Digital Signage Display Stand - Black - Locking
Product ID: DSIGNAGESTND
The digital signage stand provides a convenient and cost-effective way to communicate with clients.
Engineered with a sleek and sturdy design, the portrait kiosk enclosure provides a secure mount for a 45"
to 55" TV (with maximum weight of 176 lb./80 kg) that will attract and captivate passersby.
Durable Construction
The digital signage mount features durable construction which makes it ideal for commercial use, in
environments such as trade shows and retail establishments. While many kiosks have a built-in display,
the LCD advertising stand display allows you to repurpose an existing display or one of your choice. Built-
in cable management keeps your cables organized and hidden from view. The digital signage kiosk
enclosure features a lockable cabinet for installing your computer, media player or video extender.
Easy Assembly
The flat TV stand features a solid base that provides the display with stability, perfect for use in areas with
heavy traffic. The base of the touch screen kiosk stand is designed to be bolted to the floor to provide
greater stability than freestanding display kiosks.
www.startech.com
1 800 265 1844
The Choice of IT Pros Since 1985
StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we
are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our
local StarTech.com Technical Advisors have broad product expertise and work directly with our
StarTech.com Engineers to provide support for our customers both pre and post-sales.
This DSIGNAGESTND is backed by a StarTech.com 5-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Keep guests informed in hotels, restaurants, train stations, or
airports
• Create an interactive display or map for wayfinding
• Perfect for advertising with dynamically updated content on your
display
Features
• Built-in cabinet with lock protects your video equipment from theft
and tampering
• Heavy-duty steel TV mount supports up to 175 lb. (80 kg)
• Hook-and-mount design for easy setup with VESA compliant TVs
• Integrated cable management allows for clean installation
www.startech.com
1 800 265 1844
Warranty 5 Years
Hardware # of Displays Supported 1
Articulating No
Cable Management Yes
Mounting Options Desktop Stand
Orientation Vertical
Tools Included Yes
VESA Hole Pattern(s) 200x200 mm
400x200 mm
300x300 mm
400x400 mm
600x400 mm
Wallmountable No
Performance Anti-theft Yes
Fits Curved Display No
Maximum Display Size 55"
Minimum Display Size 45”
Physical
Characteristics
Product Height 1940.000
Product Length 37.8 in [96 cm]
Product Width 350.000
Weight of Product 40.000
Packaging
Information
Package Height 270.000
Package Length 435.000
Package Width 1452.000
Shipping (Package) Weight 44.100
What's in the Box Included in Package 1 - Lower Base Board
2 - Lower Columns
4 - Lower Column Caps
1 - Cabinet
1 - Upper Base Board
www.startech.com
1 800 265 1844
1 - Upper Column, Left
1 - Upper Column, Right
2 - End Caps
2 - Cross Bars
2 - TV Brackets
1 - Cable Bracket
2 - Locking Brackets
2 - Cable Clips
2 - Screw Caps
4 - M10 x 25 Screws
10 - M6 x 12 Screws
4 - M8 x 60 Screws
4 - M8 Nuts
8 - M6 x 15 Screws
2 - M6 x 35 Screws
2 - M4 x 6 Screws
2 - Screws
2 - Cable Ties
1 - 4mm Hex Key
1 - 6mm Hex Key
1 - 5mm Hex Key
1 - M6/M8 Wrench
4 - M5 x 14 Screws
4 - M6 x 14 Screws
4 - M8 x 30 Screws
4 - M8 x 50 Screws
4 - Rectangular Washers
8 - Small Spacers
8 - Large Spacers
1 - Floor Anchor
1 - Instruction Manual
Product appearance and specifications are subject to change without notice.
