m)
Supports 1280x1024 or 1024x768 resolutions at 250 ft. (80m)
Mounting bracket included
Single power adapter can be connected at local or remote end of the extension
Uses standard Cat 5 or better cabling
Kit consists of 1 Base unit and 1 Remote unit
Pure hardware design - no software or drivers required
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Audio No
Cabling Cat 5 UTP
Daisy-Chain No
Ports 1
Max Distance 80 m / 260 ft
Supported Resolutions 1920x1200 @ 50m(164ft)
1280x1024 @ 80m(260ft)
Local Unit Connectors 1 - RJ-45 Female
Local Unit Connectors 1 - VGA (15 pin; High Density D-Sub) Female
Remote Unit
Connectors
1 - RJ-45 Female
Remote Unit
Connectors
1 - VGA (15 pin; High Density D-Sub) Female
Note Resolution may vary at distances depending on cable quality. Cat 5e UTP cables are
recommended.
Color Black
Enclosure Type Aluminum
Product Height 1 in [25 mm]
Product Length 3.9 in [100 mm]
Product Weight 1.3 oz [36 g]
Product Width 5.4 in [138 mm]
Center Tip Polarity Positive
Output Current 0.6A
Output Voltage 12 DC
Power Source AC Adapter Included
Shipping (Package)
Weight
2.7 lb [1.2 kg]
Included in Package 1 - VGA over Cat5 Transmitter
Included in Package 1 - VGA over Cat5 Receiver
Included in Package 1 - Installation Bracket (w/ screws)
Included in Package 1 - VGA Cable
Included in Package 1 - Universal Power Adapter (NA/UK/EU/AUS)
Included in Package 1 - Instruction Manual
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
