Startech MST30C2HDPPD Product Data Sheet

Dual-Monitor USB-C Docking Station - Dual DisplayPort - 2.5" SATA SSD/HDD Drive Bay - MST and 60W Power Delivery - 4K
Product ID: MST30C2HDPPD
This dual-monitor USB-C™ docking station adds valuable data storage and backup to your Windows
laptop, and makes it easy to create a multi-monitor workstation through support for DP Alt Mode and
DisplayPort Multi-Stream Transport (MST).
The USB-C dock provides a versatile way to connect to two DisplayPort monitors, a wired network
single USB-C cable. Plus, with Power Delivery support, you can power and charge your laptop as you
work.
www.startech.com
1 800 265 1844
Add data storage and backup
Featuring a built-in 2.5” SATA SSD/HDD drive bay, this docking station gives you the added advantage of
external data storage and backup, reducing the number of devices on your desktop. You can consolidate
your peripherals, including external storage, with just one connection to your laptop. This reduces clutter
in your workspace and simplifies workflow, making it easier to perform routine tasks like data offloads.
The 2.5" drive bay supports SATA I, II, and III. It’s ideal for creative professionals, IT executives,
engineers, business executives and other professionals requiring high-performance functionality and
external storage and backup, with Windows Backup, macOS Time Machine or other backup software. And,
if you want to add further external storage, the dock has three USB 3.0 ports available.
Connect just one adapter to power the dock and your laptop
This premium laptop dock capitalizes on the full potential of USB Type-C™, which simultaneously transfers
power, video, and data.
The docking station supports USB Power Delivery, providing up to 60 watts of power, through the 100W
power adapter included. This means you can power and charge your laptop while it's docked, through its
USB-C port, and cut clutter at your workstation. Plus, you don’t need to carry or remember an extra
power adapter when you’re traveling to or from the office.
Take advantage of versatile video output
This dual-monitor docking station replicates the high performance of a full-size workstation, with DP Alt
Mode and MST support providing single, mirror and extended display mode functionality. The USB-C
docking station supports 4K Ultra HD resolution (providing the connected DisplayPort display supports it).
With this versatile dock, you can connect:
2x DisplayPort display at 1920 x 1200 resolution (60Hz)
1x DisplayPort display at 3840 x 2160 resolution (30Hz)
Note: Multi-display and dual-display configurations are only supported in Windows operating systems that
support MST.
The MST30C2HDPPD is backed by a StarTech.com 3-year warranty and free lifetime technical support.
Notes:
Ensure your laptop’s drivers, firmware, and operating system are up to date prior to using the docking station.
Video output capabilities are dependent on the video card and hardware specification of your connected laptop. Certain video cards
have limited MST support, while some monitors will also limit the available resolution.
www.startech.com
1 800 265 1844
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your laptop USB-C port supports DP alt
mode, as well as USB Power Delivery.
Not all Thunderbolt 3 USB-C ports support the full functionality of the Thunderbolt 3 standard. Ensure that your laptop Thunderbolt
3 port supports USB Power Delivery.
macOS does not support MST.
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
Applications
The perfect accessory for USB-C equipped laptops, supports backup functions using Windows Backup, macOS Time Machine or other backup software
Ideal for creative professionals, engineers, IT executives and many more professionals requiring multiple sources for external storage or backup of large files
Power and charge your USB-C equipped laptop, using only the dock’s power adapter
Create a full-size workstation that’s ideal for hot desk and BYOD (Bring Your Own Device) users, or for CYOD (Choose Your Own Device) applications
Features
Add data storage and backup capability with an internal 2.5” SATA SSD/HDD drive bay (supports SATA I, II, III)
Power and charge your laptop as you work with 60W USB Power Delivery 2.0 support
Turn your USB-C laptop into a dual-video workstation with MST single, mirror and extended mode support
Easy plug and play setup with no drivers required
Connect your existing peripherals using three available USB 3.0 (Type-A) ports, including one fast-charge port to charge phones, with or without dock connected to laptop
Gigabit Ethernet connectivity with Wake-on-LAN
Thunderbolt™ 3 port compatible
Boot from LAN or USB devices
Convenient front panel ON/OFF button
www.startech.com
1 800 265 1844
Warranty 3 Years
Hardware 4K Support Yes
Bus Type USB-C
Chipset ID VIA - VL813 (USB Power Delivery)
MegaChips - STDP4320 (DisplayPort with MST) AS Media - ASM1153E (SATA III) Realtek - RTL8153 (LAN) C-Media - CM6533 (C-Media)
Displays Supported 2
Fast-Charge Port(s) Yes
Industry Standards USB Power Delivery Specification Rev. 2.0
USB Battery Charging Specification Rev. 1.2 DisplayPort 1.2 with MST IEEE 802.3, IEEE 802.3u, IEEE 802.3ab USB 3.0 - Backward compatible with USB 2.0 and 1.1
Performance Maximum Data Transfer Rate 5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions 2x DisplayPort display at 1920 x 1200 resolution (60Hz)
1x DisplayPort display at 3840 x 2160 resolution (30Hz)
Type and Rate USB 3.0 - 5 Gbit/s
UASP Support Yes
Connector(s) Connector Type(s) 1 - USB Type-C (24 pin) USB 3.0 Female
2 - DisplayPort (20 pin) Female
1 - USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
2 - USB Type-A (9 pin) USB 3.0 Female
1 - RJ-45 Female
1 - 3.5 mm Mini-Jack (4 Position) Female
Software OS Compatibility Windows® 7, 8, 8.1, 10
Mac OS 10.11 to 10.12*
*MacOS does not support MST
Special Notes / Requirements
Note Not all USB-C ports support the full functionality of the USB
Type-C standard. Ensure that your host USB-C port supports USB Power Delivery 2.0 and DP alt mode.
If you are connecting multiple DisplayPort monitors in a daisy chain through the dock's DisplayPort connection, the monitors must support DisplayPort 1.2 and MST
USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps
www.startech.com
1 800 265 1844
A 4K-capable DisplayPort display is required to achieve 4Kx2K resolution
Video output capabilities are dependent on the video card and hardware specifications of your connected host laptop. Certain video cards have limited MST or video support, while some monitors will also limit the available resolution.
For a dual-monitor configuration the host laptop must support MST
System and Cable Requirements A host laptop with an available USB-C port (to ensure full
adapter functionality, the host USB-C port must support USB Power Delivery 2.0 and DP alt mode)
Power Center Tip Polarity Positive
Input Current 2 A
Input Voltage 100 ~ 240 AC
Output Current 5 A
Output Voltage 20V DC
Plug Type N
Power Consumption (In Watts) 100
Power Delivery 60W
Power Source AC Adapter Included
Environmental Humidity 0%~95% RH (Non-condensing)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Physical Characteristics
Cable Length 39.4 in [1000 mm]
Color Black & Silver
Enclosure Type Plastic
Product Height 1.1 in [28 mm]
Product Length 8.3 in [210 mm]
Product Weight 4.7 oz [133 g]
Product Width 3.5 in [90 mm]
Packaging Information
Shipping (Package) Weight 35.3 oz [1000 g]
What's in the Box Included in Package 1 - docking station
1 - 1 m USB-C cable
www.startech.com
1 800 265 1844
4 - hard-drive mounting screws
1 - universal power adapter (NA/JP, UK, EU, ANZ)
1 - Quick-start guide
Product appearance and specifications are subject to change without notice.
