USB-C Multiport Adapter - USB-C Travel Dock with 4K HDMI or 1080p VGA - Gigabit Ethernet,
5Gbps USB-A 3.0 - USB-C Digital AV Adapter - USB Type-C/Thunderbolt 3 Laptops - White
Product ID: DKT30CHVW
Expand the connectivity of your USB-C enabled laptop. This USB-C multiport adapter lets you turn your laptop into a
powerful workstation, virtually anywhere you go, eliminating the hassle of carrying and connecting many different port
adapters. This 4-in-1 adapter lets you add 4K Ultra HD HDMI or VGA video output, one USB 3.0 Type-A port, and
one Gigabit Ethernet port through your laptop’s USB-C port.
It’s the perfect travel accessory for your MacBook Pro, Chromebook, Dell XPS, or other USB Type-C equipped
laptop, giving you the most common video outputs plus other essential added port options. It features a sleek white
and silver design that looks great next to your laptop, and it’s also Thunderbolt 3 port compatible.
The multiport adapter enhances the connectivity of your port-limited laptop, giving you the ability to connect to
multiple devices simultaneously. When coupled with your laptop display, this versatile USB-C multiport adapter
makes it easy to create a powerful workstation.
The USB-C multiport adapter provides HDMI (with audio) and VGA ports, so you can easily connect a 4K HDMI or a
standard-definition VGA monitor. Connect a high-resolution monitor to deliver engaging presentations in boardrooms,
classrooms, and conference rooms. Use an HDMI port-equipped television in a hotel room as an external display
when traveling. The option of VGA video output means you can connect easily to legacy VGA projection systems or
monitors when you need to.
The Gigabit Ethernet port ensures reliable wired network access, ideal for areas with limited Wi-Fi availability.
This compact multiport adapter is USB-powered, so there's no need to carry a separate power adapter with you. It
provides both HDMI and VGA video output, giving you the flexibility to adapt to newer and older boardroom setups as
needed. The adapter also features a built-in USB-C cable and gives you network connectivity and a USB Type-A
connection for optimum versatility as you travel.
The DKT30CHVW is backed by a StarTech.com 3-year warranty and free lifetime technical support.
Notes:
For MacBook host systems using macOS 10.12, version 10.12.6 or later is required to support this product.
• Your USB-C equipped host laptop must support video (DP alt mode) to work with this adapter. The adapter does not
support USB Power Delivery.
Certifications, Reports and Compatibility
Applications
• The portable adapter, in silver and white, is the perfect accessory for your MacBook Pro, Chromebook or other
USB-C laptop, adding 4K video, VGA, GbE and one USB 3.0 Type-A port
• Connect your laptop to a projector and enjoy multimedia content at home, or display engaging presentations in
boardrooms and classrooms
• Use an HDMI port-equipped television in a hotel room as an external display when traveling
• Integrate the compact adapter into small workspaces in offices and home offices
Hardware
Warranty
3 Years
4K Support
Yes
Fast-Charge Port(s)
No
Displays Supported
1
Bus Type
USB-C
Industry Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Chipset ID
Cypress - CYPD2122
Cypress - CYUSB3314
STMicroelectronics - STDP2650
Chrontel - CH7517
ASIX - AX88179
Performance
Maximum Data Transfer
Rate
5 Gbps (USB 3.0) <br / >2 Gbps (Ethernet; Full-Duplex)
Features
• 4-IN-1 PORTABLE DOCK: This USB C multiport adapter to 4K 30Hz HDMI or 1080p VGA video display for a single
monitor, USB-A (USB 3.1 Gen 1 5Gbps) port & GbE for USB-C laptops, tablets, smartphones
• WIDE DEVICE COMPATIBILITY: This USB C travel dock is compatible with USB-C & Thunderbolt 3 (TB3) devices
like HP Spectre & EliteBook, Dell XPS, Lenovo Yoga, MacBook Pro & MacBook Air and Chromebooks
• WIDE OPERATING SYSTEM COMPATIBILITY: The USB Type-C digital AV multiport adapter is fully compatible
with major operating systems like Windows, macOS, and Chrome OS
• COMPACT & LIGHT DESIGN: This USB bus powered portable mini docking station for laptops is designed to easily
fit in a laptop bag or pocket for on-the-go travel and work from home applications
• STYLISH HOUSING: The usb-c all in one adapter hub has an all-white housing and attached cable that matches
well with MacBooks, Chromebooks, and other laptop and ultrabooks using the same finish
Maximum Analog
Resolutions
2048 x 1280p - 30Hz (VGA)
Maximum Digital
Resolutions
3840 x 2160p - 30Hz (HDMI)
Audio Specifications
HDMI output - 7.1 surround sound
Type and Rate
USB 3.0 - 5 Gbit/s
UASP Support
Yes
Compatible Networks
10/100/1000 Mbps
Auto MDIX
Yes
Full Duplex Support
Yes
Connector(s)
Connector Type(s)
USB Type-C (24 pin) USB 3.0 (5Gbps)
HDMI (19 pin)
VGA (15 pin, High Density D-Sub)
RJ-45
USB Type-A (9 pin) USB 3.0 (5 Gbps)
Software
OS Compatibility
Windows 7, 8, 8.1, 10
macOS 10.10 to 10.15
Chrome OS
Special Notes /
Requirements
System and Cable
Requirements
Host laptop with an available USB-C port (to ensure full functionality,
the laptop's USB-C port must support DP alt mode).
Note
Not all USB-C ports support the full functionality of the USB Type-C
standard. Ensure that your laptop USB-C port supports DP alt mode.
Only one video output port can be used at the same time (HDMI or
VGA). If two displays are connected, the HDMI port takes priority.
A 4K-capable display is required to achieve 4K x 2K resolution (4K is
also known as 4K x 2K).
USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard
offers speeds up to 5Gbps.
For MacBook host systems using macOS 10.12, version 10.12.6 or
later is required to support this product.
Power
Power Source
USB-Powered
Environmental
Operating Temperature
5C to 35C (41F to 95F)
Storage Temperature
-40C to 70C (-40F to 158F)
Humidity
5~95% RH (Non-condensing)
Physical
Characteristics
Color
White & Silver
Material
Plastic
Cable Length
4.1 in [10.5 cm]
Product Length
4.5 in [11.4 cm]
Product Width
2.1 in [54.0 mm]
Product Height
0.7 in [17.0 mm]
Weight of Product
2.5 oz [72.0 g]
Packaging
Information
Package Length
7.6 in [19.3 cm]
Package Width
4.9 in [12.4 cm]
Package Height
1.3 in [32.0 mm]
Shipping (Package)
Weight
5.4 oz [152.0 g]
What's in the
Box
Included in Package
USB-C multiport adapter for laptops
instruction manual
*Product appearance and specifications are subject to change without notice.
