3 ft DisplayPort™ 1.2 Cable with Latches M/M – DisplayPort 4k
StarTech ID: DISPLPORT3L
The DISPLPORT3L 3ft DisplayPort™ 1.2 Cable with latches provides a secure, connection between your
DisplayPort-equipped devices and is capable of providing higher performance than either HDMI® or dual link
DVI.
The DP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2
bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and
provides optional audio support.
The DISPLPORT3L is backed by StarTech.com’s Lifetime Warranty, for guaranteed reliability and ensures that
digitally protected content is displayed properly, with both HDCP and DPCP capability.
Applications
Connecting a DisplayPort Display to a PC or other DisplayPort Source
Features
High-resolution support of up to 4k x 2k
Support for High Bit Rate 2 (HBR2) bandwidth of up to 21.6 Gbps
Supports the DPCP (DisplayPort Content Protection) standard in addition to HDCP
Backward compatible with DisplayPort 1.1
Designed and manufactured to DisplayPort standards
Molded latching connectors with strain relief
www.startech.com
1 800 265 1844
Technical Specifications
Warranty Lifetime
Cable Jacket Type PVC - Polyvinyl Chloride
Cable Shield Type Aluminum-Mylar Foil with Braid
Connector Plating Nickel
Fire Rating CMG Rated (General Purpose)
Number of Conductors 19
Connector A 1 - DisplayPort (20 pin) Latching Male
Connector B 1 - DisplayPort (20 pin) Latching Male
Cable Length 3 ft [0.9 m]
Cable OD 0.3 in [6.5 mm]
Color Black
Connector Style Latching
Product Weight 2.3 oz [65 g]
Wire Gauge 30 AWG
Package Quantity 1
Shipping (Package) Weight 3.2 oz [90 g]
Included in Package 1 - 3 ft DisplayPort™ Cable with Latches - M/M
Certifications, Reports and Compatibility
www.startech.com
1 800 265 1844
