Startech S2510BMU33 User Manual

2.5in Aluminum USB 3.0 External SATA III SSD Hard Drive Enclosure with UASP for SATA 6 Gbps – Portable External HDD
Product ID: S2510BMU33
The S2510BMU33 USB 3.0 Hard Drive Enclosure with UASP lets you connect a 2.5in SATA III hard drive
(HDD) or solid state drive (SSD) through an available USB port. The enclosure delivers optimal
performance with a USB 3.0 connection, but is backward compatible with USB 2.0/1.1 host connections as
well.
faster than conventional USB 3.0 when paired with a UASP-enabled host controller. Using a more efficient
protocol than the traditional USB BOT (Bulk-Only Transport), UASP reduces latency, significantly
increasing transfer speeds and reducing processor usage to utilize the full potential of your SATA III hard
drives. See our UASP testing results below for further details.
With support for SATA I/II/III, and large capacity drives (tested up to 1TB) this HDD enclosure is
compatible with virtually any 2.5in SATA hard drive, and greatly increase the
storage/backup capabilities of your computer.
www.startech.com
1 800 265 1844
The USB 3.0/SATA III enclosure requires no external power adapter and features high quality aluminum
construction, ensuring both portability and durability when carried as a laptop accessory.
To ensure compatibility with your computer system, the S2510BMU33 supports all of the leading
operating systems, including: Microsoft Windows® (8/7/Vista/XP/Server 2008/Server 2003), Apple® OSX
(10.9/10.8/10.7/10.6), Linux, and Google Chrome OS™.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Improved Performance with UASP
UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing UASP performs with a
70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.
At the same peak in testing UASP also shows an
80% reduction in required processor resources.
Testing results were obtained using an Intel® Ivy
Bridge system, a UASP enabled StarTech.com
enclosure, and a SATA III solid state drive.
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
Applications
Take advantage of new laptops and desktops with USB 3.0 (UASP) connectivity
Create a fast, portable external storage solution for desktops, laptops or netbooks
Upgrade from a USB 2.0 drive enclosure to faster USB 3.0
Add extra storage to almost any USB enabled computer system
Back up important data to an external storage device
Share large files between computers quickly and securely without a network
Retrieve data from old SATA drive, or turn the unused drive into additional external storage space
Features
Compliant with USB Attached SCSI Protocol (UASP) Transport Specifications
Compatible with SATA revision I/II/III (1.5/3.0/6.0 Gbps) drives
Light weight and durable aluminum enclosure
Powered directly from the USB port
SuperSpeed USB 3.0 compliant host interface supporting data transfer rates up to 5Gbps
High Speed USB 2.0 compliant host interface, with transfer rates up to 480Mbps
Power/Activity LED indicator
Plug-and-Play and Hot-Swap compatible
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Chipset ID ASMedia - ASM1053 - 6G
Compatible Drive Types (Type and Rate)
SATA
Drive Installation Fixed
Drive Size 2.5in
Fan(s) No
Interface USB 3.0
Number of Drives 1
Performance Max Drive Capacity Currently tested with up to 1TB 5400 RPM hard drives
RAID No
Type and Rate USB 3.0 - 5 Gbit/s
SATA III (6 Gbps)
UASP Support Yes
Connector(s) Drive Connectors 1 - SATA Data & Power Combo (7+15 pin) Female
Host Connectors 1 - USB 3.0 Micro-B (10 pin, SuperSpeed) Female
Software OS Compatibility OS independent; No software or drivers required
Special Notes / Requirements
System and Cable Requirements Available USB port
Indicators LED Indicators 1 - Power & Activity
Power Power Source USB-Powered
Environmental Humidity Operation Humidity: 10% ~ 90% RH
Storage Humidity: 5% ~ 95% RH
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 65°C (14°F to 149°F)
Physical Characteristics
Color Black
Enclosure Type Aluminum and Plastic
Max Drive Height 0.4 in [9.5 mm]
Product Height 0.6 in [15.5 mm]
Product Length 4.7 in [120 mm]
Product Weight 4.6 oz [130 g]
Product Width 3 in [77 mm]
www.startech.com
1 800 265 1844
Packaging Information
Shipping (Package) Weight 0.5 lb [0.2 kg]
What's in the Box Included in Package 1 - 2.5” USB 3.0 SATA III HDD Enclosure
1 - Screw Kit
1 - 18" USB 3.0 Cable
1 - Product Manual
Product appearance and specifications are subject to change without notice.
