1 Port Flush Mount ExpressCard SuperSpeed USB 3.0 Card Adapter with UASP Support
StarTech ID: ECUSB3S11
The ECUSB3S11 Flush Mount 1-Port USB 3.0 ExpressCard lets you add a single USB 3.0 port connection to
your laptop through an ExpressCard slot.
The USB 3.0 adapter uses a unique form factor design that allows it to sit fully in a standard 34mm ExpressCard
slot without sticking out. The port sits virtually flush with the sides of the laptop, enabling you to leave the card
installed even while on the move, without fear of damage to the card or slot.
Enhanced with UASP support (USB Attached SCSI Protocol), this USB 3.0 controller performs up to 70% faster
than conventional USB 3.0 when paired with a UASP supported enclosure (Note: UASP requires a compatible
operating system). Using a more efficient protocol than the traditional USB BOT (Bulk-Only Transport), UASP
technology optimizes transfers by allowing multiple commands to be processed simultaneously, significantly
increasing transfer speeds for less wait time on data transfers. See our UASP test results below for further
details.
The USB 3.0 ExpressCard adapter supports data transfer rates up to 5Gbps, and is still backward compatible
with USB 2.0 at up to 480Mbps, or USB 1.1/1.0 at up to 12/1.5 Mbps respectively.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Improved Performance with UASP
UASP is supported in Windows® 8, Server 2012 and Linux kernel 2.6.3 or later. In testing UASP performed with
up to a 70% faster read / 40% faster write speed over traditional USB 3.0 at peak performance.
www.startech.com
1 800 265 1844
At the same peak in testing, UASP also showed up to an 80% reduction in required processor resources.
Test results were obtained using an Intel® Ivy Bridge system, StarTech.com add-on USB 3.0 cards, a UASPenabled StarTech.com enclosure, and a SATA III solid state drive.
Applications
Add a SuperSpeed USB 3.0 port through an ExpressCard slot, without having to worry about damaging
the card or slot while on the move
Connect high performance USB 3.0 external storage devices, printers or external video adapters to a
laptop
Upgrade an older laptop to USB 3.0 capability
Add an extra USB 3.0 port to a laptop with limited USB 3.0 ports available
www.startech.com
1 800 265 1844
Features
Unique flush-mount form factor design
SuperSpeed USB 3.0 compliant host interface with support for transfer rates up to 5 Gbps
UASP support for more efficient data transfer
Provides up to 850mA of power over USB
Backward compatible with USB 2.0/1.x devices
Compliant with USB 3.0 base specification 1.0 and xHCI specification 0.95
Includes 34mm to 54mm ExpressCard stabilizer bracket
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Product
Height
0.2 in [5 mm]
Product
Length
3 in [75 mm]
Product
Weight
0.6 oz [17.5 g]
Product
Width
1.3 in [34 mm]
Bus Type ExpressCard
Card Type 34mm ExpressCard
Chipset ID Renesas / NEC - µPD720202
Interface USB 3.0
Port Style Integrated on Card
Ports 1
Type and
Rate
USB 3.0 - 5 Gbit/s
UASP
Support
Yes
Connector
Type(s)
1 - ExpressCard (34mm)
External
Ports
1 - USB 3.0 A (9 pin; SuperSpeed) Female
OS
Compatibility
Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64)
Windows Server® 2012, 2008 R2, 2003
Note The maximum throughput of this card is limited by the host bus interface. If used with
ExpressCard Gen 1.0 enabled computers, the max throughput is 2.5 Gbps. If used with
ExpressCard Gen 2.0 enabled computers, the max throughput is 5 Gbps.
System and
Cable
Requirements
Available ExpressCard slot
Humidity 5% ~ 95% RH
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Storage
Temperature
-10°C to 85°C (14°F to 185°F)
www.startech.com
1 800 265 1844
Package
Quantity
1
Shipping
(Package)
Weight
3.5 oz [99 g]
Included in
Package
1 - Slim ExpressCard adapter
Included in
Package
1 - DC to USB Adapter Cable
Included in
Package
1 - 34mm to 54mm Stabilizer Bracket
Included in
Package
1 - Driver CD
Included in
Package
1 - Instruction Manual
Certifications, Reports and Compatibility
