6 ft. (1.8 m) USB KVM Cable for StarTech.com
Rackmount Consoles
Product ID: RKCONSUV6
This 6 ft. (1.8 m) USB KVM Cable enables your StarTech.com Rackmount LCD console and KVM
switch kit to conveniently operate your VGA and USB-equipped server.
This line of KVM cables are available in variable lengths, and are the only cables engineered for
guaranteed compatibility with the StarTech.com line of RKCONS series of Rackmount Consoles and KVM
switches. Supported models of Rackmount LCD Consoles are: RKCONS1701,
RKCONS17HD, RKCONS1708K, RKCONS1716K, RKCONS1901, RKCONS1908K, RKCONS1916K.
Engineered to Keep Your Server Room Tidy
This KVM cable has been specifically designed for the StarTech.com line of Rackmount KVM and Console
kit. The USB and VGA KVM cord is wired with a unique schematic that enables a single connector on
the KVM to interface with both VGA and USB on your server. This space-saving design
dramatically reduces cable-clutter in your server rack, and ensures a tidy, professional server room.
www.startech.com
1 800 265 1844
Crystal-Clear Picture Quality
When connected to an HD rackmount console, the 6-foot KVM cable supports HD resolutions up to
1920x1200 including 1080p, maintaining the quality of your server’s video card to deliver every detail in
high-definition.
Available in Different Lengths
To support the complexities and demands of your data center, this 6 foot (1.8 meter) KVM cable is also
available as a 10 foot 3 meter KVM Cable (RKCONSUV10), and a 15 foot (4.6 meter) KVM
cable (RKCONSUV15).
The RKCONSUV6 is backed by a StarTech.com Lifetime warranty and free technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Connect severs to your StarTech.com Rackmount KVM console
• Keep replacement cables on hand to ensure continuous control of
your mission critical servers
Features
• Maintain your clutter-free server room with a VGA and USB KVM
cable that combines into a single connector on the KVM side
• Get crystal-clear picture quality with support for HD resolutions up to
1920x1200 or 1080p
• Accommodate variable rack configurations, with cables available in
different lengths
www.startech.com
1 800 265 1844
Warranty Lifetime
Hardware Cable Jacket Type PVC - Polyvinyl Chloride
Cable Shield Type Aluminum-Mylar Foil with Braid
Connector Plating Nickel
Connector(s) Connector A 1 - VGA (14 pin, High Density D-Sub) Male
Connector B 1 - USB Type-A (4 pin) USB 2.0 Male
1 - VGA (15 pin, High Density D-Sub) Male
Physical
Characteristics
Product Height 0.6 in [1.5 cm]
Product Length 6 ft [1.8 m]
Product Width 1.2 in [3 cm]
Weight of Product 8.6 oz [245 g]
Packaging
Information
Package Height 7.9 in [200 mm]
Package Length 8.7 in [22 cm]
Package Width 0.4 in [1 cm]
Shipping (Package) Weight 8.8 oz [250 g]
What's in the Box Included in Package 1 - KVM Cable
Product appearance and specifications are subject to change without notice.
