Startech RACKCOND1701 User Manual

1U 17” HD 1080p Dual Rail Rackmount Widescreen LCD Console

StarTech ID: RACKCOND1701

The RACKCOND1701 1U 17-inch Rack Mount LCD Console Drawer offers a high resolution LCD display, full
keyboard and touchpad console, allowing you to centrally manage and monitor your servers and KVM switches
using a space-saving 1U of rack space.

The LCD Console drawer features an innovative dual-rail system that allows the display to slide independently from
the keyboard/touchpad tray, giving system administrators the ability to use the device as a monitoring station while
the keyboard is neatly tucked away inside the rack. Unlike other 17-inch LCD Rack Consoles, this unit supports
VGA resolutions up to 1920x1080 for crystal clear high definition display, while an LED Backlight reduces power
consumption by up to 50%.

The Rack Console features an integrated single port KVM module enabling direct connections to a single system or
to KVM switches in a cascaded configuration for centralized control of multiple systems.

Backed by a StarTech.com 3-year warranty and free lifetime technical support.

Applications

Perfect for racks with acrylic or glass doors where you can close the rack and leave the display visible, for
easy and secure monitoring
Ideal for high resolution applications in the server room, where the previous standard 1024x768 17" screens
are not sufficient
Centralized control of dozens of PCs and servers when used with the integrated KVM console (optional)
Improving the internal space-efficiency of existing cabinets
Manage cabinet-mounted servers and KVM switches

Features

Dual-rail console design allows LCD display and keyboard/mouse to slide independently
Supports HD resolutions up to 1920x1080
Durable 1U rack mountable design
LED Backlight; reduced power consumption
Security features include port locking and auto scan
On Screen Display (OSD) control and LED indicators for easy monitoring
Embedded USB-A connectors support wireless keyboard / mouse, or keyboard/mouse combo kits
Integrated 106-key US standard keyboard with touchpad
