USB-C to HDMI Adapter - 4K 60Hz
Product ID: CDP2HD4K60SA
This is no ordinary video adapter. Yes, it enables you to connect the USB-C port on your computer to an HDMI
display or projector, but it also features a unique Presentation Mode switch. When you turn on this switch, the adapter
prevents your computer from launching its screen saver, going to sleep or entering power save mode. The adapter
ensures that your screen will always stay on, making it the perfect USB-C video adapter for any presentation or
meeting.
When you deliver a presentation, your goal is to engage with your audience, not your computer. But, if you don't
move your mouse soon enough, or change your power settings, your screen goes black due to inactivity while you're
addressing the audience. This can be a major distraction when you're trying to focus on the message you're
communicating.
This adapter prevents screen disruptions with Presentation Mode, a unique feature that automatically initiates
occasional cursor movement to prevent your computer’s power settings from interrupting your presentation. It’s
perfect for sharing websites, drawings, spreadsheets, PDFs or slide shows during your meeting.
You can turn Presentation Mode on or off depending on your application. Turn it on when you're in the boardroom
and want your screen to stay on, and turn it off when you’re using the adapter at your workspace or office hot desk, to
enable your computer's original power settings to take effect. Using the toggle switch is easy, and saves you the
hassle of constantly making adjustments in your operating system settings.
To ensure easy operation and installation, this unique adapter is natively supported on Windows and Mac computers.
It’s easy to connect the adapter using the versatile USB Type-C port on your computer. The reversible USB-C
connector means you will always plug it in correctly on your first try, which saves you the hassle and distraction of
repeatedly attempting to connect your laptop to a display or projector.
This adapter lets you harness the video capabilities that are built into your computer's USB Type-C connection, to
deliver astonishing UHD 4K 60Hz resolution to your HDMI 2.0 display. This makes it easier for you to multitask while
you work on the most resource-demanding applications imaginable.
With this adapter, you can achieve an output resolution of up to 3840 x 2160p at 60Hz, which is perfect for performing
high-resolution tasks such as viewing 4K video. Plus, the adapter is backward compatible with 1080p displays, which
makes it a great travel accessory ensuring you can connect to any boardroom display or projector.
The CDP2HD4K60SA is backed by a 3-year StarTech.com warranty and free lifetime technical support.
Note: Your USB-C equipped device must support video to work with this adapter.
Certifications, Reports and Compatibility
Applications
• Keep this adapter with you while you travel to ensure you can connect to any HDMI display you come across
• Be ready to present from your laptop, with the peace of mind in knowing your laptop will not enter power save mode
when you don't want it to
• Connect an HDMI display to your USB-C laptop to use as a secondary monitor
Page 2
Features
Hardware
Warranty
3 Years
AV Input
USB-C
Ports
1
AV Output
HDMI - 2.0
Performance
Maximum Cable Distance
To Display
23.0 ft [7 m]
Maximum Digital
Resolutions
3840 x 2160 (Ultra HD 4K) @ 60Hz
Supported Resolutions
1024 x 768
1280 x 720
1920 x 1080
1920 x 1200
2560 x 1440
2560 x 1600
3840 x 2160
• Equipped with a Presentation Mode feature to ensure your video output is not interrupted by your computer’s power
saving modes
• Avoid the hassle of adjusting power settings, with an easy-to-use toggle switch that lets you turn Presentation Mode
on or off
• Works on Mac and Windows computers
• Support for Ultra HD video resolutions up to 4K at 60Hz
• Hassle-free connection with the reversible USB-C connector
• Maximum portability with a small footprint and lightweight design
• Thunderbolt 3 port compatible
• 7.1 audio support
Page 3
Wide Screen Supported
Yes
Audio Specifications
HDMI - 7.1 Channel Audio
Connector(s)
Connector A
USB-C (24 pin) DisplayPort Alt Mode
Connector B
HDMI (19 pin)
Special Notes /
Requirements
System and Cable
Requirements
Your USB-C port must support DisplayPort over USB-C (DP Alt mode)
in order to work with this adapter.
Note
This video adapter is not compatible with cables that use RedMere
technology.
Environmental
Operating Temperature
5C to 35C (41F to 95F)
Storage Temperature
5C to 35C (41F to 95F)
Humidity
25% to 85% RH Non-Condensing
Physical
Characteristics
Color
Black
Accent Color
Black
Cable Length
3.7 in [95 mm]
Product Length
7.5 in [19.0 cm]
Product Width
1.7 in [43.0 mm]
Product Height
0.6 in [16.0 mm]
Weight of Product
1.0 oz [28.0 g]
Packaging
Information
Package Length
9.3 in [23.5 cm]
Package Width
3.2 in [82.0 mm]
Package Height
0.9 in [22.0 mm]
Shipping (Package)
2.4 oz [67.0 g]
Page 4
Weight
What's in the
Box
Included in Package
USB-C to HDMI video adapter
quick-start guide
*Product appearance and specifications are subject to change without notice.
