USB-C Multiport Video Adapter - Space Gray - 4-in1 USB-C to VGA, DVI, HDMI or mDP - 4K
Product ID: CDPVDHDMDPSG
This USB-C multiport video adapter offers a portable solution for connecting your USB Type-C or
Thunderbolt 3 computer to a VGA, DVI, HDMI® or Mini DisplayPort display.
All-in-one video connectivity, with travel in mind
Avoid the hassle of carrying different adapters for different displays with this 4-in-1 USB-C video adapter’.
With VGA, DVI, HDMI and mDP output, you can connect your laptop to virtually any display. It’s a
convenient plug-and-play solution for travel or Bring Your Own Device (BYOD) applications, wherever you
go.
The adapter features a built-in magnetic fastener that helps guide the breakout cable into place for quick
and secure portability. With its durable aluminum enclosure, the adapter can withstand being carried
around in any travel bag.
www.startech.com
1 800 265 1844
Astonishing picture quality
The HDMI and mDP outputs on this adapter support UHD 4K resolutions providing four times the picture
quality of high-definition 1080p. All of the outputs (HDMI, mDP, VGA, DVI) can support high-definition
resolutions of up to 1920 x 1200.
Stylish connectivity for your space gray MacBook or any laptop
This USB-C adapter has an aluminum housing and built-in black USB-C cable designed to match your
space gray MacBook. The adapter is compatible with any device that supports USB-C DP Alt Mode.
The CDPVDHDMDPSG is backed by a StarTech.com 2-year warranty and free lifetime technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Keep the adapter with you while traveling, to connect to virtually any
display
• Connect your BYOD MacBook to a provided VGA, DVI, HDMI or mDP
display at work or school
• Connect a VGA, DVI, HDMI or Mini DisplayPort monitor to your space
gray MacBook, to use as a secondary monitor
Features
• 4-in-1 adapter - USB-C to VGA, USB-C to DVI, USB-C to HDMI or
USB-C to Mini DisplayPort
• Maximum portability with built-in magnetic cable manager
• Astonishing picture quality with support for 4K UHD
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Active or Passive Adapter Active
Adapter Style Adapters
AV Input USB Type-C
AV Output HDMI
DVI-D
VGA
Mini-DisplayPort
Chipset ID Cypress - CYPD1120
Cypress - CY7C65210
Parade - PS8348B
Parade - PS171
Performance Audio Specifications HDMI and mDP output - 7.1 surround sound
Maximum Analog Resolutions 1920 x 1200 @ 60Hz
Maximum Digital Resolutions 3840 x 2160 @ 30Hz
Supported Resolutions Max HDMI output: 3840 x 2160 @ 30Hz
Max mDP output: 3840 x 2160 @ 60Hz
HDMI and mDP output: 3840 x 2160, 2560 x 1600, 1920
x 1200, 1920 x 1080, 1280 x 720
DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x
720
Video Revision DisplayPort 1.2
Wide Screen Supported Yes
Connector(s) Connector A 1 - USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B 1 - Mini-DisplayPort (20 pin) Female Output
1 - VGA (15 pin, High Density D-Sub) Female Output
1 - DVI-D (25 pin) Female Output
1 - HDMI (19 pin) Female Output
Special Notes /
Requirements
Note Only one video output is supported on the video adapter at
a time, if multiple connections are made, only one of the
outputs will function
Environmental Humidity Storage: 5% ~ 90 % RH (no condensation)
Operating: 10% ~ 85 % RH (no condensation)
Operating Temperature 0°C to 45°C (32°F to 113°F)
www.startech.com
1 800 265 1844
Storage Temperature -10°C to 70°C (14°F to 158°F)
Physical
Characteristics
Cable Length 4.5 in [115 mm]
Color Space Gray
Enclosure Type Aluminum
Product Height 0.6 in [15 mm]
Product Length 4.1 in [104 mm]
Product Weight 3.2 oz [90 g]
Product Width 2.1 in [54 mm]
Packaging
Information
Shipping (Package) Weight 0.3 lb [0.1 kg]
What's in the Box Included in Package 1 - travel A/V adapter
Product appearance and specifications are subject to change without notice.
www.startech.com
1 800 265 1844
