7.5 m CAT6 Patch Cable - 100% Copper Wire Snagless Connector - Green
Product ID: N6PATC750CMGN
This CAT6 cable meets all Category 6 cable specifications, to deliver a reliable Gigabit network connection.
Protect Your Equipment
This CAT6 patch cable is built using 100% copper wire and are tested to comply with ANSI/TIA 568 C.2
Category 6 requirements. We don’t use copper-clad aluminum (CCA) wire, which is subject to problems
like weak power delivery, heat buildup, equipment damage and possibly fire.
The 50-micron gold connectors deliver optimum conductivity and eliminate signal loss due to oxidation or
corrosion.
www.startech.com
1 800 265 1844
High-Quality Construction
The CAT6 cable is manufactured using high-quality copper conductors and carefully constructed and
tested to keep Near-End Crosstalk (NEXT) well within acceptable limits. The patch cable is constructed with
24 AWG copper wire, to ensure peak performance for demanding Ethernet applications such as Power-
over-Ethernet and 4K or 1080p video streaming.
Easily Install Your Network Cables
For trouble-free cable runs, this durable cable feature snagless connectors that protect the RJ45 clips
during installation, making them less likely to snag or break.
The CAT6 Ethernet cable also features molded boots which offer strain relief by stopping the RJ45
connectors from bending at sharp angles. This reduces the risk of cable damage, which could decrease
network connectivity and performance.
N6PATC750CMGN is backed by a StarTech.com lifetime warranty for guaranteed reliability.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Designed for use with Gigabit networks
• Patches from hub to distribution panel
• Connects workstation to wall outlet
Features
• Protect your network and equipment with 100% copper wire CAT6
cables
• Tested to comply with ANSI/TIA 568 C.2 CAT6 requirements
• RJ45 connector-clip protectors prevent cable snags and breaks during
installation
• 50-micron gold-plated connectors for a clear signal
• Built with 24 AWG copper wire to ensure a peak performance for your
demanding Ethernet applications
www.startech.com
1 800 265 1844
Warranty Lifetime
Hardware Cable Jacket Type PVC - Polyvinyl Chloride
Cable Type Snagless
Connector Plating Gold
Fire Rating CMG Rated (General Purpose)
Number of Conductors 4 pair UTP
Wiring Standard TIA/EIA-568-B.1-2001 T568B
Performance Cable Rating CAT6 - 650 MHz
Connector(s) Connector A 1 - RJ-45 Male
Connector B 1 - RJ-45 Male
Physical
Characteristics
Cable Length 7.5 m [24.6 ft]
Color Green
Conductor Type Stranded Copper
Product Height 8.200
Product Length 750 cm [295.3 in]
Product Width 11.600
Weight of Product 320.000
Wire Gauge 24 AWG
Packaging
Information
Package Height 0.100
Package Length 200.000
Package Width 220.000
Shipping (Package) Weight 335.000
What's in the Box Included in Package 1 - CAT6 Cable
Product appearance and specifications are subject to change without notice.
