Startech HDMM5MA User Manual
5m (15 ft) Active High Speed HDMI® Cable - Ultra HD 4k x 2k HDMI Cable - HDMI to HDMI M/M
StarTech ID: HDMM5MA
The HDMM5MA 15 ft Active High Speed HDMI® Cable features a built-in active signal booster for a connection
distance of up to 15 feet (5m) between your HDMI-enabled devices, with no signal loss.
This durable, lightweight cable features thinner HDMI wire construction - approximately half the thickness of a
regular 5m cable, which allows for a more flexible installation with minimal clutter. Plus, the cable features builtin amplifier circuitry which actively boosts the HDMI signal with no external power required.
This high quality HDMI cable fully supports 1080p+ resolutions at up to 120Hz refresh rate, with life-like color. To
accommodate the demands of future high definition devices, such as increased resolutions and higher frame
rates, this Ultra HD cable supports resolutions up to 4k x 2k.
This 5 meter HDMI cable is backed by StarTech.com's 2-year Warranty.
Please Note: This cable features unidirectional architecture which requires that the cable is installed in the
correct direction. Please refer to the "TV" label on the HDMI connector which plugs into your display, in order to
ensure that the device and the HDMI source are connected properly.
Applications
Connecting high-definition A/V devices such as Blu-Ray Disc™ players, HDTVs, DVD Players, DVRs,
game consoles, projectors etc., up to 5m away, with no signal loss
www.startech.com
1 800 265 1844
Features
Thin cable construction – outer diameter (OD) of 3.6mm
Built-in, active amplifier circuitry
Supports Ultra HD Resolutions up to 4k x 2k
Gold-plated HDMI connectors
High quality construction
Technical Specifications
Warranty 2 Years
Cable Length 16.4 ft [5 m]
Cable OD 0.1 in [3.6 mm]
Color Black
Connector Style Straight
Product Length 16.4 ft [5 m]
Product Weight 4.8 oz [135 g]
Wire Gauge 36 AWG
Cable Jacket Type PVC - Polyvinyl Chloride
Cable Shield Type Aluminum-Mylar Foil with Braid
Connector Plating Gold
Fire Rating CMG Rated (General Purpose)
Connector A 1 - HDMI (19 pin) Male
Connector B 1 - HDMI (19 pin) Male
Package Quantity 1
Shipping (Package) Weight 4.9 oz [138 g]
Included in Package 1 - 5m Active High Speed HDMI® Cable - HDMI - M/M
www.startech.com
1 800 265 1844
