Juniper RX-FXSM-SFP Compatible SFP Transceiver
Module - 100Base-LX10
Product ID: RXFXSMSFPST
The RXFXSMSFPST is a Cisco SFP-10G-ER compatible fiber transceiver module that has been designed,
programmed and tested to work with Cisco brand switches and routers. It delivers dependable 100 MbE
connectivity over fiber cable, for 100Base-LX10 compliant networks, with a maximum distance of up to 40
km (24.8 mi).
Technical Specifications:
• Wavelength: 1310nm
• Maximum Data Transfer Rate: 100 Mbps
• Type: Single Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 10 km (6.2 mi)
• MTBF: 53,972,659 hours
• Power Consumption: < 1.3W
• Digital Diagnostics Monitoring (DDM): Yes
www.startech.com
1 800 265 1844
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing
network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime
multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP
cables, providing the convenience and reliability you need to ensure dependable network performance.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Features
• 100% Compatibility with Juniper RX-FXSM-SFP guaranteed
• StarTech.com SFP modules are backed by a lifetime warranty
• Meets or exceeds OEM specifications and Multi-Source Agreement
(MSA) industry standards
• Low power consumption of < 1.3W
• Hot-swappable with fiber-optic modules
www.startech.com
1 800 265 1844
Warranty Lifetime
Hardware Compatible Brand Juniper®
Performance Fiber Operating Mode Full-Duplex
Max Transfer Distance 10 km (6.2 mi)
Maximum Data Transfer Rate 155 Mbps
Wavelength 1310nm
Connector(s) Connector A 1 - SFP Slot Plug Output
Connector B 1 - Fiber Optic LC Duplex Female
Physical
Characteristics
Product Height 0.5 in [1.2 cm]
Product Length 2.6 in [65 mm]
Product Width 0.6 in [14 mm]
Weight of Product 2.5 oz [72 g]
Packaging
Information
Package Height 0.6 in [15 mm]
Package Length 9.1 in [230 mm]
Package Width 8.1 in [207 mm]
Shipping (Package) Weight 2.8 oz [80 g]
What's in the Box Included in Package 1 - SFP Transceiver
Product appearance and specifications are subject to change without notice.
