M.2 to SATA SSD adapter – expansion slot mounted
StarTech ID: S32M2NGFFPEX
The S32M2NGFFPEX M.2 to SATA adapter lets you connect a SATA M.2 (NGFF) SSD to a standard SATA
port, and mount the drive into any desktop expansion slot.
Now, you can greatly increase the performance of your desktop computer by replacing your platter drive with a
fast M.2 NGFF solid state drive. By installing your primary operating system on the M.2 SSD drive and using
your higher-capacity platter HDD for bulk storage, you can harness the speedy performance of the M.2 drive for
frequently accessed data while storing files you access less often on your platter drive.
For a hassle-free installation, the adapter mounts into any new or legacy desktop expansion slot, with support
for AGP, PCI, and PCIe slots. The adapter also includes full-profile and low-profile brackets, ensuring
compatibility with both full-sized and small form factor desktops.
The S32M2NGFFPEX is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Install your primary operating system on a faster SSD drive, and keep your larger standard HDD in the
same system for bulk storage
Connect an unused M.2 drive to your computer system using an available expansion slot
Recover data from an M.2 drive by connecting it to a standard SATA computer system
www.startech.com
1 800 265 1844
Features
Add SSD performance to any desktop computer system by converting M.2 to SATA
Optimize performance with support for SATA III transfer speeds, up to 6 Gbps
Wide installation compatibility with support for the most common M.2 drives (2230, 2242, 2260, 2280)
Includes both low-profile, and full-profile expansion slot brackets
Supports SATA I,II,III drives (1.5/3.0/6.0 Gbps)
PCI/PCIe slot compatible
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Compatible Drive Types (Type and Rate) M.2 (NGFF; B Key)
Drive Installation Fixed
Interface SATA
Number of Drives 1
Supported Drive Height(s) 2230
Supported Drive Height(s) 2242
Supported Drive Height(s) 2260
Supported Drive Height(s) 2280
General Specifications Not compatible with PCI-Express M.2 SSDs
Maximum Data Transfer Rate 6 Gbps
Type and Rate SATA III (6 Gbps)
Drive Connectors 1 - M.2 (NGFF; B Key) Receptacle
Host Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle
Product Height 3.7 in [95 mm]
Product Length 4.7 in [120 mm]
Product Weight 4.6 oz [130 g]
Product Width 0.7 in [18 mm]
Humidity 5% to 95% RH
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -10°C to 85°C (14°F to 185°F)
Shipping (Package) Weight 5.3 oz [150 g]
Included in Package 1 - SATA to M.2 NGFF SSD Adapter
Included in Package 1 - Full profile bracket (pre-installed)
Included in Package 1 - Low profile bracket
Included in Package 1 - SSD installation screw
Included in Package 1 - Screw driver
Included in Package 2 - Standoffs (for PCI slot installation)
