25 ft DisplayPort® Cable with Latches - M/M
StarTech ID: DISPLPORT25L
The DISPLPORT25L 25-foot DisplayPort® cable provides a connection of up to 25ft between a DisplayPort
source and a DisplayPort display, with no loss of signal quality – almost/,more than double the typical
DisplayPort connection distance limitation of 16ft. Its 26 gauge (AWG) pure copper wire, and Aluminum and
Mylar shielding helps to eliminate EMI and RFI interference. Delivering a maximum bandwidth of 10.8 Gbps, the
DISPLPORT25L is capable of providing higher performance than either HDMI® or dual link DVI and supporting
next generation multimedia applications with a maximum resolution capability of up to WQXGA (2560×1600).
The DisplayPort cable’s small, USB-sized latching connectors support two-way display connectivity and optional
audio support.
The DISPLPORT25L DisplayPort cable is both HDCP and DPCP capable, ensuring that digitally protected
content is displayed properly on the connected display.
Applications
Connecting a DisplayPort® display to a PC or alternative DisplayPort source
Features
Molded latching connectors with strain relief
Supports the DPCP (DisplayPort® Content Protection) standard in addition to HDCP
Designed and manufactured to DisplayPort standards
www.startech.com
1 800 265 1844
Technical Specifications
Warranty Lifetime
Cable Jacket Type PVC - Polyvinyl Chloride
Cable Shield Type Aluminum-Mylar Foil with Braid
Connector Plating Nickel
Fire Rating CMG Rated (General Purpose)
Number of Conductors 19
Connector A 1 - DisplayPort (20 pin) Latching Male
Connector B 1 - DisplayPort (20 pin) Latching Male
Cable Length 25 ft [7.6 m]
Cable OD 0 in [0.3 mm]
Color Black
Connector Style Latching
Product Weight 1.2 lb [0.5 kg]
Wire Gauge 26 AWG
Shipping (Package) Weight 1.2 lb [0.5 kg]
Included in Package 1 - 25 ft DisplayPort® Cable with Latches - M/M
Certifications, Reports and Compatibility
