Startech SATDOCK2REU3 User Manual
USB 3.0 SATA HDD/SSD Dock 1:1 Duplicator
SATDOCK2REU3
*actual product may vary from photos
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
For the latest information, technical specications, and support for
this product, please visit www.startech.com/SATDOCK2REU3.
Manual Revision: 06/09/2016
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by StarTech.com could void the user’s
authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
Instruction manual
IC Radiation Exposure Statement
This equipment complies with IC RSS-102 radiation exposure limit set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 0.5cm between the radiator and your body.
Déclaration d’exposition à la radiation
Cet équipement respecte les limites d’exposition aux rayonnements IC dénies pour un
environnement non contrôlé. Cet équipement doit être installé et mis en marche à une
distance minimale de 0.5 cm qui sépare l’élément rayonnant de votre corps.
L’émetteur ne doit ni être utilisé avec une autre antenne ou un autre émetteur ni se trouver
à leur proximité.
FCC ID:xxx
IC:xxx
The Country Code Selection feature is disabled for products marketed in the US/Canada
The device, for operation in the band 5150–5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction manual
Table of Contents
Introduction ............................................................................................1
Packaging contents .................................................................................................................................. 1
System requirements ...............................................................................................................................1
Product diagram ....................................................................................2
Front view ....................................................................................................................................................2
Rear view ...................................................................................................................................................... 2
Top view .......................................................................................................................................................3
Using the SATDOCK2REU3 as a dock ..................................................4
Connect the SATDOCK2REU3 to a computer ..................................................................................4
Install a drive ............................................................................................................................................... 4
Prepare the drive for use ........................................................................................................................4
About driver installation ......................................................................................................................... 5
Remove a drive .......................................................................................................................................... 5
About the dock LED indicators ............................................................................................................ 6
Duplicating drives ..................................................................................7
Duplicate a drive ....................................................................................................................................... 7
About the duplication LED indicators ............................................................................................... 7
Erasing drives..........................................................................................8
Erase a drive ................................................................................................................................................ 8
About the erase LED indicators ............................................................................................................8
Technical support ................................................................................... 9
Warranty information ............................................................................9
Instruction manual
i
Introduction
You can use the SATDOCK2REU3 to connect your 2.5 in. or 3.5 in. SATA HDDs or SSDs
through USB 3.0 and swap drives in and out as you need to. The SATDOCK2REU3 also
functions as a standalone drive duplicator and eraser, providing an ecient and a
versatile solution to help you manage your external drives.
Packaging contents
• 1 x HDD dock duplicator and eraser
• 1 x USB 3.0 cable
• 1 x universal power adapter
• 4 x power cords (NA/JP, UK, EU, AU)
• 1 x user manual
System requirements
Drive duplication
• 2.5 in. or 3.5 in. source and destination drives
Interfacing with a computer
• USB-enabled computer system with a USB port
Operating system requirements are subject to change. For the latest requirements,
please visit www.startech.com/SATDOCK2REU3.
Instruction manual
1
