Startech IES5102 User Manual

5-port industrial Ethernet switch - DIN rail mountable
StarTech ID: IES5102
This compact 5-port industrial Ethernet switch is engineered to deliver fast, reliable network connectivity and durability in the most demanding industrial environments. It provides top performance in a wider range of operating temperatures than conventional network switches, making it ideal for factories and warehouses.
Conquer the tough demands of industrial environments
Designed with a rugged IP30-rated housing, the network switch delivers maximum performance even in harsh industrial conditions. Its wide-range terminal block input gives you the flexibility to power the switch as required, based on your own power input source, while its wide operating temperature range keeps your network running smoothly.
Get up and running in no time
This industrial Ethernet switch is easy to install, with an attached metal bracket for DIN rail mounting on equipment racks and cabinets.
Now you can eliminate the hassle of troubleshooting mismatched speed and duplex settings. This switch gives you full/half-duplex auto-negotiation and auto MDI/MDIX operation, enabling you to connect your network devices quickly and easily with little to no configuration required.
Reduce your energy costs with Energy-Efficient Ethernet
With lower overall power consumption, the Ethernet switch enhances your energy efficiency, in turn helping you reduce monthly costs.
The IES5102 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Applications
Well suited for networks in demanding industrial applications such as warehouses and factories A great way to enhance network connectivity, adding small workgroups to an existing network Install in a server rack or cabinet in a network room or test lab environment
Features
Network up to 5 Ethernet devices, even in industrial settings, with a robust IP30-rated switch Wide-range 12-48V DC terminal block input Easy installation with an integrated DIN rail bracket Wider range of operating temperatures, ideal for industrial environments IEEE 802.3az Energy-Efficient Ethernet Supports 10BaseT/100BaseTX and Full-Duplex/Half-Duplex Auto-negotiation Supports IEEE 802.3x flow control and back pressure Store-and-forward switching mechanism
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years Industry Standards IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX) Industry Standards IEEE 802.3az (Energy-Efficient Ethernet) Industry Standards IEEE 802.1P Quality of Service (QoS) Interface RJ45 (10/100 Ethernet) Ports 5 Regulatory Approvals EN61000-6-2
EN61000-6-4 EN61000-4-3 (Radiated RFI Standards) EN61000-4-4 (Burst Standards) EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) IEC60068-2-6 Fc (Vibration)
IEC60068-2-27 Ea (Shock) Auto MDIX Yes Auto-Negotiation Yes Buffer Size 56 KB Compatible Networks 10/100 Mbps Flow Control IEEE 802.3x Full-Duplex Full Duplex Support Yes Jumbo Frame Support No Maximum Cable Length 328 ft [100 m] Maximum Data Transfer Rate 200 Mbps (Full-Duplex) MTBF 1,179,133 Hours Surge Protection ESD: EN61000-4-2
Surge: EN61000-4-5 Switching Architecture Store-and-Forward External Ports 5 - RJ-45 Female External Ports 1 - Terminal Block (3 Wire) OS Compatibility OS Independent; No additional drivers or software required Color Black Enclosure Type Plastic Product Height 4.3 in [110 mm] Product Length 2.8 in [70 mm] Product Weight 5.2 oz [148 g]
www.startech.com
1 800 265 1844
Product Width 1 in [25 mm] LED Indicators 1 - Power LED Indicators 5 - Link/Activity LED Indicators 5 - Activity (100 Mbps) Input Voltage 12 ~ 48 DC Power Consumption 2.12W Max Power Source Terminal Block Humidity 5~95% RH (Non-Condensing) Operating Temperature -10°C to 60°C (14°F to 140°F) Storage Temperature -25°C to 85°C (-13°F to 185°F) Shipping (Package) Weight 11.8 oz [335 g] Included in Package 1 - 5 Port Ethernet Switch (w/ Attached DIN Rail Bracket) Included in Package 1 - Terminal Block Included in Package 1 - Instruction Manual CD
Certifications, Reports and Compatibility
