DisplayPort to VGA Adapter Cable with Audio - 6ft (2m)
StarTech ID: DP2VGAAMM2M
Now you can organize your workspace with less mess than ever before.
This unique 6-foot DisplayPort™ to VGA adapter cable features a built-in audio port, which enables you to
connect a VGA monitor as well as speakers to your DisplayPort (DP) equipped desktop computer.
Create a clutter-free environment
Remove the cable clutter from your desk. With the built-in audio port you no longer need to run a separate audio
cable from your monitor or speakers directly to your desktop or laptop computer. Simply plug the audio cable
from your speakers into the adapter cable for a simple and tidy solution.
In order to use the audio function of the adapter, it needs to be powered through USB. Simply connect a MicroUSB cable into the adapter from your computer, monitor or USB grommet in order to provide the necessary
power.
Substitute for a damaged audio port
The adapter guarantees you always have all of the connections you need. If the audio port on your computer is
damaged or blocked, this adapter cable ensures you still have sound available for watching video presentations,
listening to music while you work or chatting with your colleagues over Skype™.
The DP2VGAAMM2M is backed by a 2-year StarTech.com warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Applications
Connect your speakers and a VGA monitor to your DisplayPort equipped computer with the cables
hidden and out of the way
Use in your boardroom or office workstations for installations requiring 6 feet of cable
Features
Create a clutter-free work environment by placing your audio and video cables neatly behind your monitor
Substitute a damaged or blocked audio port by connecting your speakers to your computer directly
through the adapter
Provide crystal-clear picture quality with support for high-definition video resolutions up to 1920x1200 or
1080p
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Adapter Style Cable Adapter
Audio Yes
Converter Type Active
Audio Specifications 2-channel stereo (3.5mm)
Maximum Analog Resolutions 1920x1200 / 1080p (output)
Maximum Digital Resolutions 1920x1200 / 1080p (input)
Wide Screen Supported Yes
Connector A 1 - DisplayPort (20 pin) Latching Male
Connector B 1 - VGA (15 pin; High Density D-Sub) Male
Connector B 1 - 3.5 mm Mini-Jack (3 Position) Female
Connector Type(s) 1 - USB Micro-B (5 pin) Female
Cable Length 6.6 ft [2 m]
Color Black
Product Length 6.6 ft [2 m]
Product Weight 2.5 oz [70 g]
Power Source USB-Powered
Humidity 40%~50%RH
Operating Temperature 0°C to 70°C (32°F to 158°F)
Storage Temperature -10°C to 55°C (14°F to 131°F)
Package Quantity 1
Shipping (Package) Weight 5.7 oz [162.5 g]
Included in Package 1 - 2m DiplayPort to VGA adapter cable with audio
Included in Package 1 - 0.5m Micro USB cable
www.startech.com
1 800 265 1844
Certifications, Reports and Compatibility
