Startech NETRS2321POE User Manual

1 Port RS232 Serial Ethernet Device Server - PoE Power Over Ethernet
StarTech ID: NETRS2321POE
The NETRS2321POE 1 Port RS232 Serial Ethernet Device Server - PoE (Power Over Ethernet) allows you to install your RS232 devices anywhere on your TCP/IP Ethernet WAN/LAN, and access them as if they were right beside you - even over the Internet!
The Serial Device Server is designed to function seamlessly with your other integrated and add-on serial ports as if they were right inside your computer. Perfect for industrial automation, security, Point of Sale, or any long­range serial application, delivering reliable performance in any environment.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Manufacturing (CNC machinery, process control equipment, bar code scanners, serial printers) Security (UPS control, access key panels, video cameras, card readers) Environmental Control (lighting, temperature, clocks) POS (credit/debit card readers, receipt printers, bar code scanners, cash registers, scales) Hospital (monitoring equipment, nurses' stations) Hotel Front Desk (serial printers, bar code scanners, keyboard, mouse, receipt printer, credit/debit card reader) Hospitality/Restaurant (credit card/debit card reader, serial printers)
www.startech.com
1 800 265 1844
Features
Supports standard Ethernet or Power over Ethernet (POE) Supports UDP, IP, TCP, ICMP, HTTP, DHCP and ARP-Ping protocols Wall mountable Integrated 10/100Mbps RJ45 LAN port Data transfer rates of up to 115.2 Kbps per port Supports Auto Crossover (MDI/MDI-X) Support for Windows® 2000, XP 32bit, and Vista 32bit
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years Industry Standards IEEE 802.3af Power-over-Ethernet Data Bits 6, 7, 8 Maximum Data Transfer Rate 115.2Kbps MTBF 233,403 Hours Stop Bits 1, 2 Supported Protocols UDP, IP, TCP, ICMP, HTTP, DHCP, ARP-Ping Connector Type(s) 1 - DB-9 (9 pin; D-Sub) Male Connector Type(s) 1 - RJ-45 Female OS Compatibility Windows® 2000, XP 32bit, Vista 32bit Color Black Enclosure Type Aluminum Product Height 1 in [25.4 mm] Product Length 4.2 in [107 mm] Product Weight 16.9 oz [480 g] Product Width 2.6 in [66.3 mm] LED Indicators 3 - Heartbeat, Link/Activity, 10/100 Mbps Center Tip Polarity Positive Input Current 0.3 A Input Voltage 110 ~ 240 AC Output Current 0.1A Output Voltage 12 DC Plug Type M Power Source AC Adapter Included Humidity 5~95% RH Operating Temperature 0°C to 55°C (32°F to 131°F) Storage Temperature -20°C to 85°C (-4°F to 185°F) Shipping (Package) Weight 1.9 lb [0.9 kg] Included in Package 1 - Industrial Serial over IP Device Server Included in Package 1 - Universal Power Adapter (NA/UK/EU) Included in Package 1 - Driver CD Included in Package 1 - Instruction Manual
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
