1U Rack-Mount Light Panel - Dimmable LEDs, with
Flexible Gooseneck Arms
Product ID: RKPNLLT
This 1U rack-mount light panel installs into any EIA-310 compliant cabinet and enables you to complete
tasks inside your server rack that require lighting. The panel mounts into 1U of rack space in any standard
19 in. rack and features two adjustable gooseneck lights, each 17 in. (432 mm) in length. For easy
installation, the light panel also includes a 5 ft. (1.5 m) power cord that can easily reach a PDU that's
mounted inside of your rack.
Target illumination with adjustable lights
This rack-mount light enables you to direct light exactly where you need it. The lamp features two easy-
to-adjust lights that can be positioned independently with flexible gooseneck arms. You can also direct the
lights so they’ll work together, to intensify the light in a specific location.
The gooseneck design provides virtually limitless movement and easily bends 360 degrees in any
direction. The lights tilt, turn and rotate, so you can instantly switch from any position, and back again.
www.startech.com
1 800 265 1844
Precise lighting control, with dimming and power switches
For simple operation, the rack-mount light features a dimming dial, which makes it easy for you to adjust
the light to the perfect settings. Unlike some rack-mount lighting systems that require you to physically
disconnect the power cable in order to turn them off, this LED rack light features a built-in on/off switch.
Save energy with LED lights
The 1U rack light features LED lights which are long lasting and emit very little heat, unlike some systems
that use incandescent lighting. With this rack-mount light, you can be confident your equipment won’t
overheat due to residual heat generated from your lighting.
The RKPNLLT is backed by a 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Install into your server rack to easily see equipment
• Ideal for multimedia cabinets in dark settings
Features
• Direct light exactly where you need it with two easy-to-adjust lights
on independent gooseneck arms
• Get perfect illumination with a dimming dial that adjusts the intensity
of both lights
• Save energy and be confident that your equipment won’t overheat,
with LED lights
• Features an on/off switch making it easy to control
• Installs into only 1U of space
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Industry Standards EIA-310-D
Mounting Holes Slot
Number and Type of Included Cage
Nuts
4 - M5
U Height 1U
Performance Maximum Arm Extension 17 in [432 mm]
Power Center Tip Polarity Positive
Input Current 0.4 A
Input Voltage 12 AC
Output Current 0.5 A
Output Voltage 12 DC
Power Source AC Adapter Included
Physical
Characteristics
Cable Length 60 in [152.4 cm]
Product Height 1.7 in [44 mm]
Product Length 19 in [482.6 mm]
Product Weight 24.4 oz [690 g]
Product Width 2.2 in [55 mm]
Packaging
Information
Shipping (Package) Weight 1.6 lb [0.7 kg]
What's in the Box Included in Package 1 - light panel
4 - M5 cage nuts
4 - M5 screws
1 - universal power adapter (NA/JP, UK, EU, ANZ)
Product appearance and specifications are subject to change without notice.
