DVI to HDMI Video Converter with Audio
Product ID: DVI2HDMIA
The DVI2HDMIA DVI to HDMI Converter/Adapter lets you connect a DVI-D source with the accompanying RCA audio
signal to an HDMI monitor or HDTV, with support for full HD 1080p (1920x1080) resolution.
A cost-effective alternative to upgrading equipment for compatibility, this small form factor adapter provides a
plug-and-play solution for connecting your Mac, PC or home theater device with DVI (digital) output to your television
or HDMI monitor. The RCA stereo audio connections integrate the audio signal directly into the HDMI output, so that
a single cable can be run to your destination device.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Certifications, Reports and Compatibility
Applications
• Deliver audio/video content from your PC or Mac to your A/V devices (HDTV or receiver) for a larger and louder
viewing
• Ideal for digital entertainment centers, home offices, business conference rooms and trade show displays
• Convert your DVI and audio signals for video and audio pass-through to one HDMI cable
• Keep your existing HDMI monitor to be used with your DVI device
Features
• Compact design
• Rugged metal enclosure
Hardware
Warranty
2 Years
Active or Passive Adapter
Active
AV Input
DVI-D
Audio RCA
AV Output
HDMI
Audio
Yes
Industry Standards
Standard HDMI, HDCP Compliant
Performance
Maximum Data Transfer
Rate
2.25Gbps
Maximum Digital
Resolutions
1080p / 1920x1080
Supported Resolutions
480i,576i,1080i Interlaced(50-60Hz)
480p,576p,720p,1080p Progressive(50-60Hz)
Wide Screen Supported
Yes
Bandwidth
225MHz
Connector(s)
Connector Type(s)
DVI-I (29 pin)
Stereo Audio (2 x RCA)
HDMI (19 pin)
Special Notes /
Requirements
Note
DVI signal must be DVI-D (digital only).
• Supports HD 1080p (1920x1080) resolution
• Supports 2-channel RCA audio
• DVI-D Video with Audio pass-through to a single HDMI cable
Indicators
LED Indicators
Power indicator
Connection indicator
Power
Power Source
AC Adapter Included
Input Voltage
100 - 240 AC
Input Current
0.5A
Output Voltage
5 DC
Output Current
2A
Center Tip Polarity
Positive
Plug Type
M
Power Consumption (In
Watts)
5
Environmental
Operating Temperature
0C to 70C (32F to 158F)
Storage Temperature
-10C to 80C (14F to 176F)
Humidity
10~85% RH
Physical
Characteristics
Color
Black
Material
Steel
Product Length
3.5 in [88 mm]
Product Width
1.0 in [25.5 mm]
Product Height
2.7 in [68 mm]
Weight of Product
4.0 oz [113 g]
Packaging
Information
Package Length
4.8 in [12.3 cm]
Package Width
6.8 in [17.2 cm]
Package Height
2.4 in [60 mm]
Shipping (Package)
Weight
12.8 oz [362 g]
What's in the
Box
Included in Package
DVI to HDMI converter
Power Adapter
User Manual
*Product appearance and specifications are subject to change without notice.
