10 ft DisplayPort to VGA Adapter Converter Cable – DP to VGA 1920x1200 - Black
StarTech ID: DP2VGAMM10B
The DP2VGAMM10B 10ft active DisplayPort to VGA converter cable lets you connect your DisplayPortequipped desktop or laptop directly to a VGA monitor or projector with no additional adapters or cables
required -- a cost-effective solution for enabling your new Mini DisplayPort computer to work with an older VGA
monitor or projector.
Plus, because the converter cable supports video resolutions up to 1920x1200 you can convert a DisplayPort
video source to VGA without sacrificing video quality.
The DP2VGAMM10B is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Applications
Connect your existing VGA display device (monitor, projector) to a DisplayPort output device (Desktop,
Laptop computer)
Use your VGA monitor as a secondary display, connected to a DisplayPort output
Connect a DisplayPort computer to a VGA projector for presentations or meetings in a boardroom or
auditorium setting
Features
Active DisplayPort to VGA conversion
Plug-and-Play Installation
Supports resolutions up to 1920x1200 (WUXGA) and HDTV resolutions up to 1080p
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Adapter Style Cable Adapter
Audio No
Chipset ID ANALOGIX 9832
Converter Type Active
Maximum Analog Resolutions 1920x1200 / 1080p (Output)
Maximum Cable Length 10 ft [3 m]
Maximum Digital Resolutions 1920x1200 / 1080p (Input)
Connector A 1 - DisplayPort (20 pin) Latching Male
Connector B 1 - VGA (15 pin; High Density D-Sub) Male
Humidity 40%-85%RH
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -10°C to 70°C (14°F to 158°F)
Cable Length 10 ft [3 m]
Color Black
Product Height 0.6 in [15 mm]
Product Length 36 in [915 mm]
Product Weight 5.6 oz [160 g]
Product Width 1.3 in [33 mm]
Shipping (Package) Weight 0.3 lb [0.2 kg]
Included in Package 1 - DisplayPort™ to VGA Adapter Cable
