DisplayPort to HDMI Adapter with HDR - 4K 60Hz Black
Product ID: DP2HD4K60H
This DisplayPort to HDMI Adapter lets you connect your DP equipped computer to an HDMI display. The
adapter supports High Dynamic Range (HDR) and provides sharper images with enhanced video.
With brighter colors and greater contrast, the adapter is ideal for:
• Creating eye-catching visuals for photography, videography, cinematography
• Displaying crisp digital signage walls
• Delivering enriched presentations
www.startech.com
1 800 265 1844
True 4K at 6Hz and HDR
The DisplayPort to HDMI adapter is fully compatible with your HDMI 2.0b equipment, supporting
resolutions up to 4K 60Hz (3840 x 2160) and bandwidths up to 18Gbps. The adapter offers 4:4:4 chroma
subsampling, so every pixel gets its own unique color. It’s also backward compatible with earlier versions
of HDMI and DisplayPort at their supported maximum resolutions.
With HDR support, you can enjoy lifelike images with increased contrast, brightness and colors and
greater luminosity than standard digital imaging. [DS1] [JV2]
Ideal for Travel
This lightweight video adapter is highly portable, with a small footprint design. It's the perfect accessory
for your DP supported devices, fitting easily into your carrying case.
Hassle-Free Setup
To ensure easy operation and installation, this unique DP to HDMI adapter allows for plug-and-play
installation without any additional software or drivers.
DP2HD4K60H is backed by a 3-year StarTech.com warranty and free lifetime technical support.
Note: To achieve HDR, a DisplayPort 1.4 output and an HDMI 2.0b display are required.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Features
• Astonishing picture quality with support for UHD video resolutions up
to 4K 60Hz
• Supports HDR for expanded contrast ratio and color accuracy
• Features an electromagnetic interference (EMI) shielding cage to
ensure reliable and consistent audio-video signal
• Maximum portability with a compact, lightweight design
• Hassle-free setup with an active DisplayPort conversion
www.startech.com
1 800 265 1844
Warranty 3 Years
Hardware Active or Passive Adapter Active
Adapter Style Adapters
Audio Yes
AV Input DisplayPort
AV Output HDMI
Chipset ID MegaChips - MCDP2900
Industry Standards DPCP (DisplayPort Content Protection)
HDCP 2.2 (High Definition Content Protection)
DisplayPort 1.4
HDMI 2.0b
Ports 1
Performance Audio Specifications 7.1 surround sound
Maximum Digital Resolutions 4096 X 2160 @ 24Hz
3840 X 2160 @ 60Hz
Supported Resolutions 4096 X 2160 @ 24Hz
3840 X 2160 @ 60Hz
Lower resolutions and refresh rates may also be supported
Video Revision HDMI 2.0b
Wide Screen Supported Yes
Connector(s) Connector A 1 - DisplayPort (20 pin) Latching Male Input
Connector B 1 - HDMI (19 pin) Female Output
Special Notes /
Requirements
Note This video adapter is not compatible with cables that use
RedMere™ technology.
In order to achieve maximum performance of this product,
both the source and destination devices must support the
appropriate specifications
Environmental Humidity 25%-60%RH
Operating Temperature 5°C ~ 35°C (41 F°~95 F°)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Physical
Characteristics
Cable Length 7.7 in [195.6 mm]
Color Black
Enclosure Type Plastic
Product Depth 7.7 in [195.6 mm]
www.startech.com
1 800 265 1844
Product Height 0.4 in [11.4 mm]
Product Length 2.2 in [56 mm]
Product Weight 1.1 oz [30 g]
Product Width 1.1 in [28.6 mm]
Packaging
Information
Shipping (Package) Weight 0.1 lb [0 kg]
What's in the Box Included in Package 1 - DisplayPort to HDMI Adapter
Product appearance and specifications are subject to change without notice.
